Kenmore 10651119710 side-by-side refrigerator Parts

Most Kenmore side-by-side refrigerators are about 36 inches wide. For Kenmore model 10651119710, our 10651119710 owner's manual lists a 36 inch (91.44 cm) minimum cabinet cut-out width for installation, which is the practical width you should plan around.

What “width” means for fit and installation

When you’re measuring for a new spot, we recommend planning for more than just the cabinet opening.

• Cabinet opening (cut-out) width: the space between cabinets or walls
• Refrigerator case width: the appliance body (often close to 36 inches on this style)
• Door swing clearance: extra room so doors open fully
• Ventilation clearance: space around the refrigerator for airflow

Clearances to plan for (model 10651119710)

The manual’s location requirements call out these typical clearances:

• 1/2 inch on each side and at the top for ventilation
• 2 inches behind the refrigerator
• At least 2 inches on each side next to a fixed wall (varies by setup) so doors can swing open
• Extra space behind if you have an ice maker water line connected

Quick planning table

Measurement you need	What to use	Typical value for this model style
Minimum opening width	Cabinet cut-out width	36 in
Side clearance	Ventilation	1/2 in each side
Rear clearance	Ventilation and water line	2 in
Wall-side clearance	Door swing	2 in minimum

Why it matters

A refrigerator that “fits” by width can still be hard to use if the doors cannot open far enough to remove bins and crispers. Planning for door swing and ventilation helps prevent warm temperatures, noise, and premature wear.

Last updated: February 2026

To replace the water filter in your Kenmore side-by-side refrigerator model 10651119710, open the water filter cover door in the base grille, unlock and remove the old filter, then install the new filter and flush the water system to clear air and carbon fines. See the 10651119710 owner's manual for the exact filter style and orientation.

Step-by-step: replace the filter (base grille style)

• Pull open the water filter cover door in the base grille.
• Twist the filter 90° counterclockwise to unlock.
• Pull the filter straight out of the housing.
• Move the cap from the old filter to the new filter (align the arrows/grooves).
• Insert the new filter fully, then lock it in place (reverse the twist to secure).
• Close the filter cover door.

Flush the water system after replacement

Air in the line can cause sputtering or dripping right after a filter change. We recommend flushing the system using the dispenser:

• Hold the dispenser lever for 5 seconds, then release for 5 seconds.
• Repeat until water starts flowing smoothly.
• Continue the 5-on/5-off cycle until you dispense 3 gallons (12 liters) total.

What you see after a filter change	What it means	What to do
Water spurts or sputters	Air in the water line	Flush 3 gal. (12 L)
Dispenser drips	Air still clearing	Keep flushing; wipe spills
Door will not close easily	Filter not fully seated	Reinsert and lock filter, then close door firmly

Why it matters

A properly installed filter helps protect the water inlet valve and dispenser system from debris, and flushing prevents nuisance dripping and improves water flow and taste.

Related help

For choosing and swapping Kenmore filter types, use how to replace the water filter in a Kenmore refrigerator.

Last updated: February 2026

On Kenmore side-by-side refrigerator model 10651119710, the model number is printed on the model and serial tag inside the fresh food (refrigerator) compartment. Open the refrigerator door and look along the interior cabinet walls near the top or side areas; the tag is typically easy to spot once the door is fully open. For diagrams and exact locations, use the 10651119710 owner's manual.

Common places to check first

• Inside the fresh food compartment on a side wall (upper area)
• Inside the fresh food compartment near the ceiling liner
• Along the door frame area (cabinet face) when the door is open
• Behind or near crisper drawers (less common, but worth a quick look)
• Near the base grille area if you do not see it inside (some units place labels lower)

What you should write down

Record these exactly as shown on the tag so we can match parts correctly:

• Model number (example: 10651119710)
• Serial number
• Type or manufacturing code (if listed)

Quick ID checklist (helps avoid wrong parts)

Item on tag	Why it matters	Example format
Model number	Matches the correct parts breakdown	10651119710
Serial number	Helps confirm production run details	Letters and numbers
Color code (if shown)	Helps match door and trim colors	Often a suffix or code

Why it matters

Kenmore model numbers can look similar across 106-series refrigerators, but small differences change the correct parts (for example, an ice maker assembly, water inlet valve, or door gasket). Using the exact model number from the tag prevents ordering the wrong replacement.

