Kenmore Elite 11067062600 dryer Parts

When a Kenmore Elite 11067062600 dryer powers on but the drum will not spin, it usually means the motor is running but the drum drive system is not transferring motion. The most common cause is a broken or slipped drum belt, followed by an idler pulley or drum support roller problem.

Quick checks before opening the cabinet

• Confirm the door fully closes and latches; a door issue can stop tumbling.
• Try turning the drum by hand (dryer unplugged); if it spins very freely, the belt may be broken.
• Start a cycle and listen:
  • Motor hums/runs but no tumbling: likely belt, idler, roller, or a jam.
  • Click then silence: possible motor issue or a safety switch stopping the motor.
• If the drum is stuck, check for a small item wedged at the front or rear drum seal.

Parts that most often cause “runs but won’t spin” on this model

For the 11067062600, these are common wear items we see tied to a no-tumble symptom:

• Dryer drum belt WP8547157
• Dryer idler assembly WPW10547292
• Support WPW10314173 (drum support roller)
• Dryer repair kit 4392067 (often bundles multiple wear parts)

What to do next (safe, practical path)

1. Unplug the dryer (or switch off the breaker) before any inspection.
2. Use the 11067062600 use & care manual for access and safety guidance.
3. Inspect the belt path around the motor pulley and idler; replace any cracked, glazed, or broken belt.
4. Spin the drum rollers by hand; replace rollers that bind, wobble, or feel rough.
5. Check the idler pulley for a seized bearing or a pulley that will not spin smoothly.

Symptom-to-cause guide

What you notice	Most likely cause	Typical fix
Motor runs, drum doesn’t move	Belt broken/off	Replace belt
Loud squeal, then no tumbling	Idler pulley failing	Replace idler
Thumping, drum hard to turn	Roller worn/flat-spotted	Replace rollers
Drum won’t turn by hand	Jammed drum or seized roller	Clear jam or replace roller

Why it matters

A slipping belt or seized roller can overload the drive motor and shorten its life. Fixing the drive system early helps prevent bigger repairs and keeps drying performance consistent.

Last updated: January 2026

Replacing drum bearings on a Kenmore Elite 11067062600 dryer typically costs $150 to $400 total. The parts are usually the smaller share of the bill; most of the cost is labor because the dryer must be opened up and the drum support components inspected and serviced.

What you are usually paying for

Drum “bearing” noise on this model is often related to drum support wear (rear support, drum rollers, idler pulley, belt, and seals). We recommend using the troubleshooting and access steps in the 11067062600 dryer manual.

Typical cost drivers include:

• Diagnostic/service call (if you hire a technician)
• Labor time to remove the cabinet and drum
• Parts replaced (often more than one wear item)
• Extra work if the drum has been rubbing and damaged seals or the drum surface

Common parts that get replaced together

If you are already opening the dryer, it often makes sense to refresh multiple wear items at once.

• Dryer repair kit 4392067 (commonly bundles multiple wear components)
• Support WPW10314173 (drum support roller)
• Dryer drum belt WP8547157 (belt wear can cause squeal or thump)
• Drum seal 280140 (felt seal that can wear if the drum rubs)

Cost ranges (parts vs. labor)

Scenario	Typical parts cost	Typical labor cost	Typical total
DIY replacement	$30 to $150	$0	$30 to $150
Pro repair (single wear item)	$30 to $120	$120 to $280	$150 to $400
Pro repair (multiple wear items)	$80 to $200	$180 to $350	$260 to $550

Why it matters

Worn drum support parts can quickly get louder and can lead to secondary wear (belt damage, seal wear, or drum rubbing). Fixing the root cause early usually keeps the repair smaller and helps the dryer run smoother and quieter.

Last updated: January 2026

For Kenmore Elite dryer model 11067062600, the heating element part itself is typically $20 to $120, depending on whether you buy the element alone or a more complete assembly. If you hire a technician, total replacement cost is commonly $100 to $350 including labor.

What you may need to replace (not just the element)

On model 11067062600, a “no heat” complaint is not always the heater. We often see heat failures caused by a safety device opening due to restricted airflow.

Common related parts to check:

• Dryer heating element WP8544772
• Dryer thermal fuse WP3390719
• Whirlpool dryer thermal cut-off fuse kit (352-degree f) 280148
• Dryer high-limit thermostat WP8557403
• Lint screen and venting (clogs can overheat the heater housing)

Typical cost breakdown

Costs vary by region and service rates, but this is a realistic planning range.

Cost item	Typical range	Notes
Heating element part	$20 to $120	Model-specific; element-only is usually less than an assembly
Extra safety parts (if needed)	$15 to $60	Thermal fuse, thermal cut-off, high-limit thermostat
Labor (service call + install)	$80 to $250	Depends on access, diagnosis time, and local rates
Estimated total (pro install)	$100 to $350	Most common all-in range

Why it matters

If the dryer overheated because of poor airflow, replacing only the heater can lead to repeat failures. Cleaning the lint screen, checking the exhaust duct, and confirming proper venting helps protect the new heating element and improves drying performance.

