Are all Craftsman mower blades the same?
No. Craftsman mower blades are not all the same; the correct blade depends on your exact mower model, deck size, and blade mounting pattern. For Craftsman model 917376406 (22-inch Multi-Cut), match the replacement blade to the model’s specified blade part to ensure safe fit, cut quality, and proper engine load.
How to choose the right blade for Craftsman 917376406
Use the model-specific parts list in the 917376406 owner's manual and match the blade by part number and mounting style.
Key fit checks we use:
- Deck size: this mower is a 22-inch deck (from the manual cover).
- Blade length: should match the deck size (a 22-inch deck typically uses a blade around 21 to 22 inches).
- Center hole and adapter pattern: star, bow-tie, round, or multi-hole patterns must match.
- Blade type: standard lift, high lift, or 3-in-1 (mulch, bag, side discharge).
- Direction and curvature: wrong orientation can reduce lift and leave clumps.
Model-matched blade example
For this model, a common model-listed blade is the husqvarna lawn mower 22-inch deck 3-in-1 blade 532421825. Always confirm your current blade matches the same part number or the same mounting pattern before ordering.
Why blades are not universally interchangeable
Even within Craftsman walk-behind mowers, blade hubs and crankshaft adapters vary. A blade that “almost fits” can:
- Vibrate and damage the crankshaft
- Cut unevenly or leave uncut strips
- Overload the engine and reduce performance
- Create a safety hazard if it loosens
Quick comparison: what must match vs what can vary
| Item | Must match? | Notes |
|---|---|---|
| Center hole / mounting pattern | Yes | Most important for safe installation |
| Blade length | Yes | Must match deck design and clearance |
| Blade type (mulching vs high-lift) | No | Can vary if it fits and matches your mowing goal |
| Brand name on blade | No | OEM-equivalent blades can fit if specs match |
Helpful DIY guidance
If you’re removing the blade to compare it, use a blade-holding method and the right socket size; our lawn mower blade removal tool guide helps you do it safely.
Why it matters
The blade is the main cutting and airflow component. Using the correct blade for Craftsman 917376406 protects the mower deck, keeps the self-propel system from working harder than it should, and improves mulching and bagging results.
Last updated: February 2026
How do I know what size mower blade I need?
For Craftsman walk-behind mower model 917376406, the most reliable way to confirm blade size is to match the blade to your model’s parts listing and blade-mount pattern; this model commonly uses a 22-inch deck blade such as the husqvarna lawn mower 22-inch deck 3-in-1 blade 532421825.
The quickest ways to confirm the right blade
- Match by model number: Use 917376406 to select the correct blade and hardware in the 917376406 owner's manual.
- Measure the old blade length: Measure tip-to-tip (straight across the blade’s cutting length). Most walk-behind mowers in this class are 21 to 22 inches.
- Confirm the center hole and mount: Your blade’s center hole must match the blade adapter pattern; the manual notes the center hole must align with the star on the adapter.
- Check blade type: Choose the style that fits how you mow (3-in-1, mulching, bagging, side discharge).
- Inspect the blade adapter key: If the adapter key is worn or damaged, blade fit and cutting performance suffer even with the correct blade.
What to measure (and what it tells you)
| What you check | What it confirms | Why it matters |
|---|---|---|
| Blade length (tip-to-tip) | Deck/blade size (often 21 to 22 in.) | Wrong length can scalp grass or leave uncut strips |
| Center hole shape/pattern | Correct fit on blade adapter | Prevents wobble and unsafe operation |
| Blade condition (bent, cracked) | Whether replacement is required | Damaged blades cut poorly and stress the engine |
| Blade bolt tightness | Proper installation | Manual torque spec is 35 to 40 ft-lbs |
Why it matters
A blade that matches the length and center-hole mount for Craftsman 917376406 cuts cleaner, reduces vibration, and protects the crankshaft and blade adapter. Correct installation torque also helps prevent loosening during operation.
Helpful related DIY guidance
If you’re replacing or servicing the blade, these guides help you do it safely and accurately:
Last updated: February 2026
Is it cheaper to repair or replace a lawnmower?
For a Craftsman walk-behind mower like model 917376406, repair is usually cheaper when the fix is routine maintenance or a single worn part; replacement makes more sense when the repair total is over about 50% of the cost of a comparable new mower, or when the engine or drive system has major failure.
Quick rule of thumb
- Repair when the mower needs normal wear items (blade, cable, wheels) or a tune-up.
- Replace when the engine has internal damage, the crankshaft is bent, or multiple big-ticket systems fail at once.
- Decide based on total cost: parts + labor + your time, compared to a new mower.
