Kenmore 10658149801 side-by-side refrigerator Parts

Kenmore model 10658149801 was manufactured for Kenmore by Whirlpool. The 106 prefix is the key identifier; it’s the Kenmore source code commonly used to tie this refrigerator to Whirlpool production.

We recommend verifying the model and serial information on the rating label, then matching the full model number.

• Look for the rating label inside the fresh food compartment (often on a side wall) or near the door frame
• Confirm the model reads 10658149801 (all digits matter)
• Note the serial number as well; it helps when ordering parts like a water filter or ice maker
• Use the parts diagram and service info in the 10658149801 owner's manual

Kenmore is a brand name; the actual manufacturer determines the engineering platform and which replacement parts fit correctly (water filter style, ice maker design, control components).

For water and ice performance, the correct filter type is critical. This model’s manual lists a base grille water filter replacement as part #9030; on our parts list you’ll typically see that as the genuine Kenmore refrigerator water filter EDR3RXD1.

Using the correct manufacturer platform (Whirlpool-built Kenmore 106) helps prevent ordering the wrong filter, ice maker, or control part, which saves time and avoids fit issues.

Last updated: February 2026

On Kenmore model 10658149801, the model number is printed on the appliance identification label (the same label that lists the serial number). We use that label information to match the correct parts, diagrams, and troubleshooting steps in the 10658149801 owner's manual.

Look for a paper or foil label in one of these spots:

• Inside the fresh food compartment on a side wall (often near the top front)
• On the ceiling of the fresh food compartment near the light housing
• Behind the crisper drawers (you may need to slide drawers out)
• Along the door frame area that’s visible when the refrigerator door is open
• On the back exterior panel (less common, but possible)

Record both the model and serial number exactly as shown. The serial number format can vary, but it is typically a mix of letters and numbers.

• Wipe the label gently with a damp cloth and dry it; grease and dust can hide characters.
• Use your phone camera and zoom in; angled light helps make faint print visible.
• Copy the number exactly; don’t drop leading zeros or swap similar characters (like O and 0).

Kenmore side-by-side refrigerators can look similar across multiple model families. Using the exact model number (like 10658149801) prevents ordering the wrong water filter, ice maker, door parts, or temperature control.

Last updated: February 2026

Most Kenmore refrigerators average 10 to 15 years of service life. For a Kenmore side-by-side like model 10658149801, regular care (cleaning, good airflow, and fixing small issues early) is what most often determines whether it lands closer to 10 years or pushes beyond that range.

• 10 to 15 years: common for many household refrigerators
• 15 to 20 years: achievable with consistent maintenance and timely repairs
• Under 10 years: usually tied to heavy use, poor ventilation, dirty condenser coils, or unresolved cooling/ice maker issues

We recommend focusing on the items below because they directly reduce compressor run time and prevent temperature swings.

• Clean condenser coils and keep airflow clear around the cabinet
• Keep door gaskets clean so the doors seal tightly
• Set stable temperatures (avoid frequent adjustments)
• Replace the water filter on schedule to protect water flow and ice maker performance
• Level the refrigerator so doors close fully and consistently
• Address unusual noises, warming, or frost buildup quickly

For model-specific care and cleaning guidance, follow the 10658149801 owner's manual.

A refrigerator that runs longer than necessary (from restricted airflow, a leaking door seal, or a clogged filter) puts extra wear on the sealed system (compressor, evaporator, condenser). That extra run time is one of the biggest drivers of early failure.

These are examples of parts on this model that can influence performance when worn or restricted:

• Refrigerator water filter EDR3RXD1 (helps maintain dispenser and ice maker water flow)
• Door gaskets (reduce warm air leaks and frost)
• Evaporator fan components (support steady cooling)

Last updated: February 2026

The most common issues we see on Kenmore refrigerators like model 10658149801 are cooling problems, water and ice dispenser or ice maker failures, leaks, and unusual noises. Many of these trace back to airflow restrictions, temperature control settings, or worn water-system and fan components; start with the basics in the 10658149801 owner's manual.

• Not cooling or warm temperatures: blocked vents, dirty condenser coils, evaporator fan issues, or defrost problems
• Freezer too warm or not making enough ice: freezer temperature set too warm, airflow blocked, ice maker or water supply issue
• Water leaking or puddles: clogged/iced drain path, loose water line connections, or inlet valve seepage
• Ice maker not working: water supply off, frozen fill tube, failed ice maker module
• Noisy operation: normal valve buzz during ice maker fill, fan/compressor speed changes, or items vibrating on the cabinet

1. Confirm controls are on and set near the factory mid-settings; then wait 24 hours after any adjustment.
2. Do not block airflow vents in either compartment; blocked vents cause temperature and moisture problems.
3. Listen to the noise type: buzzing during ice maker fill and pulsating from fans/compressor can be normal.
4. Check door closing and sealing; poor sealing causes long run times and temperature swings.
5. Verify water supply is on and the line is not kinked if you have dispenser or ice issues.

Most “big” refrigerator complaints start with small causes: blocked vents, incorrect temperature settings, or restricted water flow. Fixing those early helps protect food temperatures, improves ice production, and reduces compressor run time.

Last updated: February 2026

For Kenmore model 10658149801, the most accurate way to get cubic feet is to look up the capacity in the specifications section of the 10658149801 owner's manual. Model numbers help narrow the family, but the manual and the rating plate confirm the exact capacity for your specific build.

• Check the rating plate inside the fresh food compartment (often on a side wall or ceiling area); it typically lists model/serial and may list capacity.
• Use the specifications section in the manual for model 10658149801.
• Measure and estimate if the label is missing (useful for planning shelves or moving).
• Compare to typical side-by-side sizes to sanity-check your estimate.

If you cannot access the rating plate, you can estimate interior volume:

1. Measure interior width x interior height x interior depth (in inches) for the refrigerator section.
2. Do the same for the freezer section.
3. Add the two volumes and divide by 1,728 (cubic inches per cubic foot).

Most Kenmore side-by-side refrigerators are approximately:

• 20 to 26 cu. ft. total capacity
• 36-inch cabinet cutout width is common for installation planning (your manual also calls out a 36-inch minimum cutout width).

Cubic feet affects how much food you can store, but it also impacts fit and airflow requirements. Using the manual specs helps you match the right shelves, bins, and accessories and plan installation clearances correctly.

Last updated: February 2026

For Kenmore model 10658149801, the fastest way to track down discontinued parts is to start with the exact model and part number from the 10658149801 owner's manual, then search for OEM substitutions, compatible replacements, or good used parts from reputable sources.

• Confirm the full model number and serial number from the rating label; this prevents ordering a similar-looking but wrong part.
• Look up the original part number in the parts list and diagrams in the 10658149801 owner's manual.
• Search for a manufacturer substitution (many discontinued parts are replaced by a newer part number that fits).
• Check for compatible assemblies (sometimes a small discontinued piece is only sold as part of a larger assembly).
• Use reputable used-part sources (appliance recyclers, refurbishers, and local repair shops with “new old stock”).
• Compare photos and key specs (mounting points, electrical connectors, dimensions) before buying.

These are often the hardest to find for side-by-side refrigerators like the Kenmore 10658149801:

• Door trim, handles, and color-specific panels
• Shelves, bins, and drawer components
• Dispenser bezels and small plastic clips
• Wiring harnesses and specialty brackets

Using the exact model number and the original part number helps you avoid “almost fits” parts that cause leaks, noise, poor cooling, or repeat failures. It also makes it easier to identify safe, direct-fit substitutions.
