Kenmore 79691172210 dryer Parts

Your Kenmore dryer’s model number is printed on the appliance ID label; for most Kenmore dryers it’s easiest to find by opening the door and checking the cabinet frame around the door opening. Once you have it, match it exactly (for example, 79691172210) when ordering parts.

Where to look for the model number label

Check these common locations in this order:

• Inside the dryer door opening on the cabinet frame (most common)
• On the back of the dryer cabinet near the top
• Along the door opening edge or inner front panel area
• On the side panel near the front edge (less common)

Use the format shown on the label; Kenmore model numbers are typically a long number string.

What to write down (so you get the right parts)

Record the key identifiers exactly as shown:

• Model number (example: 79691172210)
• Serial number (helps confirm production run)
• Type (gas or electric, if listed)

If you are shopping parts for this page, the correct model is Kenmore 79691172210.

Quick check: model number vs. part number

Item	What it identifies	Example format
Model number	The exact dryer design	79691172210
Part number	The manufacturer’s part code	4400EL2001A
Part ID	Sears PartsDirect part identifier	4400EL2001F

Why it matters

We use the model number to match the correct drum belt, thermostat, igniter, door switch, and other dryer parts because Kenmore dryers can look similar while using different components.

For diagrams and the exact label locations called out for your dryer, use the 79691172210 manual.

Last updated: January 2026

For the Kenmore dryer model 79691172210, most units in this series are about 27 inches wide and about 43 to 44 inches tall, with about 27 to 28 inches of cabinet depth (not including the vent connection). For the exact dimensions and capacity for your configuration, use the 79691172210 owner's manual.

Typical dimensions you can plan around

When you are measuring for a laundry closet or side-by-side install, we recommend allowing space for the dryer cabinet plus door swing and venting.

• Width: ~27 in.
• Height: ~43 to 44 in.
• Depth (cabinet): ~27 to 28 in.
• Depth (with vent/clearance): plan for extra space behind the dryer
• Capacity: many Kenmore 796 dryers are around 7.0 cu. ft.

Quick measuring checklist

Use a tape measure and record all three cabinet dimensions.

• Measure width at the widest cabinet point (left to right)
• Measure height from floor to the top of the cabinet
• Measure depth from the front cabinet face to the back panel (exclude the vent elbow)
• Add clearance for the exhaust duct and power cord/gas line (if applicable)
• Confirm door swing clearance so the door opens fully

Size planning table

What you are planning for	What to use	Why
Laundry closet opening	Cabinet width/height	Ensures the dryer physically fits
Behind-dryer space	Depth plus vent clearance	Prevents crushed venting and long dry times
Side-by-side with washer	Width and door swing	Avoids door interference
Stacking (if supported)	Manual requirements	Prevents unsafe installs

Why it matters

Correct sizing helps prevent installation headaches and performance problems. A tight fit can kink the vent, restrict airflow, and lead to longer dry times and overheating symptoms.

Last updated: January 2026

PF on a Kenmore dryer indicates a power failure occurred during the cycle. On model 79691172210, you can usually clear PF by pressing Stop/Clear and then restarting the cycle; if PF returns, focus on the home power supply and the dryer’s power connection.

What to do when PF appears

• Press Stop/Clear to clear the display.
• Open and close the door, then reselect the cycle and press Start.
• If the load is still wet, run Timed Dry for 10 to 20 minutes to finish drying.
• If PF happens repeatedly, stop using the dryer until you correct the power issue.

Common causes of PF (and quick checks)

• Loose plug or outlet fit: Make sure the plug is fully seated and the outlet grips firmly.
• Tripped breaker: Reset the dryer breaker(s); many electric dryers use a 2-pole breaker.
• Power cord or terminal block issue: Inspect for heat damage or loose connections (unplug power first).
• House voltage drop: Other large appliances on the same circuit can cause brief dips.
• Control interruption: A momentary outage can trigger PF even if power returns quickly.

Parts that may be involved

If you find heat damage, intermittent power, or a loose connection at the cord, replacement is often the fix.

Symptom	Most likely area	What it affects
PF happens when the dryer is bumped	Outlet/plug fit	Intermittent power to control
PF after a few minutes of running	Breaker/house supply	Voltage stability
Burning smell at cord area	Cord/terminal connections	Safe power delivery

Consider checking the dryer power cord 6411EL1001H if your cord shows wear, overheating, or damaged prongs.

Why it matters

A PF code is more than an inconvenience; repeated power interruptions can stop heating mid-cycle, extend dry times, and point to an unsafe electrical connection that should be corrected before continued use.

For model-specific reset steps and operating details, use the 79691172210 owner’s manual.

Last updated: January 2026

To hard reset your Kenmore dryer model 79691172210, unplug the power cord (or switch the breaker off) for at least 1 minute, then restore power and try a normal cycle. This clears many temporary control glitches, but it will not fix airflow or failed-part problems.

Hard reset steps (safe and effective)

• Turn the dryer OFF.
• Unplug the dryer from the outlet (preferred) or turn the circuit breaker OFF.
• Wait 1 to 5 minutes.
• Restore power.
• Open and close the door once, then select a cycle and press Start.

If the dryer still will not run or keeps acting up

A reset helps when the control is confused, but common dryer issues are mechanical or airflow-related.

• Check that the door fully latches; a failed door switch can prevent starting.
• Clean lint buildup and confirm strong exhaust airflow; poor venting can cause overheating and shutdowns.
• If the drum will not turn or you hear squealing, inspect the belt and idler system.
• If the dryer runs but shuts off early or dries poorly, check the moisture sensor bars and wiring.
• If you see an error code, use a model-family error code reference to narrow the failure.

Parts that commonly relate to “reset” symptoms

Symptom after reset	Most likely area	Example part for this model
Drum will not turn, motor runs or hums	Belt or idler	Dryer drum belt 4400EL2001F
Stops mid-cycle, overheats, long dry times	Airflow or thermostat	Dryer high-limit thermostat (inspect vent first)
Auto cycles end too soon or clothes still damp	Moisture sensing	Dryer moisture sensor and harness

Why it matters

Hard resets clear the control board’s temporary state, but dryers most often fail due to restricted venting, door-latch/door-switch problems, or drum drive wear. Fixing the root cause prevents repeat shutdowns and protects heating components.

For model-specific operating steps and control behavior, follow the 79691172210 dryer manual.

Last updated: January 2026
