Kenmore Elite 79671523210 dryer Parts

On the Kenmore Elite dryer model 79671523210, the model number is printed on the appliance’s rating label. You’ll usually find that label just inside the dryer door opening on the cabinet frame; on some installations it can also be on the back of the dryer near the top. See the 79671523210 owner's manual for the exact label location and what the full model and serial number look like.

• Open the dryer door and look around the door opening (cabinet frame) for a sticker or metal tag
• Check the inside edge of the door itself
• Look on the back panel near the top (especially if the door label is worn or missing)
• If the dryer is stacked, use a flashlight and check the door opening first (easiest access)

The rating label typically includes:

• Model number (for example: 796.71523210 or 79671523210)
• Serial number
• Electrical and fuel information (electric or gas)
• Manufacturing codes used for parts matching

The model number is how we match the correct Kenmore Elite dryer parts and diagrams. Even small model-number differences can change which drum belt, thermostat, or moisture sensor fits.

Last updated: January 2026

A hard reset for your Kenmore Elite dryer model 79671523210 is simple: unplug the dryer (or switch off the breaker) for about 1 to 5 minutes, then restore power and try a normal cycle. This clears many temporary control glitches, but it will not fix a heating or airflow problem.

• Turn the dryer OFF.
• Unplug the power cord (or turn the circuit breaker OFF).
• Wait 1 to 5 minutes.
• Restore power.
• Open and close the door once, then select a cycle and press Start.
• If the display shows an error again, write it down before resetting again.

A reset helps with a “stuck” control, but most repeat issues come from airflow restrictions, door switch problems, or drum drive wear.

• Clean the lint screen and confirm strong airflow at the outside vent hood
• Avoid crushed, kinked, or extra-long venting
• If the drum will not turn or you hear squealing, inspect the belt and idler system
• If the dryer stops mid-cycle, check for overheating symptoms (hot cabinet, burning smell)
• If the dryer will not start, confirm the door closes firmly and the latch engages

Resetting clears the control board’s temporary state, which can restore normal operation after a power flicker. If the same problem returns quickly, focusing on airflow, drum drive parts, or overheating protection saves time and helps prevent repeat shutdowns.

For model-specific button sequences, indicator meanings, and error code definitions, use the 79671523210 owner's manual.

Last updated: January 2026

For Kenmore Elite dryer model 79671523210, the load capacity is typically about 7.0 to 8.0 cubic feet, which fits most medium-to-large family loads. For the exact rated capacity for your specific unit, check the specifications section in the 79671523210 owner's manual.

Using the right load size helps your dryer heat and tumble correctly, which improves dry time and reduces wear on the drum belt and rollers.

• Fill the drum loosely; items should tumble freely
• Avoid packing heavy items (towels, jeans) tightly together
• Mix similar fabrics and weights in the same load
• For bulky items (comforters), dry one at a time when possible
• If clothes come out damp, reduce load size before changing parts

These examples match how most 7 to 8 cu. ft. dryers perform in real use.

Overloading commonly causes longer dry times, hotter operating temperatures, and extra strain on moving parts like the dryer drum belt 4400EL2001F and drum support system. Underloading can also reduce sensor-dry accuracy because items may not contact the moisture sensor consistently.

If loads that used to dry fine now take much longer, check these basics first:

• Clean the lint screen every load and confirm it seats correctly
• Make sure the exhaust vent is not crushed, kinked, or clogged
• Verify strong airflow at the outside vent hood
• If your model shows an error, use Kenmore elite dryer error codes to match the code to a fix path

Last updated: January 2026

CL on your Kenmore Elite dryer 79671523210 means Control Lock is turned on. The dryer can still power on, but the control panel is locked so most buttons will not respond until you unlock it using the steps in the 79671523210 owner's manual.

• Locks the control panel to prevent accidental setting changes
• Commonly shows CL on the display (sometimes alternating with time remaining)
• May allow Power to work while other keys are disabled
• Can prevent starting a cycle if Start is locked out

Use the exact Control Lock procedure listed for 79671523210 in the 79671523210 owner's manual. The correct steps depend on which button or key combination is labeled for Control Lock on your specific control panel.

If the panel is not responding while you try to unlock:

• Press the intended Control Lock key(s) firmly and hold for the full time stated in the manual
• Make sure the dryer is not in a paused state; press Power once, then try the unlock steps again
• Restore power (unplug or switch off the breaker for 1 minute), then retry the manual’s unlock steps

Control Lock is a normal feature; it is the most common reason a dryer has power but “won’t respond” to button presses.

For codes other than CL, use Kenmore elite dryer error codes to identify the issue and the next checks.

Last updated: January 2026
