Whirlpool LG5801XKW1 dryer Parts

Yes. For your Whirlpool dryer model LG5801XKW1, searching by the full model number is the most reliable way to match the correct replacement part because it filters results to the exact diagrams and part listings built for that dryer.

• Find the model tag on the dryer (commonly on the door opening, door frame, or inside the cabinet).
• Enter LG5801XKW1 exactly as shown (letters and numbers matter).
• Use the model’s parts list and diagrams to identify the part by name and location.
• Match the part by its ID and description before ordering.
• If you are fixing a symptom (noise, no heat, no start), confirm the failure first so you do not replace the wrong part.

These are examples of parts that are commonly searched by model for LG5801XKW1:

Whirlpool often uses similar-looking parts across many dryer series, but mounting points, wiring connectors, and lengths can differ. Searching by LG5801XKW1 helps prevent ordering a belt, thermal fuse, or motor component that does not fit your exact dryer.

Last updated: February 2026

On the Whirlpool dryer model LG5801XKW1, error code F-01 points to a problem with the electronic control board (main control) or its wiring connections. In most cases, the fix is reseating wire plugs and, if the code returns, replacing the control board.

• Unplug the dryer (or switch off the breaker) for 2 minutes, then restore power and try a cycle.
• If F-01 returns, unplug power again and access the control area.
• Reseat each wire harness connector on the control board (push in firmly until fully seated).
• Look for loose pins, corrosion, or heat damage on connectors.
• Confirm the dryer door closes and latches consistently; a door that is not closing can cause confusing symptoms.

If the wiring looks good and F-01 comes back quickly, the control is typically failing internally. At that point, replacement is the practical repair.

F-01 is a control-system fault; continuing to run the dryer with unstable control signals can cause repeated shutdowns, incomplete drying, or no-start conditions. Fixing airflow issues and electrical connections helps prevent repeat failures.

For code patterns and what they generally indicate across Whirlpool electronic-control dryers, use our Whirlpool electronic control model dryer error codes guide.

Last updated: February 2026

On your Whirlpool dryer model LG5801XKW1, we remove the control panel and top first, then release the front panel clips and lift the front panel off. This gives you safe access to common service areas like the belt, idler pulley, and blower housing.

• Unplug the dryer from the wall outlet.
• If it is a gas dryer, shut off the gas supply valve.
• Pull the dryer forward so you can reach the rear and sides.
• Have a Phillips screwdriver and a flat-blade screwdriver ready.
• Keep a small cup for screws so nothing gets lost.

1. Remove the control panel screws (typically at the ends or along the back edge of the console).
2. Rotate the control panel up and back to expose the top fasteners.
3. Remove the screws securing the main top.
4. Slide the top panel back slightly, then lift it off.

1. Insert a flat-blade screwdriver between the upper and lower front panels.
2. Push in to release the two spring clips.
3. Lift the front panel up and off the lower retaining tabs.
4. If your door switch wiring is attached to the front panel, disconnect the harness carefully before fully removing the panel.

Removing the panels the right way prevents bent sheet metal, broken clips, and pinched wiring. It also makes it easier to diagnose common Whirlpool dryer problems like a broken belt, seized idler pulley, or damaged blower wheel.

Last updated: February 2026
