Kenmore 25360502410 refrigerator Parts

The Kenmore top-mount refrigerator model 25360502410 is typically about 32 inches wide, 65-3/4 inches tall, and 26-5/8 inches deep (cabinet depth). For the most accurate fit, confirm the exact dimensions and required clearances in the 25360502410 use & care guide.

When you plan cabinetry or replacement, we recommend measuring more than just the cabinet box:

• Width: include door swing clearance if the unit sits next to a wall
• Height: include hinge area and any leveling adjustment
• Depth: include handles and space behind the unit for airflow
• Door clearance: enough room to fully open doors and remove bins
• Ventilation clearance: needed for proper air circulation

Your installation instructions call out minimum clearances for installation and airflow. Use these as your baseline when planning the space:

For leveling and door sealing, the cabinet should sit solidly on the floor and be adjusted so doors close properly; the 25360502410 installation guide walks through toe grille removal and front roller leveling.

Correct sizing prevents poor cooling, noisy operation, and door-seal leaks. Adequate rear and side clearance also protects airflow around the compressor and condenser area, which helps the refrigerator maintain safe food temperatures.

Last updated: January 2026

On the Kenmore 25360502410 top-mount refrigerator, the upper section is the freezer compartment. It’s the coldest area of the appliance and is designed to keep foods frozen; it also typically houses the ice maker on models equipped for ice production (see the 25360502410 owner's manual).

• Maintains temperatures cold enough to keep food frozen long-term
• Circulates cold air that also helps cool the fresh food section below
• Provides storage zones (door bins and interior shelves) for frozen items
• Often includes the ice maker area (if installed and turned on)

Knowing the correct compartment name helps when you’re adjusting temperature controls, troubleshooting cooling issues, or ordering the right parts for the correct section of the refrigerator.

• Leave space between packages so cold air can circulate.
• Avoid overloading the freezer with warm food all at once.
• Store temperature-sensitive frozen foods (like ice cream) in the interior, not the door.
• Keep the refrigerator level so doors close tightly and seal properly.

Last updated: January 2026

On the Kenmore 25360502410 top-mount refrigerator, replacing the water filter is a quick swap: open the filter access door, remove the old cartridge, install the new one fully seated, then run water to flush air and carbon fines. Use the steps in the 25360502410 owner's manual.

• Dispense a few cups of water first (if your model has a dispenser) to reduce pressure.
• Open the water filter access door (typically inside the fresh food compartment).
• Turn or pull the old filter out (depending on the cartridge style).
• Remove the protective caps from the new filter.
• Install the new filter and push or turn until it stops and feels fully seated.
• Close the access door.

If the access door is taped closed, remove tape carefully so you do not crack the liner or hinge area. If the door will not open without forcing it, use the 25360502410 installation guide to confirm the water supply is safely shut off and the refrigerator is unplugged before you work around the housing.

• Unplug the refrigerator before prying near plastic trim.
• Warm the tape with a hair dryer on low to soften adhesive.
• Use a plastic putty knife (not metal) to lift tape edges.
• If the door hinge is broken, replace the door or housing components rather than forcing it.

Most filter issues after a swap are just trapped air.

A properly seated, flushed filter helps protect water taste and flow, and it reduces the chance of air pockets that can cause sputtering at the dispenser or slow ice maker fill.

Last updated: January 2026