Last updated: February 2026

For the Kenmore side-by-side refrigerator model 10651119710, we recommend keeping the fresh food section at 37°F and the freezer at 0°F for the best balance of food safety, ice production, and energy use. Use the control bars to fine-tune and wait 24 hours between changes (see the 10651119710 owner's manual).

Recommended settings and what they mean

Most Kenmore side-by-side refrigerators perform best at these targets:

Compartment	Target temperature	What you’ll notice when it’s right
Refrigerator	37°F	Milk stays cold, produce lasts longer
Freezer	0°F	Ice stays hard, frozen food stays solid

How to adjust temperatures on model 10651119710

This model uses a bar-style set point range from 1 bar (least cold) to 5 bars (coldest).

• Press REFRIGERATOR to view the current refrigerator set point
• Press REFRIGERATOR again to move 1 bar colder (cycles back after 5)
• Press FREEZER to view and adjust the freezer set point the same way
• Wait at least 24 hours between adjustments before changing again
• Keep items away from air vents so temperatures stay even

Quick troubleshooting if temperatures feel “off”

If the refrigerator is too warm or too cold, these checks fix most issues:

• Make sure doors close fully and the door seals are clean
• Reduce frequent door openings (warm air raises temps fast)
• Avoid blocking interior vents with large containers
• Let warm groceries cool the cabinet back down (give it several hours)
• If the top shelf seems colder, rearrange items (top can run slightly colder on some models)

Why it matters

37°F and 0°F help prevent food spoilage while keeping the compressor from running excessively. Small control changes and good airflow usually correct temperature complaints without replacing parts.

Last updated: February 2026

Your Kenmore side-by-side refrigerator model 10651119710 has a total capacity of about 21.9 cubic feet. This is the combined storage volume of the fresh food and freezer compartments, and it helps you compare usable space across similar 36-inch side-by-side models.

How to confirm capacity for your exact configuration

We recommend checking the capacity listing in the product specifications section of the 10651119710 owner's manual. Model families can share a manual, and capacity can vary slightly by configuration.

• Look for “Capacity”, “Total volume”, or “Total capacity”
• Verify you are in the 106.5111* model section
• Compare total, refrigerator, and freezer volumes (if listed separately)
• Use the manual specs when comparing to a replacement refrigerator

Why cubic feet matters

Capacity is the quickest way to estimate how much food your refrigerator can hold, but it also affects:

• Shelf and bin layout expectations
• How full the freezer can be without blocking airflow
• Shopping for replacement units that fit your household needs
• Energy use comparisons between similar models

Typical capacity range for this style

Most 36-inch side-by-side refrigerators fall into a fairly tight range. Here is a quick comparison:

Refrigerator type	Typical total capacity
Side-by-side (36-inch class)	20 to 23 cu. ft.
Large side-by-side	23 to 26 cu. ft.

Your 21.9 cu. ft. capacity sits in the common range for a full-size Kenmore side-by-side.

Related specs you may want next

If you are planning a replacement or measuring your space, these manual specs are often just as important as cubic feet:

• Cabinet cutout width (many are 36 inches)
• Required ventilation clearances (side, top, and rear)
• Door swing clearance next to a wall
• Water supply requirements if you use the ice maker and dispenser

Last updated: February 2026

Kenmore model numbers tell us the appliance’s product family and who manufactured it; for Kenmore refrigerator model 10651119710, the 106 prefix identifies the manufacturer family, and the remaining digits narrow down the exact design so we can match the correct parts and service information. For model-specific details, use the 10651119710 owner's manual.

