Whirlpool WTW5105HW0 washer Parts

For a Whirlpool washer like model WTW5105HW0, most repairs typically land in the $150 to $400 range (parts plus labor). Small fixes such as a belt or lid-lock issue often cost less than major drive-system or electrical repairs, so the final total depends on the failure and service rates.

Typical repair cost ranges (parts + labor)

Here are common Whirlpool top-load washer repairs and what we typically see customers pay.

• Basic service call/diagnostic: often $75 to $150
• Minor mechanical repair (belt, strike, hose): often $150 to $250
• Drain or fill problem repair (pump/valve related): often $200 to $350
• Drive system repair (motor, pulley, actuator): often $250 to $450
• Electrical repair (wiring, capacitor, controls): often $250 to $500

Repair type	Common symptoms	Cost tendency
Fill-related	Won’t fill, fills slowly, hot/cold issues	Lower to mid
Drain-related	Won’t drain, stops mid-cycle	Mid
Spin/agitate-related	Won’t spin, grinding, weak agitation	Mid to higher
Lid lock-related	Won’t start, lid won’t lock/unlock	Lower to mid

Parts on WTW5105HW0 that often affect repair price

If your technician diagnoses one of these, the part cost can shift the total noticeably.

• Drive belt W11239857 (spin issues, squealing, burning rubber smell)
• Lid lock-sol W11700916 (won’t start, lid lock errors)
• Washer water inlet valve W11165546 (no fill, slow fill, wrong temperature)
• Pump asm, dr W11396717 (won’t drain, standing water)
• Drive motor W11026785 (no spin/agitate, humming)

When repair is worth it (simple rule)

Repair is the better value when the washer is otherwise in good shape and the repair cost is less than about half the price of a comparable new washer.

Why it matters

A correct diagnosis prevents repeat service calls and unnecessary parts. Using the care and maintenance guidance in the WTW5105HW0 owner's manual also helps avoid preventable failures (for example, replacing inlet hoses on schedule and checking for leaks).

Last updated: February 2026

The most common Whirlpool washer problem is a no-drain or no-spin condition, which is often caused by a lid lock issue, a drain/pump restriction, or a drive system problem. On the Whirlpool WTW5105HW0, we start by checking load balance, then the lid lock, then draining and drive components using the WTW5105HW0 owner's manual.

Most common symptoms and what they usually point to

• Washer will not drain: kinked/blocked drain hose, clogged pump path, or a failing drain pump
• Washer will not spin: lid lock not engaging, unbalanced load, or drive belt/pulley wear
• Loud noise during spin: worn belt, pulley damage, or something rubbing the tub/basket
• Won’t start or stops mid-cycle: lid lock not sensing closed, or an electrical/control interruption

Quick checks we recommend first (fast, no parts)

1. Redistribute the load (bulky items can trigger out-of-balance behavior and prevent a full spin).
2. Confirm the lid closes firmly and the strike is not loose or cracked.
3. Check the drain hose routing: no kinks, not crushed behind the washer, and seated correctly in the standpipe.
4. Run a cleaning cycle periodically; the manual notes the Clean Washer cycle and leaving the lid open afterward for drying and odor prevention.

Parts that commonly fix no-spin/no-drain on WTW5105HW0

If the basic checks do not resolve it, these model-matched parts are frequent culprits:

Symptom	Common part to inspect	What it does
Won’t spin, lid error behavior	Lid lock-sol W11700916	Locks and confirms lid status so the washer can spin safely
Won’t spin, weak/agitation issues	Washer actuator W10913953	Shifts the drive system between agitation and spin
Won’t spin, squeal/burnt rubber smell	Drive belt W11239857	Transfers motor power to the drive system
Won’t drain or drains slowly	Pump asm, dr W11396717	Pumps water out through the drain hose

Why it matters

A Whirlpool washer that cannot drain or spin usually cannot complete the cycle; that leaves clothes soaking wet and can strain the drive motor and belt over time. Catching a lid lock, belt, or pump issue early helps prevent bigger repairs.

Last updated: February 2026

On the Whirlpool WTW5105HW0 washer, the F05 E01 (often shown as F5E1) error points to a lid lock or lid switch problem; the washer senses the lid is unlocked when it must be locked to run or spin. Start by resetting power and checking the lid closes and latches cleanly.

Quick checks we recommend first

• Press Pause/Cancel (if available), then unplug the washer for 5 minutes and plug it back in.
• Make sure the lid is fully closed; remove any laundry caught between the lid and rim.
• Inspect the lid strike for cracks, looseness, or misalignment.
• Check for detergent or residue buildup around the lid lock area; wipe it clean and dry.
• Confirm the washer is plugged into a grounded 3-prong outlet (avoid extension cords).

Parts that commonly cause this code

If the code returns after the quick checks, these parts are the most common fixes on this style of Whirlpool top-load washer:

Symptom you notice	Most likely part	What it affects
Lid will not lock, or locks intermittently	Lid lock-sol W11700916	Prevents the washer from starting or spinning when the lid is not securely locked
Lid closes but never “clicks” into the lock	Washer lid strike W11457841	The strike engages the lid lock so the control can confirm the lid is shut

Why it matters

The lid lock system is a safety feature. If the control cannot confirm the lid is locked, it will stop the cycle or prevent high-speed spin to reduce the risk of injury and water slosh.

Model-specific tip

For operating and safety details (including electrical and care guidance), follow the steps in the WTW5105HW0 owner's manual.

Last updated: February 2026

Whirlpool washer parts are not universally interchangeable, even within Whirlpool models. For Whirlpool WTW5105HW0, we recommend matching parts by the exact model number and the original part ID because fit, wiring, and calibration can vary by design revision.

What “interchangeable” really means

Parts can look similar but still differ in mounting points, electrical connectors, or software compatibility.

Common examples where exact matching matters:

• Electrical parts (actuators, capacitors, lid locks) can have different connectors or timing.
• Water parts (inlet valves, hoses) can differ by flow rate and port style.
• Drive system parts (belt, pulley, motor) must match the drive design and belt profile.
• Safety parts (lid lock, lid strike) must align correctly for the washer to run.

For model-specific identification steps, use the WTW5105HW0 owner's manual.

Parts on WTW5105HW0 that should be model-matched

These are common “looks-the-same” parts that we treat as model-specific on Whirlpool top-load washers:

• Washer actuator W10913953 (shifts between agitation and spin)
• Washer water inlet valve W11165546 (controls hot/cold fill)
• Drive belt W11239857 (transfers motor power)
• Lid lock-sol W11700916 (lid safety lock)

Quick compatibility checklist

If you are replacing a...	Match by	Why it matters
Actuator or lid lock	Model number + part ID	Prevents wiring and control issues
Belt or pulley	Part ID + drive style	Avoids slipping, noise, no-spin
Inlet valve	Part ID + port layout	Prevents leaks and fill errors

Why it matters

Using the correct Whirlpool WTW5105HW0 parts prevents leaks, no-spin/no-drain symptoms, error codes, and repeat failures. It also reduces the chance of damaging the control system or creating a safety issue with the lid lock.

Last updated: February 2026
