Whirlpool ED5LHEXTD10 side-by-side refrigerator Parts

The Whirlpool ED5LHEXTD10 is a full-size side-by-side refrigerator that’s typically about 25 cubic feet of total capacity. For most kitchens, that size class needs a standard 36-inch-wide opening plus extra clearance for door swing and airflow.

What “big” usually means (capacity vs. physical size)

Refrigerator size is commonly described two ways:

• Capacity (cu. ft.): how much food it holds
• Overall dimensions: width, height, and depth (including handles)
• Clearances: space needed around the cabinet for ventilation and door swing
• Door style: side-by-side doors need side clearance to open fully

Typical size range for this Whirlpool side-by-side class

Because we do not have a model-specific spec sheet for ED5LHEXTD10 here, use these common ranges for a 25 cu. ft. Whirlpool side-by-side:

Measurement	Typical range	What to measure at home
Width	35 1/2 to 36 inches	widest point of cabinet
Height	69 to 71 inches	floor to top hinge cover
Depth	33 to 36 inches	back to front (include handles if present)

How to measure your ED5LHEXTD10 correctly

• Measure width at the widest point (often the hinge side or trim)
• Measure height from floor to the highest point (hinge cover)
• Measure depth from the wall to the front (include handles)
• Add at least 1 inch behind for airflow and water line routing
• Confirm you can remove doors or shelves if you need to move it through a doorway

Why it matters

Getting the right size prevents installation headaches like doors that hit walls, poor condenser airflow (warm temps), and crushed water lines that can affect the dispenser and ice maker.

If you’re also planning for water and ice use, pairing the correct filter and keeping water flow strong helps performance; the correct filter for this model is the refrigerator water filter EDR3RXD1.

Last updated: January 2026

“5-in-1 mode” is a convertible temperature feature found on some Whirlpool refrigerators that lets you switch a compartment between preset cooling profiles (for example: everyday cooling, party, or deep freeze). The Whirlpool ED5LHEXTD10 side-by-side refrigerator is not typically described as a “5-in-1 convertible” model; for ED5LHEXTD10, focus on standard refrigerator and freezer temperature settings and the ice and water system.

What “5-in-1” usually means (in plain terms)

On Whirlpool models that include it, 5-in-1 mode changes how cold a convertible zone runs so you can match storage needs.

Common preset profiles include:

• All-season or everyday cooling
• Party mode (extra chilling for frequent door openings)
• Deep freeze (colder setpoint for frozen storage)
• Dessert or soft-freeze style cooling
• Chef or quick-cool style cooling

What to do on Whirlpool ED5LHEXTD10 instead

Because ED5LHEXTD10 is a traditional side-by-side design, you will get the best results by dialing in normal setpoints and keeping airflow clear.

Use these practical checks:

• Set the refrigerator to about 37°F and the freezer to about 0°F (typical targets)
• Keep vents unblocked (especially near the back wall)
• Confirm the doors seal tightly and close on their own
• Replace the water filter on schedule if you use the dispenser
• If ice or water is weak, check household water supply and the inlet valve

Quick comparison

Feature	“5-in-1 convertible” refrigerators	Whirlpool ED5LHEXTD10 side-by-side
Main purpose	Switch a compartment between preset modes	Maintain steady fridge and freezer temps
User control	Mode selection (profiles)	Temperature controls and airflow management
Common related issues	Wrong mode for food type	Door seal leaks, airflow blockage, water/ice flow

Why it matters

Using the right temperature strategy prevents food spoilage, reduces frost and odor issues, and helps the ice maker and water dispenser perform consistently.

Helpful related parts and guides

• If you use the dispenser, the correct replacement is the refrigerator water filter EDR3RXD1.
• For dispenser or ice maker performance issues, follow how to prevent water dispenser and ice maker problems.

Last updated: January 2026

The model number for your Whirlpool side-by-side refrigerator is printed on the appliance’s model and serial tag; on most units like ED5LHEXTD10, that tag is inside the fresh food compartment along the side wall or near the ceiling. Use the full model number to match parts correctly.

Where to look on a Whirlpool side-by-side

Check these common tag locations first:

• Inside the refrigerator (fresh food) section on the left wall
• Inside the refrigerator section on the right wall
• On the ceiling of the fresh food compartment near the light housing
• Along the door frame (hinge side) when the refrigerator door is open
• Behind the toe grille or lower kickplate area (less common)

What the label looks like and what to copy

The tag usually lists both a model and serial number. For parts lookup, we use the model number exactly as shown.

Label item	What it’s used for	Example format
Model number	Identifies the exact design and parts	ED5LHEXTD10
Serial number	Production code and date info	Letters and numbers

Why it matters for ordering parts

Even small model-number differences can change the correct water filter, ice maker, door gasket, or inlet valve. Once you confirm the model number, you can confidently choose model-matched parts such as the refrigerator water filter EDR3RXD1 or refrigerator ice maker WPW10190965.

Quick tips to avoid mix-ups

• Write the model number exactly, including all letters and numbers
• Take a clear photo of the tag before ordering
• If the tag is hard to read, clean it gently with a damp cloth and dry it
• Match the model number to the parts list before purchasing

Last updated: March 2026
