To reset your Frigidaire FGGF3030PFE gas range oven, we recommend doing a power reset: turn the oven controls OFF, then shut off power to the range for a full minute and restore power. After power returns, reset the clock and try Bake or Broil again using the steps in the FGGF3030PFE owner's manual.

Quick reset steps (safe order)

• Turn the oven function to OFF.
• If the oven is hot, let it cool before troubleshooting.
• Shut off power at the breaker (preferred) or unplug the range.
• Wait 60 seconds.
• Restore power.
• Set the clock, then test Bake at 300°F.

What to check after the reset

A reset clears many temporary control glitches, but it will not fix an ignition or sensor failure. Use these checks to narrow it down:

• Bake ignition timing: the oven burner should ignite within about 60 seconds after starting Bake.
• Broil ignition timing: the broil burner should ignite within about 60 seconds after starting Broil.
• Normal cycling: once preheated, the igniter and flame cycle on and off to hold temperature.
• No heat after reset: focus on igniters, gas supply, and the temperature sensor.

Symptom after reset	Most likely area	Common next step
No Bake heat, Broil works	Bake ignition circuit	Inspect/replace igniter
No Broil heat, Bake works	Broil ignition circuit	Inspect/replace broil igniter
Both Bake and Broil fail	Power, gas supply, control	Verify power, then diagnose control/valve
Oven heats poorly or erratically	Temperature sensing	Test/replace sensor

Parts that commonly solve “won’t heat” after a reset

If the oven does not ignite within the normal time window, these model-matched parts are common fixes:

• Tappan range oven burner igniter 316489403 (bake igniter)
• Frigidaire range broil igniter 5304506545 (broil igniter)
• Range oven temperature sensor 316490000 (temperature feedback to the control)

Why it matters

A proper reset restores the electronic control to a known state, but ignition timing is also a safety and performance check. If the burner does not light within about a minute, the oven cannot regulate temperature correctly and cooking results suffer.

Last updated: February 2026

If your Frigidaire FGGF3030PFE gas range smells like gas, treat it as a safety issue first: turn all burner and oven controls OFF, avoid flames and switches, and follow the “What to do if you smell gas” steps in the FGGF3030PFE installation guide. After the area is safe, common causes include a burner that is not igniting fully, clogged burner ports, or an igniter that is not heating properly.

What to do right now (safety first)

• Turn all surface burner knobs and the oven control to OFF.
• Do not try to light any appliance.
• Do not touch electrical switches or use a phone inside the home.
• Call your gas supplier from a neighbor’s phone and follow their instructions.
• If you cannot reach the gas supplier, call the fire department.

Common causes when the smell happens only during use

A brief odor at ignition can happen, but a persistent gas smell usually points to incomplete ignition or poor combustion.

• Dirty or clogged burner ports: gas flows but the flame does not spread evenly.
• Weak or failing oven igniter: the igniter glows but does not pull enough current to open the gas valve reliably.
• Surface burner ignition issues: clicking without a steady flame can allow gas to accumulate.
• Ventilation problems: prolonged use without adequate ventilation can be dangerous.

Quick symptom guide

When you smell gas	Most likely area to check	What you typically see
Only when baking	Oven bake ignition	Delayed ignition, “whoosh,” uneven flame
Only when broiling	Broil ignition	Slow light-off, weak broil flame
Only on one top burner	That surface burner	Clicking, uneven flame ring
Even when everything is OFF	Gas supply/connection	Odor persists with no flame

Parts that commonly fix ignition-related gas odor

If the oven is slow to light or you smell gas before ignition, these model-compatible parts are common suspects:

• Tappan range oven burner igniter 316489403
• Frigidaire range broil igniter 5304506545

Why it matters

Unburned gas can build up and create a fire or explosion risk. Addressing ignition and burner issues promptly helps your range light quickly, burn cleanly, and operate safely.

Last updated: February 2026

If your Frigidaire FGGF3030PFE gas range oven is not heating, the most common cause is a weak bake igniter that glows but does not get hot enough to open the oven gas valve. This model’s ignition sequence normally takes about 30 to 60 seconds before the burner flame appears.

Quick checks we recommend first

• Confirm the range has electrical power; the oven igniter will not operate during a power failure.
• Set Bake to 300°F and wait a full 60 seconds for ignition.
• Look through the oven bottom openings for an igniter glow.
• Make sure the oven vent and the area around the lower front panel are not blocked; the range needs fresh air for proper combustion.
• If you smell gas with no ignition, turn the oven control OFF and ventilate the area.

What “normal” ignition looks like on this range

When you set Bake, current flows to the igniter; it should glow like a light bulb. After it heats up, the oven valve opens and the burner lights.

What you see	What it usually means	What to do next
Igniter does not glow	No power to igniter or failed igniter/circuit	Check power, then test wiring and igniter
Igniter glows, no flame after 60 seconds	Weak igniter or gas valve not opening	Replace igniter first; then evaluate gas valve
Flame lights, then cycles off/on	Normal temperature control cycling	Allow preheat time; verify temperature accuracy

Parts that commonly fix “oven won’t heat”

For the FGGF3030PFE, these are the most common heat-related parts we see involved:

• Tappan range oven burner igniter 316489403 (bake ignition)
• Frigidaire range broil igniter 5304506545 (broil ignition, if broil also fails)
• Frigidaire range oven gas valve 316031501 (opens to feed gas after igniter heats)
• Range oven temperature sensor 316490000 (can cause temperature control problems)

Why it matters

A gas oven that does not ignite can leave you with no baking heat and can create unsafe conditions if gas is present without ignition. Keeping the venting area clear and ensuring the igniter and valve operate correctly helps the oven light reliably and heat evenly.

For operating steps and troubleshooting guidance specific to this model, use the FGGF3030PFE owner’s manual.
