Samsung RF28K9580SG/AA-00 refrigerator Parts

Samsung refrigerators that advertise “four types of ice” refer to certain newer models; your Samsung RF28K9580SG is designed to dispense two ice selections: cubed ice and crushed ice (crushed is made by crushing cubes at the dispenser). For operating details, use the RF28K9580SG manual.

Ice types you can select on RF28K9580SG

• Cubed: Ice maker produces cubes; dispenser delivers them as-is.
• Crushed: Dispenser crushes the cubes as they dispense.
• Same source ice: Both options start as cubes made in the ice maker.

If you are only getting one type (cube or crush)

• Switch the dispenser selection between Cubed and Crushed on the control panel.
• Empty the bin and break up clumps; fused cubes can prevent proper crushing.
• Reseat the ice bin fully; a mis-seated bin can cause poor dispensing.
• Confirm freezer temperature is set to 0°F for normal ice production.
• If ice production is slow or stopped, follow why your Samsung fridge stopped making ice and how to fix it.

What “four types of ice” usually means (and why it does not apply here)

Some Samsung product lines combine multiple ice makers or specialty ice shapes (for example, nugget-style or bite-size ice) with a crusher. The RF28K9580SG uses a cube ice maker and a crusher, so the user-facing choices are cube and crushed.

Feature	RF28K9580SG behavior	What you would see on “4 ice types” models
Ice maker output	Cubes	Multiple shapes (varies by model)
Dispenser options	Cubed or crushed	More than two selections

Why it matters

Knowing your RF28K9580SG only supports cubed and crushed keeps troubleshooting focused on the ice maker, bin, and dispenser crusher instead of looking for extra modes that are not part of this design.

Last updated: February 2026

On the Samsung RF28K9580SG, RD (refrigerator defrost) runs a forced defrost focused on the fresh food (refrigerator) evaporator area, while FD (full or forced defrost) runs a broader defrost that targets multiple sections so you can clear heavier ice buildup affecting cooling or ice production. For exact button sequences and display behavior, use the RF28K9580SG owner's manual.

When to use RD vs FD

Use the option that matches where the frost problem is showing up.

• Use RD when the refrigerator section is warm, airflow is weak in the fresh food compartment, or you hear fan noise from ice contact behind the rear panel.
• Use FD when the freezer side is impacted too, the ice room is icing up, the ice maker performance drops, or you suspect multiple evaporator areas are frosted over.
• If symptoms return quickly after a forced defrost, focus on airflow and fan operation checks.

What each mode typically defrosts

These modes are service-style defrost cycles; they are not the same as the refrigerator’s normal automatic defrost.

Mode	Primary target	Best for	What it won’t fix by itself
RD	Fresh food evaporator area	Fridge compartment frost and restricted airflow	Root causes like a failing fan, sensor issue, or door sealing problem
FD	Multiple sections (more complete defrost)	Heavy ice buildup affecting cooling and ice making	Ongoing moisture entry, airflow restrictions, or component failures

If forced defrost keeps coming back

Repeated icing usually points to an underlying issue that needs correction.

• Check door gaskets for gaps, tears, or poor sealing (warm air leaks create frost fast).
• Make sure vents are not blocked by food packages.
• Listen for evaporator fan operation; a stalled fan can lead to icing and warm temps.
• If temperatures swing or the unit misreads temps, a sensor can be involved; the refrigerator temperature sensor DA32-10104N is one common control input.
• If ice production is the main issue, use the why your Samsung fridge stopped making ice and how to fix it guide to narrow down causes.

Why it matters

Choosing RD vs FD saves time and helps you diagnose correctly: RD is a targeted way to restore refrigerator airflow, while FD is the better choice when ice buildup is widespread and impacting both cooling and the ice system.

Last updated: February 2026

The most common Samsung refrigerator complaint is ice maker trouble (no ice, small cubes, clumping, or ice buildup), followed closely by cooling problems caused by restricted airflow or fan/defrost issues. For your Samsung RF28K9580SG, start with the ice room and airflow checks in the RF28K9580SG owner's manual.

Most common issues we see (and what they look like)

• Ice maker stops or freezes up: ice clumps in the bin, frost in the ice room, dispenser struggles
• Fresh food section warm: food spoils faster, temperature swings, vents blocked by frost
• Freezer temperature problems: soft ice cream or heavy frost buildup
• Noisy operation: fan noise, rattling, or a loud hum during cooling cycles
• Water/ice dispensing issues: slow fill, hollow cubes, or no water at the dispenser

Quick checks that solve a lot of “common problems”

1. Confirm temperatures: set refrigerator to about 37°F and freezer to about 0°F.
2. Check airflow: keep packages away from interior vents; blocked vents mimic “not cooling.”
3. Inspect the ice bin and chute: dump clumped ice and look for frost that indicates warm air leaks.
4. Verify water supply: make sure the shutoff valve is fully open and the supply line is not kinked.
5. Listen for fans: if you do not hear normal fan airflow, a fan motor issue is likely.

Common causes and the parts that often relate

Symptom	Likely cause	Example part for this model
Ice clumping, weak dispensing	Ice bucket/auger area issue	Refrigerator auger motor assembly DA97-12540G
Warm fridge, poor airflow	Evaporator fan not moving air	Refrigerator evaporator fan motor DA31-00287B
Slow ice fill or no water	Water inlet not opening correctly	Refrigerator water inlet valve DA62-04027A
Temperature swings	Sensor reading incorrectly	Refrigerator temperature sensor DA32-10104N

Why it matters

Ice maker and cooling issues are often connected: frost or airflow restrictions can reduce ice production and raise compartment temperatures. Catching the cause early helps protect food quality and reduces strain on the sealed system.

Helpful DIY guidance

• Why your Samsung fridge stopped making ice and how to fix it

Last updated: February 2026

If your Samsung RF28K9580SG refrigerator sounds like it’s running but isn’t cooling, the most common causes are lost airflow (evaporator fan not moving air), frost blocking the evaporator, or poor heat removal at the condenser. Start with the checks in the RF28K9580SG manual.

Quick checks we recommend (10 to 20 minutes)

• Confirm temperature settings: fridge about 37°F, freezer 0°F.
• Make sure interior air vents are not blocked by food packages.
• Listen for the evaporator fan when the door switch is pressed; no fan sound points to an airflow failure.
• Check the rear inside panel for heavy frost; thick frost points to a defrost/airflow restriction.
• Pull the refrigerator forward and clean dust from the condenser area; verify the condenser fan is moving air.
• Confirm both doors close fully and gaskets seal all the way around.

What “running” usually means and what to do next

What you notice	Most likely area	Next step
Freezer cold, fridge warm	Airflow from freezer to fridge	Check for frost blockage; verify evaporator fan operation
Both sections warming	Condenser heat removal or sealed system	Clean condenser; confirm condenser fan runs; schedule service if still warm
Buzzing/clicking near compressor	Start/overload or compressor strain	Unplug 5 minutes, retry; if it repeats, have a technician test components

Parts that commonly relate to “runs but won’t cool”

• Refrigerator evaporator fan motor DA31-00287B (moves cold air through compartments)
• Refrigerator temperature sensor DA32-10104N (reports temperature to the control)
• Samsung refrigerator compressor NC1MV90ALPASH (circulates refrigerant in the sealed system)

Why it matters

Cooling depends on refrigeration plus airflow. If frost blocks the evaporator or a fan stops, the compressor can keep running while temperatures rise.

Helpful DIY guidance

Follow how to fix your evaporator cooling fan for airflow-related troubleshooting.

Last updated: February 2026
