Kenmore 25361552013 refrigerator Parts

On Kenmore model 25361552013, we clean the drip pan by safely accessing it (often behind the toe grille), emptying and washing it, then reinstalling it so it sits flat and drains correctly. Use the steps in the installation guide to remove the toe grille and level the cabinet afterward.

Safety first

• Unplug the refrigerator before you reach near wiring, fans, or the compressor area.
• Wear gloves; drip pans can have sharp edges and mold residue.
• If you must pull the refrigerator out, protect the floor and avoid kinking any water line.
• Keep the toe grille area unblocked when you finish; airflow matters for proper operation.

Step-by-step: cleaning the drip pan

1. Unplug the refrigerator.
2. Remove the toe grille (front bottom panel). Many models use clips; some use screws.
3. Look for the drip pan:
   • On many top-mount refrigerators, it slides out from the front near the compressor area.
   • On some designs, it is accessed from the rear.
4. Slide the pan out carefully and keep it level to avoid spills.
5. Empty and wash:
   • Hot water plus mild dish soap.
   • For odor or slime, use a baking-soda solution and a soft brush.
6. Rinse and dry completely, then reinstall the pan so it is fully seated.
7. Reinstall the toe grille, plug the refrigerator back in, and confirm it is stable and doors close properly.

What to use (and what to avoid)

Item	Use it for	Avoid because
Mild dish soap + hot water	Routine cleaning	None
Baking soda + water	Odors and light residue	Not a disinfectant
Soft brush or bottle brush	Corners and film	Metal brushes can scratch
Bleach (very diluted)	Heavy mold (last resort)	Fumes; rinse thoroughly

Why it matters

A clean drip pan reduces odors, helps prevent mold growth, and keeps condensate from overflowing onto the floor. Keeping the toe grille clear also supports airflow, which helps the refrigerator cool efficiently.

If you still have puddles after cleaning

• Make sure the pan is fully seated and not cracked.
• Check that the refrigerator is tilted slightly back so doors seal and water drains correctly (typical guidance is about 1/4 inch front-to-back).
• Confirm the toe grille is installed and not blocked.

If you need the replacement pan for this model, match it by model number 25361552013 in the parts list.

Last updated: February 2026

For Kenmore model 25361552013, the model number alone typically does not state the exact cubic-foot capacity. The most reliable way is to look up the capacity in the product specs section of your documentation, or calculate it from the interior measurements using a simple volume formula (then convert to cubic feet). See the owner's manual for model-specific identification and specs.

Fast ways to find the capacity

1) Check the documentation (best option)

Use the model-specific documents to find the listed “capacity” or “total volume” value.

• Look for a “Specifications” or “Product data” section
• Check for “Total capacity”, “Refrigerator capacity”, and “Freezer capacity”
• Use the exact model number 25361552013 when matching specs

2) Calculate cubic feet from interior measurements

If you cannot find a listed capacity, you can estimate it by measuring the usable interior space.

• Empty the compartment you are measuring (fresh food or freezer)
• Measure width, height, and depth in inches (usable space, not the outer cabinet)
• Multiply: W x H x D = cubic inches
• Convert: cubic inches ÷ 1728 = cubic feet
• Repeat for freezer and refrigerator sections; add them for an estimated total

What to measure (and what not to)

Capacity is based on interior usable volume, so measurements should reflect the space you can actually load.

• Measure to the inside walls and liner surfaces
• Subtract obvious obstructions (large duct covers, big light housings)
• Do not use exterior cabinet dimensions; those overstate capacity

Quick reference table

What you have	What it tells you	Accuracy
Model number (25361552013)	Identifies the exact unit	High (for ID), not capacity
Listed “total capacity” in docs	True rated cubic feet	Highest
Interior measurement calculation	Estimated cubic feet	Good estimate

Why it matters

Knowing cubic feet helps you compare refrigerator sizes, confirm fit for your kitchen layout, and choose correctly sized replacement bins, shelves, and storage accessories for your Kenmore top-mount refrigerator.

Last updated: February 2026

On a Kenmore 25361552013 top-mount refrigerator, the top section is the freezer compartment. It’s the insulated area designed to hold foods at freezing temperatures and, on many models, it also houses the ice maker and cold-air circulation components (fan and vents). See the compartment layout and control details in the 25361552013 owner's manual.

What the freezer compartment does

The freezer is more than just the “top door”; it supports overall cooling performance.

• Keeps food at or below 0°F for safe long-term storage
• Sends cold air down to the fresh food section through internal air passages
• Helps maintain stable temperatures when doors are opened and closed
• Often contains the evaporator area (behind the rear panel) where frost can build during defrost issues

Common top-section parts you might hear about

If you’re troubleshooting noise, warm temperatures, or frost, these freezer-area parts are often involved.

What you notice	Common freezer-area cause	Example part on this model page
Rattling or ticking noise	Fan blade hitting ice or shroud	Refrigerator evaporator fan blade 5308000010
Freezer cold but fridge warm	Weak or stalled evaporator fan motor	Refrigerator evaporator motor 242077705
Heavy frost on back wall	Defrost system problem	Refrigerator defrost bi-metal thermostat 5303918202

Why it matters

When the freezer compartment is not circulating air correctly or is icing up, the refrigerator section can warm up even if the freezer still feels cold. Keeping the freezer vents clear and the doors sealing properly helps the entire refrigerator cool the way it should.

Quick checks we recommend

• Confirm the freezer door closes fully and seals all the way around
• Keep packages from blocking air vents inside the freezer
• If you see frost buildup, unplug the refrigerator and inspect for ice around the fan area
• After changing temperature controls, wait 24 hours before making another adjustment (a common top-mount guideline)

Last updated: February 2026

For Kenmore model 25361552013, the correct water filter is the one that matches your refrigerator’s filter housing and the part number printed on your current filter (or listed for your model in the documentation). We use the model number and the existing filter ID to ensure the replacement seals correctly and maintains water flow.

How to identify the right filter for model 25361552013

Use these quick checks before ordering:

• Confirm the model tag reads 25361552013 (usually inside the fresh food section).
• Look for a part number printed on the old filter (letters and numbers matter).
• Note the filter location: inside the refrigerator compartment, in the base grille, or on the back.
• Check whether your unit uses a twist-in cartridge or a push-in style.
• If you have an ice maker connected to a water line, confirm the filter is in the refrigerator (not an external inline filter).

For model-specific filter location and replacement steps, follow the owner's manual.

What to expect when you install a new filter

A new filter can change flow and taste for the first few uses. Plan to:

• Dispense and discard several glasses of water to clear air from the line.
• Check for drips around the filter head after installation.
• Re-seat the filter if it feels loose or the dispenser sputters.
• Replace the filter on a regular schedule (most households do this about every 6 months).

Quick troubleshooting guide

Symptom after replacement	Most common cause	What we do
Leaking at filter	Not fully seated, wrong style	Remove and reinstall; confirm correct filter for 25361552013
Low water flow	Air in line, clogged filter head	Flush water; re-seat filter
Bad taste/odor	New carbon fines	Flush more water through

Why it matters

Using the correct filter for Kenmore 25361552013 prevents leaks at the filter housing, protects the water valve and tubing from debris, and helps your ice maker and dispenser maintain steady flow.

If you need help narrowing down the exact filter type Kenmore used on your configuration, the installation guide also confirms water supply requirements (30 to 100 psi) that affect dispenser and ice maker performance.

Last updated: February 2026
