Kenmore 25371112103 top-mount refrigerator

Kenmore 25371112103 top-mount refrigerator Parts

Here are the diagrams and repair parts for Kenmore 25371112103 top-mount refrigerator, as well as links to manuals and error code tables, if available.

By Schematic
By Part
SELECT DIAGRAM
?

This is the number corresponding to the part on the diagram / schematic

Browse Parts for 25371112103 Refrigerators

Kenmore Top-Mount Refrigerator 25371112103 FAQs

Most Kenmore refrigerators last 12 to 15 years. For the Kenmore 25371112103 top-mount refrigerator, regular care like keeping airflow clear, cleaning, and maintaining good door sealing helps you reach that typical lifespan and often go beyond it (especially with consistent upkeep).

What affects lifespan the most
  • Condenser coil cleanliness (dust buildup makes the compressor work harder)
  • Door gasket condition (air leaks cause longer run times and frost issues)
  • Stable power supply (voltage drops can stress the compressor)
  • Good ventilation around the cabinet (blocked airflow raises operating temps)
  • Correct temperature settings (over-cooling increases wear)
Maintenance checklist (simple, high impact)
  • Vacuum and brush condenser coils and the condenser fan area every 6 to 12 months.
  • Keep door gaskets clean; wipe with mild soap and water, then dry.
  • Confirm doors close fully and do not pop open after loading.
  • Replace burned-out bulbs only with the correct type and unplug the refrigerator first.
  • Avoid extension cords and outlets controlled by a wall switch.
Quick reference: lifespan vs. what you can control
Item Typical impact on lifespan What to do
Dirty condenser coils High Clean on a schedule
Leaking door gasket High Clean, reshape, or replace if torn
Low or unstable voltage Medium to high Use a properly grounded outlet
Overpacked vents/shelves Medium Keep air paths open
Why it matters

A refrigerator that runs longer and hotter than it should wears out the sealed system faster. The owner guidance for this model emphasizes safe power practices and proper use and care, which directly supports longer compressor and cooling-system life.

For model-specific operating and care details, use the 25371112103 owner's manual.

Last updated: January 2026

Kenmore is a brand name sold by Sears, and model 25371112103 is part of the Kenmore 253 model prefix family shown in the model number format in the 25371112103 owner’s manual. In this series, the 253 prefix is commonly associated with refrigerators built for Kenmore by Frigidaire (Electrolux).

How to confirm the manufacturer on your exact unit

The most reliable way is to use the identification label inside the fresh food compartment (the manual notes the serial plate is located inside the refrigerator compartment).

  • Look for the model and serial tag inside the refrigerator section
  • Check for a manufacturer name such as Frigidaire or Electrolux on the label
  • Write down the full model number and serial number before ordering parts
  • Match parts by model number 25371112103 (not just “Kenmore 253”) to avoid fit issues
What the model prefix means (quick guide)

Kenmore model numbers often start with a 3-digit prefix that points to the original manufacturer.

What you see What it usually indicates Why it helps
253.XXXXXXX Frigidaire-built Kenmore refrigerator Points you toward Frigidaire-style parts and designs
970.XXXXXXX Another Kenmore supplier prefix shown in the manual Helps when cross-referencing parts lists
Why it matters when buying parts

Knowing who built the refrigerator helps you choose the right replacement parts and troubleshooting steps, especially for sealed system components and common wear items like a refrigerator light bulb or door gasket.

If you are replacing a common item, match by model first, then verify the part ID. For example, the refrigerator light bulb 316538904 is a model-matched part option for this refrigerator.

Last updated: January 2026

Kenmore model 25371112103 is a top-mount refrigerator, not an upright freezer; its cubic-foot capacity is listed in the product specifications section of the 25371112103 owner's manual. Use that spec (not an upright-freezer rating) when planning food storage or measuring fit.

How to find the cubic feet (capacity) for this model

We recommend using the manual because it’s the model-specific source for capacity and other key specs.

  • Open the 25371112103 owner's manual
  • Look for “Product specifications” or “Capacity” (often shown as total, refrigerator, and freezer)
  • Record the total cubic feet and the freezer vs. fresh food breakdown
  • If you’re comparing models, also note the exterior width and height listed near the capacity
Quick comparison: upright freezer vs. top-mount refrigerator
Appliance type What “cubic feet” represents Typical use
Upright freezer Total frozen storage volume Bulk frozen food storage
Top-mount refrigerator (25371112103) Total volume split between fresh food and freezer Everyday refrigerated and frozen storage
Why it matters

Capacity numbers are only meaningful when they match the appliance type. A top-mount refrigerator’s cubic feet includes both compartments, so it will not compare 1:1 with an upright freezer’s all-freezer storage.

Last updated: January 2026
