Electrolux EFDE317TIW2 dryer Parts

Most Electrolux dryers, including model EFDE317TIW2, typically last 10 to 15 years with normal household use. Consistent venting, cleaning, and avoiding overloads are the biggest factors that help you reach the high end of that range.

• Airflow and venting: A restricted vent makes the dryer run hotter and longer.
• Lint control: A clogged lint path strains the motor and can overheat thermostats.
• Load size: Overloading accelerates wear on the drum belt, rollers, and idler.
• Heat management: Repeated overheating can trip or weaken thermal limiters.
• Routine care: Simple cleaning and leveling reduce vibration and noise.

• Clean the lint screen every load.
• Inspect and clean the exhaust duct periodically; keep the run short and unobstructed.
• Keep the dryer level to reduce drum and cabinet stress.
• Do not dry items with hard objects attached (coins, screws, ornaments) that can damage the drum.
• Use cycles and dryness settings as described in the owner's manual.

If your EFDE317TIW2 starts squealing, thumping, or the drum stops turning, these are common wear items:

You can order these and other replacement parts from the parts list for EFDE317TIW2, or search by model on Sears PartsDirect.

A dryer that is forced to run hot or run long to dry clothes wears out drive components (belt, idler, rollers) faster and can also shorten the life of heat-safety parts such as thermostats and thermal limiters.

Last updated: February 2026

Your Electrolux EFDE317TIW2 dryer usually takes too long when airflow is restricted (lint filter, vent duct, or outside hood), the load and cycle settings do not match, or the home power supply is 208V instead of 240V (electric models). Start with venting and lint checks, then confirm cycle settings in the owner's manual.

• Clean the lint filter before every load.
• Check the outside exhaust hood for a stuck flap, lint buildup, or a bird screen blockage.
• Inspect the vent duct for kinks, crushing, or heavy lint; use 4-inch rigid or semi-rigid metal duct.
• Keep vent length within the limits shown in the installation guide.
• Avoid overloading; bulky items need room to tumble.
• Match the cycle to the load; Auto Dry times are estimates and can vary.

Your EFDE317TIW2 uses moisture sensing in Auto Dry cycles; small or nearly-dry loads can confuse the sensors and lead to odd results. If a load is not drying as expected, switch to a timed cycle and set a specific time.

If airflow is good and the dryer still runs long, common culprits are temperature control and drum drive components.

• If the dryer overheats or cycles heat oddly: consider the kelvinator dryer high-limit thermostat 3204267 or the dryer inlet thermal limiter 137032600.
• If the drum turns but squeals, thumps, or seems to slip: check the white-westinghouse dryer drum belt 134719300, dryer idler assembly 134793511, and drum rollers.

Long dry times waste energy, overheat the cabinet, and can shorten the life of wear parts like the drum belt and idler. Restoring proper airflow is the quickest way to get normal cycle times back.

You can order EFDE317TIW2 replacement parts from the parts list for this model, or search by model number on Sears PartsDirect.

Last updated: February 2026

To reset an error condition on your Electrolux EFDE317TIW2 dryer, we start by safely stopping the cycle, powering the dryer off, waiting briefly, then restoring power and restarting a cycle. If the code returns right away, the dryer is detecting an active problem that needs correction.

• Press Cancel to stop the current cycle.
• Turn the dryer Off.
• Wait about 30 seconds.
• Turn the dryer On.
• Close the door and press Start/Pause to run a cycle.

For model-specific control behavior and any reset sequence tied to your console, follow the steps in the owner's manual.

An error code that returns after a reset usually means the dryer is still seeing an overheating, airflow, or sensor issue.

• Clean the lint filter (your dryer reminds you with a CLEAN LINT message).
• Check the exhaust vent for restrictions (crushed hose, lint buildup, blocked exterior hood).
• Make sure the dryer door fully closes; the dryer will not run with the door open.
• If the dryer will not start, check the home breaker and power cord connection.
• If the dryer stopped mid-cycle and now will not run, an overheat safety device may have tripped.

If you are troubleshooting an overheating or no-heat condition on EFDE317TIW2, these parts are commonly involved:

Resetting clears the control state, but it does not fix the underlying cause. If airflow is restricted or a thermostat or thermal limiter is opening, the dryer can keep shutting down, dry poorly, or overheat until the root issue is corrected.

If you need to order replacement parts for EFDE317TIW2, use the parts list for this model or search by model number on Sears PartsDirect.

Last updated: February 2026