Where to find the model number on a Kenmore refrigerator

We use the full model number (not just the first 3 digits) to ensure parts like an ice maker, water inlet valve, or door gasket fit correctly.

• Check the inside walls of the fresh food compartment (often near the crisper drawers)
• Check the door frame area when the refrigerator door is open
• Check the back exterior panel near the power cord
• Write down the full model number and the serial number (helpful for date and revision)

How to interpret a Kenmore model number (quick breakdown)

Kenmore model numbers are typically structured as a prefix + core model + variation digits.

Section	Example from 10651119710	What it does	Why we use it
Manufacturer prefix	106	Identifies the manufacturing source family	Helps narrow parts system and design platform
Core/series digits	511197	Identifies the model series and feature set	Matches assemblies like controls, fans, and bins
Variation digits	10	Identifies version, color, or engineering change	Prevents ordering a “close but not correct” part

Why it matters when ordering parts

Using the complete model number prevents common fit and compatibility problems.

• Ensures the correct electrical and mounting style for an ice maker
• Helps match water system parts (valves, tubing, filter housings)
• Prevents door and shelf parts from being the wrong size
• Improves troubleshooting accuracy when symptoms involve cooling or dispensing

Example: parts that depend on the exact model

Even within the Kenmore 106 family, parts can vary by revision.

• Refrigerator water inlet valve WPW10179146 controls water flow to the dispenser and ice maker
• Refrigerator ice maker assembly WPW10300022 must match the wiring and mounting pattern
• Gasket, door (beige) 2159075 must match the door size and seal profile

Last updated: February 2026

Most Kenmore refrigerators last 10 to 15 years on average. For a Kenmore side-by-side like model 10651119710, lifespan depends most on basic care (airflow, clean coils, good door seals) and fixing cooling or ice-maker issues early; see the 10651119710 owner's manual for model-specific care and operating guidance.

Typical lifespan and what changes it

A refrigerator’s life is mainly driven by compressor run time, heat removal, and how well the doors seal.

• 10 to 15 years is the typical range for most household refrigerators
• 15 to 20 years is common when coils are kept clean and temperatures stay stable
• Heavy use (frequent door openings, warm garage installs) shortens life
• Poor airflow around the cabinet increases compressor wear
• Water and ice system leaks can cause corrosion and repeated service issues

Maintenance that adds years (high impact)

Use these as a simple yearly checklist.

• Vacuum and brush condenser coils and the grille area
• Keep door gaskets clean; confirm the door closes firmly
• Set temps to typical targets: 37°F fresh food, 0°F freezer
• Replace the water filter on schedule; flush air after changes
• Keep vents inside the compartments unblocked

Quick “symptom to action” table

What you notice	What it usually means	What to do first
Fridge warm, freezer OK	Airflow problem (fan/vents/ice buildup)	Check vents, listen for fan, inspect for frost
Freezer warm, fridge warm	Sealed system or compressor run issue	Clean coils, verify airflow, then diagnose cooling
Ice maker slow or no ice	Water supply or ice maker fault	Check water supply, then test the ice maker
Water dispenser weak	Filter restriction or valve issue	Replace filter, then check inlet valve

Parts that commonly affect longevity on this model

When these parts fail, the refrigerator often runs longer and hotter, which shortens overall life.

• Refrigerator water inlet valve WPW10179146: controls water flow to the dispenser and ice maker
• Refrigerator ice maker assembly WPW10300022: failed harvest or fill can mimic water supply problems
• Refrigerator evaporator fan motor WP2315549: poor airflow can cause warm temps and frost buildup

Why it matters

A refrigerator that runs warm or has restricted airflow forces the compressor to run longer. That extra heat and run time is the main reason otherwise good Kenmore units wear out early.

Last updated: February 2026
