Kenmore 25354703409 refrigerator Parts

The exact cubic-foot capacity for Kenmore model 25354703409 is listed on the model’s specification information in the 25354703409 owner's manual. If you do not see it right away, check the “Features at a glance” or specifications section; capacity is typically shown as total, with separate fresh food and freezer volumes.

How to find the capacity on your refrigerator

We use the manual first because it’s the most reliable source for model-specific specs.

• Look for a specifications or product data section in the 25354703409 owner's manual
• Check for total capacity (cu. ft.) plus refrigerator and freezer breakdowns
• If the manual lists only compartment volumes, add them for total capacity
• Compare the manual to the serial plate inside the fresh food compartment (model and serial are shown there)
• If you have a printed tech sheet behind the toe grille or rear cover, it may also list capacity

Typical capacity range (for quick expectations)

Most Kenmore 253-prefix side-by-side refrigerators are commonly in the 20 to 26 cu. ft. range. Use this only as a sizing expectation; the manual provides the exact number for 25354703409.

What you’re checking	What it means	Where to look
Total capacity (cu. ft.)	Overall storage volume	Manual specifications section
Fresh food capacity	Refrigerator-side volume	Manual specs or features pages
Freezer capacity	Freezer-side volume	Manual specs or features pages

Why it matters

Capacity affects shelf and bin fit, food storage planning, and replacement decisions (for example, matching door bins, crisper pans, and water filter schedules to how heavily the refrigerator is used).

Last updated: February 2026

Kenmore is a brand label, so different manufacturers have built Kenmore refrigerators over the years; the quickest way to identify who built yours is to use the model number prefix. For Whirlpool-built Kenmore units, the model number commonly starts with 106 (and some other Whirlpool-associated prefixes show up on non-refrigerator Kenmore products). For your Kenmore 25354703409, the 253 prefix points to a different manufacturer than Whirlpool.

How to tell who made your Kenmore refrigerator

Use the first three digits of the model number (the prefix) as the manufacturer identifier.

• Find the model number on the rating plate (typically inside the fresh food compartment).
• Write down the first three digits.
• Match the prefix to the manufacturer family.
• Use the full model number when ordering parts to avoid fit issues.
• Confirm details in the 25354703409 owner's manual.

Common Kenmore refrigerator prefixes (quick guide)

These are the prefixes we see most often on Kenmore refrigerators.

Kenmore prefix	Commonly associated with	What it means for parts
106	Whirlpool-built Kenmore	Many parts cross-reference to Whirlpool designs
253	Frigidaire/Electrolux-built Kenmore	Parts typically cross-reference to Frigidaire-style designs
795	LG-built Kenmore	Parts typically cross-reference to LG-style designs

Why it matters

The manufacturer affects parts compatibility, wiring layouts, and service procedures. Using the correct manufacturer family helps you choose the right water filter, ice maker components, door gaskets, and control parts for your exact refrigerator.

If you are replacing filtration parts on this model, the manual calls out Kenmore replacement cartridge 46 9910; on our parts list that corresponds to the genuine Kenmore refrigerator water filter WFCB.

Last updated: February 2026

On Kenmore side-by-side refrigerator model 25354703409, the model number is printed on the serial plate located inside the refrigerator (fresh food) compartment. Open the refrigerator door and look along the interior walls for the rating label; it lists the model and serial information.

Where to look (fast checklist)

• Open the refrigerator door (not the freezer door)
• Look inside the fresh food compartment for the serial plate/rating label
• Check the side walls near the front, around the crisper area, or near the ceiling light
• Wipe the label gently if it is hard to read (soap and water only)
• Record the model number exactly as shown (for this unit it starts with 253)

What the label typically shows

The serial plate usually includes both identifiers you need for parts and service.

Item on label	What it’s used for	Example format
Model number	Matching parts diagrams and replacement parts	253XXXXXXXXX
Serial number	Production info and service history	Letters + numbers

Why it matters

We use the exact model number to match the correct Kenmore parts for your refrigerator, such as the correct door gasket, ice maker components, or the right water filter cartridge.

Helpful reference

For model-specific details and diagrams, use the 25354703409 owner's manual.

Last updated: February 2026

On Kenmore model 25354703409 side-by-side refrigerators, defrost is typically controlled by an automatic defrost control (not a separate, easy-to-spot mechanical timer). The control is commonly located in the temperature control housing inside the fresh food (refrigerator) section; confirm the exact access steps in the 25354703409 owner's manual.

What you will usually find on this model

Many Kenmore side-by-side units in this design family use an electronic or adaptive defrost control that works with the cold control and defrost system. In the manual, this shows up as “Cold Control & Automatic Defrost Control” rather than a stand-alone “defrost timer.”

