Frigidaire PHS67EHSB1 refrigerator Parts

For your Frigidaire refrigerator, the most reliable way to identify the exact model is to read the model and serial plate inside the fresh food (refrigerator) compartment. On model PHS67EHSB1, the manual notes this information is found on the serial plate located inside the refrigerator compartment; record it for future parts and service needs.

Where to look on a side-by-side refrigerator

Check these common spots first (use a flashlight and wipe condensation off the label):

• Inside the fresh food compartment on a side wall (often upper right)
• Along the door frame or door jamb area
• Near the top control panel area inside the fresh food section
• Behind the crisper drawers or on the liner near the bottom
• On the ceiling of the fresh food compartment (less common)

What the model tag looks like (and what to write down)

The label typically includes both a model number and a serial number. Copy them exactly as shown (letters, numbers, and any dashes).

Item on label	What it’s used for	Example format
Model number	Matching the correct parts diagrams and parts list	PHS67EHSB1
Serial number	Identifying production series for certain part variations	Letters and numbers
Purchase date (optional)	Maintenance records and warranty paperwork	Month/day/year

Why it matters for parts and troubleshooting

Even small model number differences can change which parts fit (door bins, gaskets, ice maker components, and water filter style). Using the exact model number helps us match the right replacement part the first time.

If you are replacing the water filter on this Frigidaire side-by-side, the parts list for PHS67EHSB1 includes the Frigidaire puresource2 refrigerator water filter WF2CB, and the owner's manual shows how the filter release button works during removal and installation.

Quick tip if the label is hard to read

• Take a close-up photo and zoom in
• Write down the model first, then the serial
• If the sticker is damaged, look for a second label inside the compartment

Last updated: February 2026

Frigidaire Gallery is not a luxury, high-end line; it is a strong mid-range tier that typically adds upgraded finishes and more features than basic Frigidaire models, while staying below premium “pro-style” offerings. For feature details on your Frigidaire PHS67EHSB1, use the PHS67EHSB1 owner's manual.

What “high end” usually means for refrigerators

When shoppers say “high end,” they usually mean a combination of premium materials, advanced performance features, and a higher price tier.

Common high-end traits include:

• Dual compressors or dual evaporators for tighter humidity and temperature control
• Very quiet operation and premium interior lighting
• Higher-end dispenser and ice system features
• More robust shelving, bins, and door hardware
• Longer feature lists (smart features, specialty cooling zones)

Where Frigidaire Gallery typically fits

Gallery models are generally positioned as an upgrade from entry-level Frigidaire, with a focus on value and popular features.

A simple way to think about it:

Line tier (typical)	What you get	Who it fits
Entry-level	Basic cooling and storage	Budget-first replacement
Mid-range (Gallery)	More features and styling	Best value for most homes
Premium / pro-style	Top features and premium build	Design and performance-first

How to judge “high end” for your PHS67EHSB1

For the most accurate comparison, we recommend evaluating your PHS67EHSB1 by the features you will actually use and maintain.

Key checkpoints:

• Ice output expectations: Side-mounted ice makers commonly produce about 4 to 4.5 pounds per 24 hours under normal conditions.
• Airflow design: Keeping vents unblocked helps maintain even temperatures in both compartments.
• Water and ice quality: Regular filter changes help protect taste and flow; the compatible filter for this model is the Frigidaire puresource2 refrigerator water filter WF2CB.

Why it matters

“High end” is less about the badge and more about whether the refrigerator meets your needs for temperature stability, ice and water performance, and long-term upkeep (filters, gaskets, and dispenser components).

Last updated: February 2026

On the Frigidaire PHS67EHSB1 side-by-side refrigerator, an H or HI code indicates a high temperature alarm. It means the refrigerator or freezer temperature has been too warm for an extended period, most commonly after a door is left ajar or not sealing tightly.