DIY planning tips for this model

• Disconnect power before servicing; this is a 240V electric dryer.
• If the dryer runs but won’t heat, check airflow first, then test the thermal fuse and thermostats.
• Use the wiring and safety guidance in the 11067062600 dryer manual before disassembly.

Last updated: January 2026

Yes. For the Kenmore Elite dryer model 11067062600, we can help you find compatible replacement parts by matching the exact model number to the correct diagrams and part listings. Common repairs include the drum belt, thermal fuse, heating system parts, and door hardware; see the 11067062600 dryer manual for model-specific guidance.

How to make sure you get the right part

• Use the full model number 11067062600 (all digits matter).
• Match the part by function and location (for example: heating, drum support, door).
• Compare the part name and ID, not just a description like “belt” or “fuse.”
• If your dryer has symptoms (no heat, won’t start, squealing), start with the most common wear items.
• Follow the safety steps and access instructions in the 11067062600 dryer manual before disassembly.

Popular parts customers replace on this model

Here are a few model-matched examples from the parts list for 11067062600:

Symptom or maintenance need	Part to check/replace	Example part for this model
Drum not turning, burning rubber smell	Drum belt	Dryer drum belt WP8547157
Dryer won’t start or stops quickly	Thermal fuse	Dryer thermal fuse WP3390719
No heat (electric model)	Heating element	Dryer heating element WP8544772
Squealing or thumping noise	Drum support roller / idler	Support WPW10314173

Why it matters

Kenmore dryers often share similar-looking parts across different series, but small design changes can affect fit. Using the exact 11067062600 match helps prevent ordering a part that installs incorrectly or causes repeat failures.

Last updated: January 2026

For Kenmore Elite dryer model 11067062600, the most common problems we see are no heat or long dry times, won’t start, won’t tumble, and loud squealing or thumping. These symptoms often trace back to airflow restrictions or wear parts such as a thermal fuse, heating circuit components, or drum support parts (see the 11067062600 dryer manual).

Most common symptoms and likely causes

• Dryer won’t heat / takes too long to dry: restricted venting, failed heating element, blown thermal fuse, or a temperature-sensing issue.
• Dryer won’t start: power supply problem (tripped breaker), door not fully closed, or a failed safety component.
• Drum won’t tumble: broken belt or a seized drum support component.
• Squealing, grinding, or thumping noise: worn rollers, idler, or belt.
• Clothes overdry or underdry on Auto cycles: moisture sensor bars dirty or sensor circuit issue.

Model-specific parts that commonly fix these issues

Because 11067062600 is an electric dryer platform, these parts are frequent solutions when symptoms match:

• Dryer thermal fuse WP3390719 (no heat, won’t run in some cases)
• Dryer heating element WP8544772 (no heat)
• Dryer thermistor WP8577274 (temperature control problems)
• Dryer drum belt WP8547157 (won’t tumble)
• Support WPW10314173 (noise, thumping from worn drum support roller)

Quick checks before replacing parts

1. Clean the lint screen and confirm strong airflow at the outside vent hood.
2. Check the breaker; many electric dryers use a 2-pole breaker and one side can trip.
3. Avoid overloading; heavy loads can mimic “no heat” by extending dry time.
4. If the dryer runs but dries poorly, inspect vent length and elbows (long runs reduce performance).

Symptom-to-part cheat sheet

Symptom	Most common fix path	Parts often involved (examples)
No heat	Verify airflow, then test heating circuit	WP3390719, WP8544772, WP8577274
Won’t tumble	Inspect belt and drum support	WP8547157, WPW10314173
Loud squeal/thump	Inspect rollers/idler/belt wear	WPW10314173, WP8547157
Auto cycles inconsistent	Clean sensor bars, then test sensor circuit	WP3387223, WP8577274

Why it matters

Dryer problems often start with restricted venting; that can cause overheating, repeated thermal fuse failures, and longer dry times. Fixing airflow first helps protect the heating system and reduces repeat repairs.

Last updated: January 2026

For Kenmore Elite dryer model 11067062600, the cabinet dimensions are 27 in. (W) x 28 15/16 in. (D) x 40 13/16 in. (H), and the IEC drying capacity is 7.3 cu. ft. (22.5 lb/10.2 kg). Confirm fit and clearance details in the 11067062600 use and care manual.

Size specs for model 11067062600

• Width: 27 in.
• Depth: 28 15/16 in.
• Height: 40 13/16 in.
• IEC capacity: 7.3 cu. ft.
• Load rating (IEC): 22.5 lb (10.2 kg)

Quick reference table

Measurement	Value
Width	27 in.
Depth	28 15/16 in.
Height	40 13/16 in.
IEC capacity	7.3 cu. ft.

Installation clearance notes

Even with the correct cabinet size, you still need space for airflow, venting, and service access.

• Plan room for the exhaust vent connection behind the dryer
• Avoid crushing or kinking the vent when pushing the dryer back
• Allow space for the door to open fully
• Keep the area around the exhaust outlet free of lint buildup

Why it matters

Using the correct dimensions and capacity helps you avoid tight installs that can restrict venting, increase dry times, and make routine maintenance harder.
