Samsung RS265TDBP/XAA-00 refrigerator Parts

The Samsung RS265TDBP is a 26 cu. ft. class side-by-side refrigerator (the manual covers “26 cubic feet and larger capacity”). For exact exterior dimensions (width, height, depth), use the specifications section in the RS265TDBP owner's manual.

What “size” can mean (capacity vs. dimensions)

When customers ask for “size,” it usually means one of these:

• Capacity (cubic feet): how much food it holds
• Exterior dimensions: width, height, and depth (often with and without handles)
• Fit requirements: clearance for doors, airflow, and water line routing
• Door style/layout: side-by-side with freezer door ice maker

Typical exterior dimensions for this refrigerator class

Most Samsung 26 cu. ft. class side-by-side models are approximately:

Measurement	Typical range
Width	~35 3/4 in. to 36 in.
Height (to top of hinge)	~69 in. to 71 in.
Depth (varies by handles)	~33 in. to 36 in.

Use the RS265TDBP owner's manual to confirm the exact numbers for your configuration.

Fit and hookup checks we recommend before you buy or move it

These quick checks prevent most “it won’t fit” surprises:

• Measure the opening width and height at the front and back of the space
• Plan for door swing clearance so drawers and shelves can pull out
• Leave airflow clearance behind and above the cabinet
• Confirm the water supply can provide 20 to 125 psi for the dispenser and ice maker
• Make sure the water line is not kinked or crushed during installation

Why it matters

Capacity tells you how much the RS265TDBP can store, but dimensions and clearances determine whether it will fit through doorways, sit flush in a cutout, and allow the doors to open fully. Getting the measurements right also helps avoid water line and ice maker performance issues.

If you need replacement parts while you measure or reinstall, you can order RS265TDBP parts from the list for this model, or search by model number on Sears PartsDirect.

Last updated: February 2026

For a Samsung RS265TDBP refrigerator, a “control panel not working” issue is usually caused by the control lock (child lock) being turned on or the panel needing a power reset. Start by unlocking the panel, then reset power; if it still will not respond, check for moisture and wiring issues.

Step 1: Make sure the control panel is not locked

On this model, the panel can be locked so the buttons and dispenser pad do not work.

• Press and hold Energy Saver for 3 seconds to toggle Child Lock/Lock off.
• Watch for the lock indicator to turn off.
• Try the dispenser and temperature buttons again.
• If condensation is present on the doors, turn Energy Saver off to reduce moisture.

Reference: See the lock and Energy Saver button behavior in the RS265TDBP owner's manual.

Step 2: Do a full power reset (recommended after unlocking)

If the panel is still unresponsive after unlocking, reset the electronics.

• Unplug the refrigerator (or switch the breaker off).
• Wait 5 minutes.
• Restore power.
• Allow the refrigerator a few hours to stabilize temperatures after power is restored.

If the panel still does not respond

At that point, the issue is typically moisture intrusion, a loose connection, or a failed component in the user interface circuit.

What to check safely

• Look for water or condensation around the dispenser and control area.
• Check that doors close fully and gaskets seal evenly.
• Listen for normal fan and compressor operation after power is restored.
• If you smell burning or see smoke, disconnect power immediately.

Common parts involved (when symptoms match)

Symptom you notice	Commonly related area	Example part from this model’s parts list
Panel works sometimes, temps seem off	Temperature sensing	Refrigerator temperature sensor (DA32-10109W)
Dispenser pad does nothing but lights are on	Dispenser switch/actuator	Refrigerator micro-switch (DA34-00011A)
Water dispenser weak or no water	Water supply control	Refrigerator water inlet valve (DA62-02291D)

You can order model-specific replacement parts from the parts list for RS265TDBP, or search by model number on Sears PartsDirect.

Why it matters

When the control panel is locked or not responding, you may not be able to adjust freezer/fridge temperatures, activate Power Cool/Power Freeze, or use the dispenser. Restoring control quickly helps prevent food temperature problems and reduces the chance of icing or condensation-related damage.

