Kenmore 11022912100 washer Parts

To unclog the drain hose on your Kenmore washer model 11022912100, unplug the washer, remove as much water as possible, then check for kinks and clear blockages in the drain hose and pump area. Reinstall the hose exactly as shown in the owner's manual.

Safety first and quick prep

• Unplug the power cord before touching the pump or hoses.
• Turn off both water faucets.
• Protect the floor with towels or a shallow pan.
• Expect water to spill when you loosen hose clamps.
• If the tub is full, bail water out or use a wet/dry vac on the standpipe end of the drain hose.

Step-by-step: unclog the drain hose

1. Check the easy stuff first: pull the washer out slightly and straighten any kinks or crushed sections of the drain hose.
2. Verify the standpipe or sink drain is not clogged: a slow household drain can look like a washer problem.
3. Access the pump and hoses: remove the cabinet or service access as outlined in the owner's manual.
4. Inspect the pump inlet hose (tub to pump): this is where socks, coins, and lint clumps often lodge.
5. Clear the pump: remove debris from the pump housing and make sure the impeller turns freely.
6. Flush the drain hose: run water through it (outside or into a bucket) until it flows strongly.
7. Reassemble and test: run a drain/spin and watch for leaks.

Parts that commonly solve “won’t drain” on this model

If the hose is clear but draining is still weak or noisy, the drain pump is a common fix.

Symptom	Most likely area	What to check next
Hums but won’t drain	Pump jammed or failing	Debris in pump, impeller movement; consider washer drain pump WP3363394
Drains slowly	Partial clog or restricted hose	Hose routing, standpipe flow, pump inlet hose
Leaks during drain	Hose connection/clamp issue	Proper clamp position and secure routing per manual

Why correct drain hose setup matters

On model 11022912100, the manual calls out that the drain hose must be installed and secured correctly to prevent leaks and the hose coming off. A loose or poorly routed hose can also kink and cause “won’t drain/wet loads” symptoms.

Ordering the right replacement part

We list model-matched replacement parts for 11022912100 on this page; you can also search by model number on Sears PartsDirect if you are building a larger repair list.

Last updated: February 2026

To reset your Kenmore 11022912100 washer, we power-cycle it: stop the cycle, unplug the washer for about 1 minute, then plug it back in and restart the cycle. This clears many temporary control or cycle interruptions.

Quick reset steps (power reset)

• Push the cycle selector (timer) knob in to stop the washer.
• Turn the cycle selector to OFF.
• Unplug the washer (or switch the breaker off).
• Wait 60 seconds.
• Restore power.
• Select a cycle and pull the timer knob out to start.

If the washer stopped mid-cycle: restart correctly

The timer-style control on model 11022912100 is designed for stop and restart using the knob.

• Stop: push the cycle selector (timer) knob in.
• Restart: pull the knob out.
• If you need to change settings after agitation starts, use the control’s RESET position (for example, raising the water level on some versions). See the 11022912100 owner's manual for the exact control behavior on your console.

What a “reset” fixes (and what it doesn’t)

A reset helps when the washer is stuck, won’t advance, or you need to clear a paused cycle. If the same symptom keeps coming back, it usually points to a mechanical or water/drain issue.

Symptom after reset	Most common cause	What to check next
Won’t drain or won’t spin	Drain restriction or oversudsing	Drain hose height/kinks, reduce detergent
Stops and restarts randomly	Lid not fully closed	Close lid firmly, avoid overloading
Agitates poorly	Worn agitator drive parts	Inspect agitator dogs

Why it matters

Resetting gets you running again quickly, but repeated “needs a reset” behavior often means the washer is struggling to drain, spin, or agitate. Catching that early helps prevent wet loads and extra wear on the drive system.

Parts that commonly relate to repeat problems

If agitation is weak or intermittent, these model-matched parts are common fixes:

• Agitator dog 80040 (agitator “cams” that help the top portion grab and turn)
• Coupling 285753A (connects motor to transmission on many Kenmore direct-drive designs)

You can order replacement parts for Kenmore 11022912100 from the parts list for this model, or search by model number on Sears PartsDirect.

Last updated: February 2026

Kenmore washer model numbers (including 11022912100) are read left to right: the first 3 digits identify the manufacturer, the next group identifies the base design, and the final digits show the exact version and feature variations. Confirm the full number on the model and serial plate and in the owner's manual.

What each section of a Kenmore model number means

Most Kenmore model numbers follow this pattern:

• Prefix (first 3 digits): manufacturer code (who built it for Kenmore)
• Middle digits: base platform or series (the core design)
• Ending digits: specific configuration (color, controls, revisions, feature package)

For 11022912100:

Section	Digits	What it tells you	Why you use it
Manufacturer prefix	110	Who built the washer	Helps match the correct style of parts and diagrams
Base model	22912	Core design family	Narrows parts to the right platform
Version/suffix	100	Exact variation	Prevents ordering a similar looking but wrong part

Where to find the model number on the washer

We use the complete model number to match parts like a washer inlet valve, drain pump, or timer to your exact Kenmore washer.

Check these common locations:

• Model and serial number plate (often under the lid or on the lid opening)
• Your purchase receipt or paperwork
• The identification section in the owner's manual

Why it matters for ordering parts

A single digit difference can change the correct replacement part. For example, drive system parts such as the coupling 285753A or water-handling parts such as the washer drain pump WP3363394 must match the exact model variation to fit and work correctly.

Quick tips to avoid model-number mistakes

• Write the model number exactly as shown, including all digits
• Use the full number, not just the first 3 to 5 digits
• If the plate is worn, compare the number you find with the manual record section
• When shopping, match by model number first, then confirm the part name and part ID

You can order replacement parts for Kenmore 11022912100 from the parts list for this model, or search by model number on Sears PartsDirect.

Last updated: February 2026

A Kenmore washer typically lasts 10 to 15 years with normal household use and basic maintenance. Many classic Kenmore top-load designs like model 11022912100 can run longer when loads are balanced, water hoses are kept in good shape, and worn drive parts are replaced promptly (see the owner's manual).

Typical lifespan ranges (what we see most often)

• Standard top-load washer (direct-drive style): 10 to 15 years
• Heavier use (large family, daily loads): closer to 8 to 12 years
• Light use (few loads per week): 12 to 18 years
• Well-maintained older Kenmore top-loaders: 15 to 20 years is common

What shortens washer life fastest

• Overloading or consistently washing heavy items (comforters, rugs)
• Running with an unbalanced load that bangs or walks
• Letting small leaks continue (they damage bearings, clutch, and gearcase)
• Ignoring early symptoms like poor agitation or weak spin
• Using too much detergent (can contribute to residue and odors)

Parts that commonly extend the life of model 11022912100

If the washer still fills and drains but performance is slipping, these are frequent “keep it going” repairs:

• Agitator dog 80040 (worn dogs cause weak or no agitation)
• Coupling 285753A (broken coupling can stop agitation and spin)
• Washer drain pump WP3363394 (draining issues, leaks, or noisy pump)
• Clutch 285785 (slow or weak spin, burning smell)

Quick symptom-to-part guide

Symptom	Most likely area	Common part on this model
Agitator moves poorly	Agitator drive	Agitator dog
Won’t agitate or spin	Drive connection	Coupling
Won’t drain / leaks at pump	Drain system	Washer drain pump
Spins weak / clothes too wet	Spin drive	Clutch

Why it matters

Knowing the expected lifespan helps you decide whether a repair is a smart investment. On a durable Kenmore top-load washer like 11022912100, replacing a wear item (coupling, pump, clutch) often restores reliable washing for years, especially when the tub and gearcase are still in good condition.
