Model #DLL2880DJL Hotpoint gas dryer

Here are the diagrams and repair parts for Hotpoint DLL2880DJL gas dryer, as well as links to manuals and error code tables, if available.


There are a couple of ways to find the part or diagram you need:

  • Click a diagram to see the parts shown on that diagram.
  • In the search box below, enter all or part of the part number or the part’s name.

Not all parts are shown on the diagrams—those parts are labeled NI, for “not illustrated”.

We encourage you to save the model to your profile, so it’s easy to access parts and manuals for your appliance whenever you log in.

For DIY troubleshooting advice and repair guides, visit our repair help section.

Save to my profile

Showing 10 of 194 parts

Dryer Control Knob Clip

#41

All parts Diagram

Dryer control knob clip

Part #WE1X980
This item is not returnable
$7.19

In Stock

Dryer Valve Coil

#729

All parts Diagram

Dryer valve coil

Part #WE4X692
$23.71

In Stock

Dryer Lint Screen

#300

All parts Diagram

Dryer lint screen

Part #WE18X26
$12.32

In Stock

Dryer Drum Front Glide Kit

#454

All parts Diagram

$31.47

In Stock

Dryer Air Duct Seal

#308

All parts Diagram

Dryer air duct seal

Part #WE9X38
$35.50

In Stock

Dryer Blower Wheel Retainer Assembly

#200

All parts Diagram

$9.44

In Stock

Dryer Main Valve Coil

#731

All parts Diagram

Dryer main valve coil

Part #WE4X693
$28.46

In Stock

Dryer Burner Igniter

#717

All parts Diagram

Dryer burner igniter

Part #WE4X444
$34.66

In Stock

Bearing Plate

#513

All parts Diagram

Bearing plate

Part #WE1X461
$30.38

In Stock

Term Housi

#556

All parts Diagram

Term housi

Part #WH12X497
$16.47

In Stock

Symptoms common to all dryers

Choose a symptom to see related dryer repairs.

Main causes: door switch failure, lack of power, broken belt, blown thermal fuse, bad drive motor, control system failure
Main causes: clogged exhaust system, heating system failure, deposits on moisture sensor, control system failure
Main causes: lack of electrical power, bad power cord, wiring failure, bad control board, blown thermal fuse, bad door switch
Main causes: bad drum support roller, damaged idler pulley, broken blower fan blade, worn drum glide bearing, bad drive motor
Main causes: bad gas valve coils, broken heating element, tripped safety thermostat or fuse, bad operating thermostat, control failure
Main causes: bad timer or electronic control board, door switch failure
Main causes: clogged exhaust vent, bad motor relay, loose dryer door catch, bad door switch, control system failure, faulty drive motor
Main causes: damaged door strike, worn door catch