Common access locations to check

• Temperature control console at the top of the fresh food compartment
• Control housing near the refrigerator light area
• Behind a small cover where the temperature controls are mounted
• Toe grille area (less common for the control itself, but you may see wiring and airflow)

Quick troubleshooting: timer vs. defrost system problem

If you are chasing frost buildup or warm temperatures, the issue is often in the defrost circuit, not the “timer.” Use this checklist before replacing parts.

• Heavy frost on freezer back wall points to a defrost failure
• Clicking/snapping can be normal when controls cycle on and off
• A sizzling or hissing sound during defrost can be normal
• Poor door sealing can mimic defrost problems by adding moisture
• Dirty condenser can increase run time and temperature complaints

What symptoms suggest which area

Symptom	Most likely area to inspect	What to do next
Solid frost blanket on evaporator cover	Defrost system	Check defrost heater circuit and defrost thermostat
Fridge warm, freezer OK	Airflow/damper	Verify vents are not blocked and damper operation
Unit runs “too long”	Seals, condenser, settings	Clean condenser, check gaskets, verify control settings

Why it matters

Knowing whether your 25354703409 uses an automatic defrost control helps you avoid searching for a mechanical timer that is not there. It also keeps troubleshooting focused on the components that actually stop frost buildup and maintain airflow.

Last updated: February 2026

Most Kenmore side-by-side refrigerators are about 33 inches to 36 inches wide; your Kenmore 25354703409 falls in that common size range. For the exact cabinet width and the required clearance for doors and airflow, use the measurements listed in the 25354703409 installation guide.

Typical widths you will see (and what they mean)

Side-by-side refrigerator width is usually described in two ways:

• Cabinet width: the box itself (what must fit between cabinets)
• Overall width with doors/handles: can be wider than the cabinet
• Clearance space: extra room needed so doors open fully and the unit can breathe

Measurement type	What it affects	Typical range
Cabinet width	Fit in the opening	33 to 36 in.
With doors/handles	Walkway and door swing	34 to 38 in.
Side clearance	Door opening, airflow	1/8 to 1 in. per side

How to measure your refrigerator width correctly

We recommend measuring before ordering trim kits, doors, or bins.

• Measure across the back of the cabinet (not the doors)
• Measure at the widest point if the cabinet sides bow slightly
• If you have handles, measure handle-to-handle for overall width
• Confirm the unit is level; leveling can change how doors sit and swing
• Compare your numbers to the spec diagram in the 25354703409 installation guide

Why it matters

Width is only part of fit. Door swing and clearance determine whether you can fully open the fresh food and freezer doors, remove shelves and bins, and slide the refrigerator in without pinching the water line for the ice maker and dispenser.

Last updated: February 2026

Kenmore refrigerator model numbers are structured so the first 3 digits identify the manufacturing source, and the remaining digits narrow down the base design and specific feature variations. For Kenmore model 25354703409, the 253 prefix is the key identifier to start with.

How to break down a Kenmore model number

Most Kenmore model numbers follow this pattern:

• First 3 digits: manufacturer prefix (the most important part for parts matching)
• Next group of digits: base model platform or series
• Last digits: engineering revisions, color, or feature variations
• Full model number: always use the entire number when ordering parts

Example format (typical)

Section	Example	What it tells you
Prefix	253	Manufacturer prefix used for many Kenmore refrigerators
Base model	54703	Core design family (platform)
Variation	409	Version or feature set within that family

Where to find the model and serial number on this refrigerator

On Kenmore 25354703409, the owner’s guide indicates the serial plate is located inside the refrigerator compartment. Use mild soap and water to clean the serial plate so the numbers stay readable.

• Look along the side wall inside the fresh food section
• Check near the crisper area or upper interior liner
• Write down both the model and serial number for parts lookup

Why it matters

Kenmore often sold similar-looking side-by-side refrigerators with different internal components (ice maker parts, door bins, gaskets, controls). Using the full model number helps us match the correct Kenmore-compatible parts the first time.

For model-specific identification and location details, use the 25354703409 owner’s manual.

Last updated: February 2026

Most Kenmore refrigerators, including the Kenmore 25354703409 side-by-side, typically last 12 to 15 years with normal household use. Keeping airflow clear, cleaning condenser areas, and maintaining door seals and filters helps you reach (and often exceed) that range; see the 25354703409 owner's manual for care and operating guidance.