Last updated: February 2026

Cooling problems and ice maker or dispenser issues are the most common complaints we see with Samsung refrigerators, including the Samsung RS265TDBP. Many of these problems trace back to airflow restrictions, frost buildup at the evaporator, or water supply and filtration issues.

Most common issues (and what they look like)

• Not cooling or warm temperatures: food softening, freezer not holding 0°F
• Frost buildup and poor airflow: noisy fan, weak airflow from vents, uneven temps
• Ice maker not making ice: empty ice bin, slow production, clumping
• Water dispenser slow or not dispensing: weak stream, sputtering, no water
• Leaks or puddles: water under crisper drawers or on the floor

Quick checks we recommend first

1. Confirm settings: set freezer to 0°F and fresh food to 37°F.
2. Check door sealing: make sure doors close fully and gaskets are clean.
3. Look for blocked vents: do not pack items tightly against air outlets.
4. Verify water pressure: this model’s dispenser and ice maker need 20 to 125 psi to run correctly (low pressure causes slow fill and ice issues).
5. Replace the water filter on schedule: a restricted filter can reduce dispenser flow and affect ice production.

Parts that commonly relate to these symptoms

Symptom	Common area to inspect	Example part for RS265TDBP
Warm fridge/freezer, fan noise	Evaporator area, frost restriction	Refrigerator evaporator cover DA97-08724H
Frost buildup, not defrosting	Defrost system	Refrigerator defrost heater DA47-00322J
Slow or no water to dispenser/ice	Water supply and valve	Refrigerator water inlet valve DA62-02291D
Bad tasting water, slow dispensing	Filter restriction	Refrigerator water filter DA29-00019A

Why it matters

Cooling and ice maker problems often get worse over time. A simple airflow issue (blocked vents or frost buildup) can lead to temperature swings, food spoilage, and extra strain on the compressor.

Helpful DIY guidance

• Use the RS265TDBP manual for model-specific operating tips, temperature settings, and safety steps (including unplugging power before servicing).
• For ice maker troubleshooting steps that match common Samsung side-by-side designs, follow why your Samsung fridge stopped making ice and how to fix it.

You can order replacement parts for your Samsung RS265TDBP from the parts list for this model, or search by model number on Sears PartsDirect.

Last updated: February 2026

For the Samsung RS265TDBP side-by-side refrigerator, the exact purchase price depends on where and when it was sold; on our model page, we list current replacement-part pricing (for example, the refrigerator water filter DA29-00019A) rather than a single refrigerator purchase price. For operating details and features, use the owner's manual.

What we can price for this model (RS265TDBP)

We price the parts that keep your refrigerator running, such as water filtration, ice and water dispensing, and cooling-system components.

Commonly priced replacement parts include:

• Water filtration parts (filter replacements)
• Water supply parts (inlet valve)
• Cooling/defrost parts (defrost heater, sensors)
• Airflow parts (evaporator fan motor, fan blade)
• Door and dispenser parts (gasket, micro-switch)

Examples of parts and typical use cases

What you’re pricing	Example part for RS265TDBP	When you’d replace it
Water filter	DA29-00019A	Slow water flow, bad taste/odor, filter light reminder
Water inlet valve	DA62-02291D	No water to dispenser/ice maker, weak fill
Defrost heater	DA47-00322J	Frost buildup, warm fridge/freezer due to defrost failure
Temperature sensor	DA32-10109W	Temperature swings, incorrect readings

How to shop the right way (so you don’t buy the wrong item)

• Match the model number exactly: RS265TDBP
• Compare the part number on the old part to the listing (when accessible)
• Use the diagrams/parts list for your model to confirm fit
• For water and ice issues, confirm your home water pressure is in the typical operating range (many Samsung side-by-sides need about 20 to 125 psi for proper ice maker operation)
• Review maintenance steps and settings in the owner's manual

Why it matters

“265 L” is a capacity label used on some refrigerator lines, but your RS265TDBP is typically identified and serviced by its model number and configuration. Pricing parts by model number ensures you get components that fit your dispenser, evaporator system, and controls.

If you’re looking to purchase parts beyond the ones shown for RS265TDBP, we recommend searching by model number on Sears PartsDirect.

Last updated: February 2026
