Kenmore 79092403012 electric range Parts

The Kenmore electric range model 79092403012 is a standard 30-inch class range; the installation instructions call out a 30-inch minimum clearance above the cooking surface and show that the unit is designed for a typical 30-inch range opening. For exact overall dimensions and oven capacity, use the installation guide and owner's manual.

What “size” can mean (and what to check)

When customers ask for oven size, it usually refers to one of these:

• Overall range width (commonly 30 inches for this model class)
• Cutout and clearance requirements (critical for safe installation)
• Oven cavity capacity (measured in cubic feet)
• Interior rack dimensions (usable cooking space)

Model 79092403012 clearance and fit basics

From the installation guidance for this model, the key fit points to confirm are:

• 30-inch minimum clearance between the cooktop and the bottom of an unprotected cabinet
• 24-inch minimum if the cabinet bottom is properly protected
• 0-inch minimum rear clearance (while still following all listed dimension requirements)
• Range must sit level on its leveling legs
• Anti-tip bracket must be installed and verified

Quick reference: what to use for each measurement

What you need	Best source	Why it matters
Overall width/height/depth	Installation guide	Confirms the appliance fits your space and clearances
Oven capacity (cu ft)	Owner's manual	Helps compare cooking space between models
Rack positions and usable space	Owner's manual	Helps plan for large pans, roasts, and baking sheets

Why it matters

Using the correct dimensions and clearances prevents cabinet heat damage, reduces fire risk, and avoids a range that will not slide fully into place or sit securely (especially with the anti-tip bracket).

Last updated: February 2026

On Kenmore electric ranges like model 79092403012, the F90 code points to an oven door lock problem: the control is not sensing the door lock mechanism moving or unlocking correctly (often during or right after a self-clean cycle).

What you should do first

• Press Cancel/Off and allow the range to cool completely.
• If the code appeared after self-clean, wait 60 to 90 minutes for the lock to cool and release.
• Reset power: turn the breaker off for 1 minute, then back on.
• Try a normal Bake cycle to see if the code returns.
• If the door is locked, avoid forcing it; forcing can bend the latch or damage the lock motor.

Common causes (and the parts that usually fix it)

F90 is typically caused by one of these issues:

• Door lock motor not running or sticking
• Door lock switch not changing state
• Latch mechanism binding from heat or misalignment
• Wiring connection issue between the lock and control

If the problem repeats, the most common repair is replacing the lock assembly: range oven door lock motor and switch assembly 5304528973.

Quick symptom guide

What you notice	Most likely issue	What to check
F90 right after self-clean	Lock not cooling or releasing	Wait, then power reset
Door stays locked, won’t open	Lock motor/switch failure	Lock assembly, latch movement
F90 appears during Bake/Broil	Lock circuit fault	Wiring, lock switches
Intermittent F90	Binding latch or loose connection	Latch alignment, harness seating

Why it matters

When the control cannot confirm the door lock position, it may disable heating for safety. Fixing the lock issue restores normal baking and prevents getting stuck with a locked oven door.

For model-specific operation and self-clean guidance, follow the owner's manual for 79092403012.

Last updated: February 2026

A Kenmore 79092403012 electric range oven usually stops working because it is not getting full power, the oven temperature sensor is reading wrong, or a heating circuit component has failed (bake element, broil element, or control). Start by confirming power, then check heat and sensor-related symptoms using the owner's manual.

Most common causes (and what you typically notice)

• Power supply problem (tripped breaker, loose cord/terminal connection): display may be dead or oven will not heat at all.
• Failed bake element: broil may work but bake will not; uneven baking.
• Failed broil element: no broil heat; top browning is weak.
• Bad oven temperature sensor: temperature swings, underbakes, overbakes, or error codes.
• Control or wiring issue: intermittent heat, no response to keypad/knob settings.

Quick checks you can do first

1. Verify power at the home panel: this range needs a full 240V supply; a partially tripped double breaker can leave lights working but no heat.
2. Look for obvious heat failure: set Bake to 350°F and see if the bake element glows; then test Broil.
3. Check for error codes: if the display shows a code, use a Kenmore range error code reference such as Kenmore 790 self-cleaning range error codes.
4. Inspect the power connection area (with power off): the installation instructions warn not to loosen factory-installed terminal block nuts because it can cause electrical failure.

