Kenmore 59666133703 refrigerator Parts

To tell what model Kenmore refrigerator you have, we look for the model/serial tag on the cabinet (not on removable drawers). On Kenmore model 59666133703, the tag is typically inside the fresh food section on a side wall or ceiling, or it may be behind the lower kick plate.

Check these common spots first:

• Inside the refrigerator compartment on the left or right side wall
• On the ceiling of the fresh food compartment
• Behind or beside the crisper drawers (on the cabinet wall, not the drawer)
• Behind the toe grille or kick plate at the bottom front
• On the back exterior panel near the power cord area

For this parts page, the model number format you want is the full Kenmore number:

We use the complete model number to match the correct version of parts like a control board, door gasket, or evaporator fan motor. Even small model-number differences can change wiring, mounting holes, or connector styles.

Try these quick fixes:

• Take a photo with your phone and zoom in
• Wipe the label gently with a damp cloth, then dry it
• Look for a second tag behind the kick plate if the inside label is worn
• Write down both the model and serial number before ordering

After you confirm the model number, you can order from the parts list for your refrigerator, or search by model on Sears PartsDirect. If you are troubleshooting cooling or fan noise issues, common related parts on this model include the refrigerator evaporator fan motor WPW10128551 and refrigerator electronic control board WPW10503278.

Last updated: February 2026

Most Kenmore Elite refrigerators last 10 to 15 years with normal household use and basic maintenance. For a Kenmore bottom-mount refrigerator like model 59666133703, keeping airflow clear, doors sealing tightly, and the cooling system running efficiently is what most directly affects service life.

A refrigerator’s lifespan is usually limited by wear on the sealed system, compressor start components, and control electronics.

• Typical range: 10 to 15 years
• Common “still running” range with good care: 15+ years
• Most frequent age-related issues: cooling fan noise, frost buildup, warm temps, door seal leaks

These steps reduce compressor run time and prevent temperature swings.

• Vacuum condenser area and keep rear/bottom airflow open
• Keep freezer vents and return air paths unblocked
• Confirm doors close fully; avoid overloading door bins
• Set temps to about 37°F fresh food and 0°F freezer
• Address unusual noises early (fan blade rubbing, ice buildup)

If your 59666133703 is warming, noisy, or frosting up, these model-compatible parts are commonly involved:

Once a refrigerator gets past the 10-year mark, small efficiency problems (dirty condenser area, weak door seal, failing fan) can force longer run times. That extra strain accelerates wear on the compressor and electronics, shortening overall lifespan.

We recommend matching parts to the full model number 59666133703 and symptom. You can order model-specific replacement parts from the parts list for this refrigerator, or search by model number on Sears PartsDirect.

Last updated: February 2026

The most common problems we see on Kenmore refrigerators like model 59666133703 are cooling issues, ice maker and water dispenser troubles, leaks, frost buildup, and unusual noises. Many are caused by airflow restrictions, dirty condenser coils, door seal gaps, or a failing fan or defrost component.

• Not cooling or warm fridge section: blocked vents, dirty condenser coils, or a weak evaporator fan
• Freezer cold but fridge warm: poor airflow from the freezer to fresh food section, often tied to the evaporator fan or frost buildup
• Water leaking inside or onto the floor: clogged/iced defrost drain, cracked drain pan, or water line/valve issues
• Excessive frost on the back wall of the freezer: defrost system problem (heater, thermostat, control)
• Noisy operation (buzzing, rattling, clicking): fan blade hitting ice, failing fan motor, or start components cycling

1. Confirm temperatures: set freezer near 0°F and refrigerator near 37°F.
2. Check airflow: make sure packages are not blocking return vents.
3. Clean condenser coils: dust buildup can cause poor cooling and long run times.
4. Inspect door seals: look for gaps, tears, or doors not closing squarely.
5. Listen for the evaporator fan: it should run when the compressor is running (door switch may need to be pressed).

Cooling, frost, and leak symptoms often cascade. For example, a weak evaporator fan can cause warm temperatures, which increases run time and can lead to frost and water issues. Catching airflow and seal problems early helps protect the compressor and keeps food safe.

For display or diagnostic codes on Kenmore units, we use the troubleshooting steps in Kenmore 111 model bottom freezer refrigerator error codes to narrow down likely causes.

You can order replacement parts for Kenmore 59666133703 from the parts list for this model, or search by model number on Sears PartsDirect.
