Kenmore upright freezer model 2539244411 is a full-size upright, and its exact cubic-foot capacity is listed on the unit’s Energy Guide label (or rating label) rather than being encoded in the model number. Use the model tag plus the Energy Guide information to get the precise capacity.

Look for one of these on your Kenmore 2539244411:

• Energy Guide label (often on the side of the cabinet or included with paperwork)
• Model and serial tag inside the cabinet (side wall) plus a separate rating label
• Owner paperwork that came with the freezer

A parts-list item for this model that corresponds to the rated information is the energy guide 216367200.

Most full-size upright freezers in this Kenmore style fall into a common range; use this only for rough planning until you confirm the label.

• Typical full-size upright range: 16 to 21 cu. ft.
• Smaller uprights: 12 to 15 cu. ft.
• Extra-large uprights: 21+ cu. ft.

Cubic feet helps you compare storage space and plan organization. For parts, the model number is what ensures correct fit for interior items like glides and stops, regardless of the capacity.

Last updated: February 2026

On Kenmore upright freezer model 2539244411, a “sensor reset” is typically done by power-cycling the freezer to clear a false alarm or a control glitch. Unplug the freezer for 30 seconds, plug it back in, then confirm the door is fully closed and temperatures return to normal.

• Make sure the freezer door is fully closed and sealing.
• Press any alarm reset button (if your control panel has one).
• Unplug the freezer (or switch off the breaker) for 30 seconds.
• Restore power and wait 5 to 10 minutes for the control to stabilize.
• Check that food is staying frozen; allow 12 to 24 hours for full temperature recovery after any warm-up.

A repeating alarm usually points to a real condition, not a reset problem.

Common causes to check:

• Door not sealing (gasket not closing, door left ajar, bins holding it open)
• Heavy frost buildup restricting airflow
• Warm room conditions or frequent door openings
• Dirty condenser area or poor ventilation around the cabinet
• Cooling system or fan issue (you may hear unusual clicking, buzzing, or no fan sound)

These parts are commonly related to cooling performance or door-related symptoms on this model:

Resetting clears the control temporarily, but if the freezer is actually warming up, food safety and compressor run time become concerns. Confirming door seal and stable freezing temperatures prevents repeat alarms and protects the sealed system.

Last updated: February 2026

When a Kenmore upright freezer model 2539244411 stops freezing, the most common causes are poor airflow (dirty condenser area), a failed evaporator fan, a defrost system problem that packs the evaporator in frost, or a sealed-system/compressor issue. Start with the quick checks below before replacing parts.

• Confirm the temperature control is set colder and the door is closing fully.
• Check for heavy frost on the back interior panel; that points to a defrost problem.
• Listen for the evaporator fan inside the freezer; it should run when the compressor is running.
• Clean dust from the condenser area and make sure there is clearance around the cabinet for ventilation.
• Look for a door gasket leak (paper-strip test around the perimeter).
• If the compressor is hot and you hear repeated clicking, suspect a start-device or compressor problem.

These parts are not the only possibilities, but they are commonly related to “not freezing” complaints on upright freezers:

• Fan motor 5304442620 (moves air across the evaporator and through the cabinet)
• Freezer condenser coil 5300083897 (releases heat; must stay clean and unobstructed)
• Wire harness 216268200 (wiring issues can stop fans or controls from getting power)

A freezer can “run” but still not freeze if it cannot move heat out (condenser airflow problem) or cannot move cold air around (evaporator fan problem). Frost buildup from a defrost failure also blocks airflow and insulates the evaporator, so temperatures rise even though the compressor is working.

Last updated: February 2026

On a Kenmore upright freezer like model 2539244411, the model number is printed on a rating label inside the cabinet or on the exterior cabinet edge. Common spots include the inside side wall, the ceiling area, or behind the lower kick plate. Use our how to find your appliance model number (and what it means for parts) guide to match the label exactly.

• Inside the freezer on a side wall near the front opening
• On the inside ceiling (upper liner area)
• On the door frame or cabinet edge (open the door and look around the perimeter)
• Behind or just above the lower kick plate or toe grille
• On the back of the cabinet near the bottom

• Open the door and scan the upper interior first (ceiling and top side walls)
• Check the front cabinet frame around the opening (left and right edges)
• Remove the kick plate if your unit has one (usually snaps off or uses screws)
• Use a flashlight; labels are often small and low-contrast
• Write down the full model number exactly as shown (letters and numbers)

We use the model number to pull the correct Kenmore parts diagrams and compatible replacement parts for your upright freezer. Even one digit off can point to a different door style, thermostat setup, or wiring harness.