What to check first (fast fixes)

• Make sure both doors fully close and do not bounce back open
• Check for packages or bins preventing the door from shutting
• Inspect the door gaskets for gaps, tears, or areas not contacting the cabinet
• Confirm the temperature controls were not accidentally set warmer
• Give the unit time to recover after heavy loading or long door openings

Step-by-step troubleshooting for PHS67EHSB1

1. Close both doors firmly and listen for the door to seat against the gasket.
2. Verify temperature settings: use the Fresh Food and Freezer Up/Down buttons to adjust one degree at a time (colder is typically the Down/Colder button).
3. Check airflow: avoid blocking vents with food items in either compartment.
4. If the alarm returns, look for cooling issues such as frost buildup, weak airflow, or warm freezer temps.

Common causes and what they point to

What you notice	Likely cause	What to do next
HI after door was open	Normal warm-up event	Close doors; allow several hours to stabilize
Freezer not cold enough	Cooling or airflow problem	Check vents; listen for fan operation
Ice maker slows or stops too	Freezer temp too warm or restricted water flow	Replace clogged filter; confirm freezer temp

Parts that often relate to “HI” symptoms

If the HI condition is tied to poor sealing or restricted water flow, these model-matched parts are commonly involved:

• Refrigerator freezer gasket 241786014 (helps prevent warm air leaks)
• Frigidaire puresource2 refrigerator water filter WF2CB (a clogged filter can contribute to dispenser and ice maker issues)

Why it matters

High temperature events can lead to food spoilage and can also reduce ice production because the ice maker depends on a consistently cold freezer. Addressing door sealing and temperature recovery quickly helps the refrigerator return to normal operation.

For control locations, alarm behavior, and temperature adjustment details specific to this model, use the owner's manual.

Last updated: February 2026

The most common Frigidaire refrigerator problem we see is a cooling complaint: the fresh food section gets too warm, the freezer may still seem OK, or temperatures swing. On the Frigidaire PHS67EHSB1, the most frequent root causes are restricted airflow (dirty condenser coils), a door that is not sealing, or a defrost issue that leads to frost and poor cooling (see the owner's manual).

Most common symptoms customers report

• Refrigerator section warm but freezer cold
• Refrigerator runs too much or too long
• Frost buildup that reduces airflow
• Moisture or sweating inside the cabinet
• Ice maker or dispenser performance issues that show up alongside cooling problems

Quick checks that fix many “not cooling” calls

1. Confirm controls are set correctly and give the unit time to stabilize (allow about 24 hours after changes).
2. Clean the condenser; a dirty condenser can make the refrigerator run longer and cool poorly.
3. Check door closing and sealing; a slightly open door or a leaking gasket lets warm air in and drives long run times.
4. Reduce door openings; frequent openings add warm, humid air and can cause moisture and frost.
5. Look for frost patterns; heavy frost can point to a defrost system problem.

Parts that commonly relate to these problems (when a repair is needed)

If cleaning and door checks do not help, these model-matched parts are often involved in cooling, frost, and temperature complaints:

• Refrigerator defrost bi-metal thermostat 5303918214 (defrost protection and temperature sensing in the defrost circuit)
• Refrigerator evaporator fan blade 5308000010 (moves cold air through the freezer and into the fresh food section)
• Refrigerator freezer gasket 241786014 (helps prevent warm air leaks that cause long run times and frost)

Symptom-to-cause cheat sheet

What you notice	Most likely category	What to check first
Fresh food warm, freezer OK	Airflow/evaporator area	Frost buildup, fan airflow, vents blocked by food
Runs constantly	Heat removal or air leak	Condenser cleanliness, door seal, door alignment
Moisture on walls	Warm humid air entering	Door left ajar, frequent openings, uncovered containers
Frost buildup	Defrost/air leak	Door gasket condition, defrost components

Why it matters

Cooling problems usually get worse over time. A refrigerator that runs too long can struggle to hold safe food temperatures and can also point to airflow restrictions or a failing defrost system that is easier to correct early.
