Kenmore 11096284100 dryer feature sheet Parts

Many Kenmore dryers, including model 11096284100, were built for Kenmore by major manufacturers such as Whirlpool; the exact manufacturer can vary by model series and production run. For this specific dryer, use the model’s documentation and parts list to match the correct Kenmore-compatible replacement parts and specifications in the 11096284100 owner’s manual.

What “Kenmore” means for dryer manufacturing

Kenmore is a brand name; different companies have produced Kenmore dryers over the years. What matters most for repairs is using the correct model number (11096284100) and matching parts.

• The manufacturer behind a Kenmore dryer can vary by era and model family.
• Parts compatibility is determined by the model number, not the badge on the front.
• Many Kenmore 110-series dryers share design and parts lineage with Whirlpool-built platforms.
• Your feature sheet shows a 27-inch extra-capacity design with a 7.0 cu. ft. drum, which is typical of many Whirlpool-platform Kenmore dryers.
• When troubleshooting heat or airflow issues, always confirm the exact part by model.

How to confirm what you need for repairs (the practical approach)

Instead of focusing on the nameplate manufacturer, we recommend confirming these items first:

• Model number: 11096284100
• Fuel type: electric vs. gas (feature sheet lists both variants)
• Venting configuration (feature sheet notes 4-way venting with a separate elbow)
• Symptom (no heat, long dry times, won’t start, squealing)
• The exact replacement part ID used for your repair

Common parts customers replace on this model

Symptom	Common part to check	Example part for this model
No heat (electric)	Heating circuit	Dryer heating element WP3387747
Won’t start / stops	Overheat protection	Dryer thermal fuse WP3390719
Squealing / thumping	Belt drive support	Dryer idler pulley 279640

Why it matters

Kenmore sourcing varies, but your repair success does not. Matching parts to 11096284100 prevents ordering the wrong heating element, thermostat, motor, or fuse and helps restore safe, normal drying performance.

Last updated: February 2026

Your Kenmore dryer’s model number is printed on the appliance ID label; for most Kenmore dryers it’s easiest to spot inside the door opening on the cabinet frame. Once you have it (for example, 11096284100), use it to match the correct parts, wiring diagram, and specifications in the 11096284100 owner's manual.

Where to look for the model number label

Check these common locations on Kenmore dryers:

• Inside the dryer door opening on the front frame (most common)
• On the back panel of the dryer cabinet
• Around the lint screen housing area (near the top opening)
• On the door itself or the door hinge side area

What the model number tells you (and why it matters)

Kenmore model numbers help us identify the design family and ensure you get parts that fit and function correctly. For example, the feature sheet for Kenmore stock no. 62841 lists key specs like a 27-inch width and extra capacity; those details are tied to the correct model identification.

Why it matters

• Ensures the right replacement parts fit the cabinet and drum
• Helps match electrical and heating components correctly (electric vs. gas versions)
• Prevents ordering look-alike parts that mount differently

Quick checklist: model number vs. serial number

Use this to avoid mix-ups when ordering parts.

Item	What it looks like	What we use it for
Model number	Longer number string (example: 11096284100)	Parts lookup, diagrams, specs
Serial number	Letters and numbers, often includes date code	Manufacturing tracking and service history

After you find it: next best steps

• Write the model number exactly as shown on the label
• Compare it to the model shown on the 11096284100 owner's manual
• If you’re troubleshooting heat issues, confirm whether your dryer is electric or gas before ordering parts
• When replacing heat-related parts, use the correct match for your model, such as the dryer heating element WP3387747 (electric models)

Last updated: February 2026

Common failures on the Kenmore 11096284100 dryer fall into four buckets: no heat, won’t tumble, poor airflow/long dry times, and shuts off from overheating. This model is a 27-inch extra-capacity dryer; when symptoms show up, a few high-wear parts are usually the cause (confirm procedures in the 11096284100 owner's manual).

Most common failures and what they look like

• No heat or weak heat: heating circuit problem (heater, thermal fuse, thermostat)
• Drum won’t turn: drive system problem (idler pulley, belt, motor)
• Long dry times: airflow restriction (lint screen, ducting, blower wheel)
• Stops mid-cycle: overheating protection opening (thermal fuse or cut-off)
• Won’t start: door switch, motor switch, timer, or power supply issue

Parts that commonly fail on this model

These are frequent replacement items for Kenmore dryers like model 11096284100:

Symptom	Likely part	Example from available parts
No heat	Heating element	Dryer heating element WP3387747
Dryer won’t run or stops	Thermal fuse	Dryer thermal fuse WP3390719
Overheats, then no heat	Thermal cut-off kit	Cut-off kit 279769
Squealing, thumping, no tumble	Idler pulley	Dryer idler pulley 279640
Poor airflow, rumbling	Blower wheel	Dryer blower wheel WP697772

Quick checks we recommend before ordering parts

• Clean the lint screen every load; confirm the screen is seated correctly.
• Check venting for kinks, crushed flex duct, or heavy lint buildup.
• Verify heat setting and cycle (Auto Dry vs Timed Dry) to match the load.
• Listen for clues: squeal (idler), rumble (blower), click then stop (overheat protection).
• Test electrical parts safely with a meter when needed (unplug dryer first).

Why it matters

Most “bad part” symptoms are made worse by restricted airflow. A clogged vent can overheat the heater housing and repeatedly open safety devices like the thermal fuse, so fixing venting prevents repeat failures and improves dry time.

Last updated: February 2026

The Kenmore dryer model 11096284100 is a standard 27-inch wide, extra-capacity dryer. Based on the model’s feature sheet, its approximate overall dimensions are 27 in. wide x 27-1/2 in. deep x 43-1/8 in. tall; confirm details in the 11096284100 manual.

Dimensions for Kenmore 11096284100

Here are the listed cabinet dimensions from the feature sheet:

Measurement	Size (inches)	Size (cm)
Width	27	68.6
Depth	27-1/2	69.9
Height	43-1/8	109.5

What to measure before you move or install it

Even with the cabinet size, we recommend planning for clearance and venting space.

• Add space behind the dryer for the exhaust duct connection
• Allow room to open the door fully and pull out the lint screen
• Measure doorways, hallways, and stair turns (a 27-inch cabinet can still be tight)
• Plan for side clearance so the drum can run without cabinet vibration contacting walls
• If you are changing vent direction, confirm the venting setup described in the 11096284100 manual

Why it matters

Correct dimensions help you avoid delivery surprises, crushed venting, and poor airflow. Tight installs often lead to longer dry times and overheating, which can trip safety devices like the thermal fuse.

Quick fit check (common planning numbers)

Planning item	Typical allowance
Rear vent/duct space	4 to 6 in.
Side clearance	1 in. each side
Front clearance for door	20+ in.