What affects refrigerator lifespan most

• Condenser cleanliness and ventilation (dust buildup makes the compressor work harder)
• Door gasket condition (air leaks cause longer run times and frost issues)
• Temperature settings (steady settings reduce cycling stress)
• Ice maker and dispenser use (jams and leaks add wear)
• Water filter maintenance (protects water flow to the dispenser and ice maker)

Typical lifespan by major system

Component or system	Typical lifespan	What you notice when it’s wearing out
Compressor and sealed system	12 to 15 years	Warm temps, long run times, poor cooling
Evaporator fan and airflow parts	8 to 12 years	Warm fridge, noisy fan, uneven temps
Ice maker and dispenser parts	5 to 10 years	No ice, small cubes, jams
Door gaskets	5 to 10 years	Moisture, frost, doors not sealing

Maintenance that extends life (high impact)

• Vacuum dust from the condenser area and keep clearance around the cabinet for airflow.
• Keep freezer and fresh food temps stable (avoid frequent setting changes).
• Check for a tight seal by closing a dollar bill in the door; resistance should feel consistent.
• Replace the water filter on schedule; for this model, the filter cartridge is commonly genuine Kenmore refrigerator water filter WFCB.
• If ice clumps or jams, empty the bin and loosen cubes by shaking the bin (avoid sharp tools).

Why it matters

A refrigerator that runs longer to hold temperature uses more energy and puts extra load on the compressor and fans. Simple upkeep (airflow, seals, and filtration) directly reduces run time and helps the refrigerator reach its full service life.

Last updated: February 2026

The most common issues we see on Kenmore refrigerators like model 25354703409 are warm temperatures from airflow problems (dirty condenser coils, fan issues, or defrost trouble), water leaks from a clogged defrost drain or loose water connections, and ice maker or dispenser jams. Use the 25354703409 owner's manual troubleshooting section to match symptoms to the fastest fix.

Most common symptoms and what usually causes them

• Not cooling or too warm: dirty condenser coils, doors left ajar, controls set too warm, evaporator airflow restricted by frost
• Moisture or frost inside: door slightly open, frequent door openings, humid conditions
• Water leaking or puddles: clogged defrost drain, cracked water line, leaking filter housing or reservoir
• Ice maker not working: water supply issue, frozen fill tube, ice maker failure
• Ice dispenser jammed: cubes melting and refreezing after a power outage or from infrequent use (shaking the bin typically clears it)
• Noisy operation: fan blade hitting ice, worn fan motor, items vibrating against the cabinet

Quick checks we recommend first (fast, no parts)

1. Confirm the fresh food and freezer controls are not set to “0” (that stops cooling but still leaves power to lights and other components).
2. Make sure doors fully close and seals are clean.
3. Clean condenser coils and verify airflow around the unit.
4. If the ice dispenser is jammed, remove the bin and shake to loosen cubes (do not use sharp tools).
5. After changing a filter, flush water for several minutes to purge air.

Common fixes and related parts (when replacement is needed)

Problem	What to inspect	Part that often applies to this model
Bad tasting/slow water, weak ice production	Water filter age, trapped air after replacement	Genuine Kenmore refrigerator water filter WFCB
Warm fridge with normal compressor run	Frost buildup, defrost system	Refrigerator defrost bi-metal thermostat 5303918214
Poor airflow, warm sections, fan noise	Evaporator fan blade damage/ice contact	Refrigerator evaporator fan blade 5308000010

Why it matters

Catching airflow and sealing problems early helps your compressor and sealed system run less, keeps food at safe temperatures, and prevents repeat issues like frost buildup, dispenser jams, and interior moisture.

Last updated: February 2026

Yes. We still carry replacement parts for Kenmore refrigerators, including the Kenmore 25354703409 side-by-side. The key is matching parts to your exact model number so items like water filters, door gaskets, and ice maker components fit and work correctly (use the 25354703409 owner's manual to confirm locations and procedures).

How to find the right part for your Kenmore model

Use your model number (for example, 25354703409) and then match by part name and part ID.

• Confirm the full model number from the rating plate inside the fresh food section
• Identify the system you are repairing (ice maker, dispenser, cooling, door seal, lighting)
• Match the part ID and description, not just a similar-looking photo
• For water and ice parts, confirm your filter style and connection type
• If you are unsure, compare the old part markings to the replacement listing

Common Kenmore 25354703409 parts customers replace

Here are examples of parts available for this model that commonly wear out or get damaged:

What you are fixing	Common symptom	Example part for this model
Water taste/flow	Slow dispenser flow, bad taste/odor	Genuine Kenmore refrigerator water filter WFCB
Door sealing	Frost, moisture, warm spots near door	Refrigerator gasket 241786014
Ice production	No ice, small cubes, leaking ice maker	Ice maker mold 241798231
Interior lighting	Light out in fresh food/freezer	Refrigerator light bulb 316538904

Water filter note (model-specific)

For Kenmore refrigerators with the rear ice and water filter system, the manual calls out Kenmore replacement cartridge 46 9910 and notes the filter is an expendable item with a shorter warranty period than the refrigerator itself. Follow the steps in the 25354703409 owner's manual when changing the filter and flushing the system.

Why it matters

Using the correct Kenmore part for your exact model helps prevent leaks, poor cooling, dispenser jams, and repeat repairs. It also saves time because you avoid returns caused by near-match parts.

Last updated: February 2026