Parts that commonly fix “oven not working” on this model

Symptom	Likely part	Part to consider
Oven won’t reach temp or bakes erratically	Temperature sensing problem	Frigidaire range oven temperature sensor 316490000
No bake heat	Bake heating circuit failure	Frigidaire range bake element 316413800
No broil heat	Broil heating circuit failure	Frigidaire range broil element 316203301

Why it matters

When an electric oven loses heat, the root cause is often power delivery (breaker, terminal block connections) or a failed heating/sensing component. Fixing the correct part first prevents repeat failures and helps avoid overheating, poor baking results, and nuisance shutdowns.

Last updated: February 2026

To reset your Kenmore 79092403012 electric range oven, we recommend doing a full power reset: turn the range off, shut off power at the circuit breaker for 5 minutes, then restore power and set the clock. This clears many control glitches and false error codes.

Quick reset steps (power reset)

• Turn all surface elements and the oven off.
• Switch the range circuit breaker OFF (or remove the fuse).
• Wait 5 minutes.
• Switch the breaker ON.
• Re-set the clock and test Bake and Broil.
• If an error code returns immediately, use the troubleshooting steps below.

If the display shows an error code after resetting

A reset helps when the electronic oven control locks up, but repeated codes usually point to a failed sensor, wiring issue, or control problem.

• If the oven temperature seems wildly inaccurate or you get temperature-related codes, check the oven temperature sensor and its wiring; the model uses an electronic sensor circuit.
• If the oven will not heat in Bake or Broil, inspect the heating elements for visible damage.
• If the oven is stuck in a locked state after self-clean, the door lock system can be involved.

Helpful references for code meanings: Kenmore 790 self-cleaning range error codes.

Common parts that relate to “won’t heat” or error-code resets

Symptom after reset	Most common check	Example part for this model
Oven heats poorly or throws temp-related codes	Sensor circuit	Frigidaire range oven temperature sensor 316490000
No broil heat	Broil element	Frigidaire range broil element 316203301
No bake heat	Bake element	Frigidaire range bake element 316413800

Why it matters

A breaker reset restores clean power to the electronic oven control. If the control is seeing bad temperature feedback (sensor) or the oven cannot produce heat (element), the problem comes right back even after a reset.

For model-specific operating details (clock setting, lock features, and error displays), follow the owner's manual.

Last updated: February 2026

If a surface or oven element on your Kenmore 79092403012 electric range is not heating, the most common causes are a failed heating element, a bad control (surface infinite switch or oven control), or a wiring connection problem. Start with a visual check, then test for continuity with power disconnected.

Quick checks we recommend first

• Confirm the control is set correctly and the element is seated properly (if it is a plug-in style).
• Look for visible damage: blisters, cracks, burn spots, or a broken coil/loop.
• For cooktop radiant elements, check whether other elements work (helps narrow it to a single circuit).
• For the oven, test Bake and Broil separately to see if only one function fails.
• If the range was recently moved or installed, verify the power connection is correct per the installation guide.

Parts that commonly fix “element not working”

If the oven is not heating correctly, these model-compatible parts are common fixes:

Symptom	Most likely part	Example part on this model page
Oven will not heat or heats erratically	Oven temperature sensor	Frigidaire range oven temperature sensor 316490000
No broil heat	Broil element	Frigidaire range broil element 316203301
No bake heat	Bake element	Frigidaire range bake element 316413800
One small surface element will not heat	Surface element control switch	Frigidaire range small surface element control switch 316436000

Safe troubleshooting steps (power off)

1. Disconnect power at the breaker (240V). Confirm the cooktop and oven are off.
2. Remove the element (or access the terminals) and check continuity with a multimeter.
3. Inspect wiring terminals for loose, overheated, or burned connectors.
4. If the element tests good, test the related control (surface switch or oven circuit) and wiring.

Why it matters

A non-heating element is often a simple part failure, but loose or overheated wiring can damage terminals and create intermittent heating. Catching heat-damaged connectors early helps prevent repeat failures after you replace an element.

Last updated: February 2026