Common repairs that are usually worth it
These are typical, cost-effective fixes on a gas walk-behind mower:
- Replace a worn or bent blade (example: husqvarna lawn mower 22-inch deck 3-in-1 blade 532421825)
- Replace a stretched or broken control cable (example: cable assembly 587326601)
- Clean drive wheel/pinion areas when the mower will not self-propel (grass buildup is common)
- Annual maintenance: oil change, air filter service, spark plug replacement
When replacement is the better value
Replacement is typically the smarter choice when you have one of these situations:
- Major engine damage (hard to start plus low power plus metal noise)
- Bent crankshaft (often happens after striking a stump or rock)
- Transmission/drive system failure on a self-propelled mower, especially if combined with other repairs
- The deck is severely rusted or cracked (structural issues keep coming back)
Cost comparison checklist
| Situation | Typical best choice | Why |
|---|---|---|
| One worn part (blade, cable, wheel) | Repair | Low parts cost, fast turnaround |
| Needs seasonal tune-up | Repair | Restores performance and reliability |
| Engine internal failure | Replace | Repair cost approaches new mower cost |
| Drive system plus engine issues | Replace | Stacked repairs exceed mower value |
Why it matters
Putting money into the right repair keeps your 917376406 cutting safely and evenly, and it protects the warranty expectations around proper maintenance and approved replacement parts. For model-specific maintenance intervals and service guidance, follow the 917376406 owner's manual.
Last updated: February 2026
What are the common problems with Craftsman lawn mowers?
On the Craftsman walk-behind mower model 917376406, the most common problems we see are no-start conditions (often fuel, spark, or air-related), loss of power, poor cut quality, excessive vibration, and drive or push issues. Our 917376406 owner's manual troubleshooting chart matches these symptoms closely.
Most common symptoms and what usually causes them
- Won’t start: stale fuel, dirty air filter, water in fuel, disconnected spark plug wire, bad spark plug, or the control bar not held to the handle
- Loss of power: cutting too much grass at once, dirty air filter, grass buildup under the deck, too much oil, or walking speed too fast
- Poor cut or uneven cut: worn or bent blade, uneven wheel height settings, or debris packed under the mower deck
- Excessive vibration: loose or damaged blade, broken blade adapter, or a bent crankshaft (typically after striking a hard object)
- Starter rope hard to pull: blade dragging in grass, brake engaged when the control bar is released, or internal damage after an impact
- Hard to push or loss of drive: grass too high, deck dragging, or drive system wear (belt, pulley, transmission components)
Quick checks we recommend before buying parts
- Drain old gas and refill with fresh fuel.
- Inspect and clean the underside of the deck (built-up clippings can cause power loss and poor cutting).
- Verify the control bar is fully depressed to the handle during starting.
- Check the blade for bends, cracks, and tight mounting hardware.
- Confirm all wheel height adjusters are set to the same notch.
Parts that commonly get replaced on this model
| Symptom | Commonly involved part | Example from this model’s parts list |
|---|---|---|
| Poor cut, vibration | Blade | Husqvarna lawn mower 22-inch deck 3-in-1 blade 532421825 |
| Poor discharge, safety concern | Clipping deflector | Lawn mower clipping deflector 532426129 |
| Drive issues | Transmission assembly | Lawn mower transmission assembly 589600601 |
| Self-propel speed problems | Drive pulley | Lawn mower drive pulley 532443262 |
Why it matters
Catching these issues early prevents bigger failures. For example, mowing with a bent blade can damage the blade adapter and crankshaft, and grass buildup under the deck can make the engine work harder and lose power.
Last updated: February 2026
What model number is a Craftsman 6.75 lawn mower?
A “Craftsman 6.75” label usually refers to the engine series (commonly a Briggs & Stratton 675 Series), not the mower’s model number. For the Craftsman walk-behind mower covered by this page, the model number is 917.376406; you’ll find it on the ID decal and in the 917376406 owner’s manual.
Where to find the model number on the mower
We use the mower’s model number (not the engine label) to match the correct diagrams and replacement parts.
- Check the mower housing/deck near the rear discharge door or wheel area
- Look for a white or silver ID decal with a model format like 917.XXXXXX
- Confirm it matches the manual cover page (for this unit: 917.376406)
- If the decal is worn, compare handle, deck size, and drive features to the manual
“6.75” vs. mower model number: what’s the difference?
The “6.75” marking is commonly tied to the engine family, while the mower model number identifies the full Craftsman machine (deck, drive system, handle, wheels, and safety controls).
| What you see | What it identifies | Example on this mower |
|---|---|---|
| 6.75 / 675 Series | Engine series/family | Briggs & Stratton 675 Series |
| 917.376406 | Mower model number | Craftsman 917.376406 |
| Part ID (SKU-style) | Specific replacement part listing | 532421825 |
Why it matters when ordering parts
Using the correct model number prevents common fit issues, especially on wear items and safety-related controls.
Common parts that must match the mower model:
- Blade and blade hardware (example: husqvarna lawn mower 22-inch deck 3-in-1 blade 532421825)
- Zone control cable and handle controls
- Drive components (pinion, pawl, belt keeper)
- Rear skirt and clipping deflector
Last updated: February 2026
