Kenmore 11070222511 gas dryer Parts

For Kenmore gas dryer model 11070222511, the installation guide lists the cabinet at about 27 inches wide and 43 3/8 inches tall, with depth varying by door style (about 27 3/4 inches for a side-swing door or about 29 inches for a hamper door). See the 11070222511 installation guide for the exact diagram and clearance notes.

Dimensions and what they mean

These measurements help you confirm fit in a laundry room, closet, or recessed alcove.

• Width: about 27 inches
• Height: about 43 3/8 inches
• Depth (door closed): about 27 3/4 inches (side-swing door) or about 29 inches (hamper door)
• Rear clearance for venting: most installs need about 5 1/2 inches behind the dryer for the exhaust elbow
• Door swing: allow space for the door to open fully

Quick size table

Measurement	Side-swing door (A)	Hamper door (B)
Width	~27 in	~27 in
Height	~43 3/8 in	~43 3/8 in
Depth	~27 3/4 in	~29 in

Why it matters

Getting the size right prevents common installation problems like a crushed exhaust vent, a door that cannot open fully, or a tight closet that restricts airflow. Proper spacing also supports safe venting and better drying performance.

Related installation tips (common for this model type)

• Use 4-inch metal venting (rigid or flexible metal), not foil-type vent
• Keep the vent run as short and straight as possible to reduce dry times
• Plan for at least 1 inch of airspace at the front and sides in tight installs
• Confirm your door style (side-swing vs hamper) before measuring depth

Last updated: February 2026

On Kenmore gas dryer model 11070222511, the model and serial information (used to identify the correct replacement parts) is typically on a rating label inside the dryer door opening. We use that label info to match the exact parts list for your dryer.

Where to look on the dryer

Check these common label locations first:

• Inside the door opening on the front panel (most common)
• On the door itself near the hinge side
• On the front frame just behind the lint screen housing
• On the back panel (less common)

What numbers you should write down

The rating label usually includes several identifiers. Here is what each one is for:

Label item	What it’s used for	Example format
Model number	Matches the correct parts diagram	11070222511
Serial number	Helps confirm production series	Letters and numbers
Type/series info	Helps with variations within a model	Code or revision

Why this matters when ordering parts

Kenmore dryers often have multiple versions that look similar. Using the exact model number and serial number from the rating label prevents ordering the wrong belt, igniter, thermostat, or timer.

If you’re replacing a wear item, we commonly see customers match parts by symptom, then confirm by model:

• Squealing or thumping: drum support rollers and idler pulley (often sold together)
• Drum not turning: belt or drive motor
• No heat: igniter, radiant sensor, or high-limit thermostat

For model-specific diagrams and label guidance, use the 11070222511 owner’s manual.

Last updated: February 2026

The average lifespan of the Kenmore 11070222511 gas dryer is about 13 years. Regular airflow maintenance (lint screen and venting) and replacing wear items like the belt and rollers on time helps this dryer reach that typical service life.

What affects lifespan most

A dryer usually fails early from heat stress, restricted airflow, or worn drum-drive parts. For model-specific care and safety steps, follow the 11070222511 owner's manual.

• Clean the lint screen before or after each load.
• Keep the exhaust outlet area free of lint, dust, and debris.
• Have the interior cabinet and exhaust vent cleaned periodically by qualified service personnel.
• Use a short, smooth, 4-inch metal vent whenever possible; avoid excessive elbows.
• Stop using the dryer if you notice burning smells, overheating, or repeated shutdowns.

Typical lifespan by component (what you may replace first)

Component area	Common wear signs	Example part for this model
Drum drive	Squealing, thumping, drum not turning	Belt 341241
Heat system (gas)	No heat, intermittent heat	Igniter 279311
Air movement	Poor drying, loud rumble	Dryer blower wheel WP694089
Temperature control	Overheating, long dry times	Dryer operating thermostat WP3387134

Why it matters

A 13-year lifespan assumes safe venting and normal loads. Restricted airflow makes the dryer run hotter and longer, which accelerates wear on the motor, thermostats, and gas burner components.

Last updated: March 2026
