Kenmore 79092603012 electric range Parts

Kenmore model 79092603012 is made for Kenmore by Frigidaire (Electrolux/Frigidaire family). The quickest way to confirm the manufacturer is the model number prefix: Kenmore ranges that start with 790 are Frigidaire-built.

How to confirm on the appliance

You can verify you are working with the correct model and manufacturer by checking the identification tag.

• Look for the model/serial tag on the range frame (commonly behind the oven door opening or on a side frame rail).
• Confirm the full model number is 79092603012 (all digits).
• Match the 790 prefix to Frigidaire-built Kenmore ranges.
• Use the model number when ordering parts like a bake element, broil element, or control switch.

Why the manufacturer matters for parts and troubleshooting

Kenmore is a brand label; the actual manufacturer determines the design, wiring layout, and which replacement parts fit.

What you need	Why it matters	Example for this model
Model number prefix	Identifies the manufacturer family	790 indicates Frigidaire-built
Correct part ID	Ensures fit and electrical match	Frigidaire range oven temperature sensor 316490000
Correct wiring method	Prevents damage and unsafe connections	Follow the 79092603012 installation guide

Helpful next steps if you are ordering parts

• Use the full model number 79092603012 when searching.
• If the oven temperature seems off, start with the sensor and calibration steps in the manual.
• If a surface element will not regulate heat, check the correct surface element control switch for that burner.
• If the oven will not bake or broil, inspect the bake and broil elements for visible damage.

Why it matters

Using the correct manufacturer family (Frigidaire-built Kenmore 790) helps you avoid wrong-part returns and speeds up diagnosis for common issues like no-heat, temperature swings, and burner control problems.

Last updated: January 2026

For the Kenmore 79092603012 electric range, the installation instructions focus on required clearances and cabinet cutout spacing, not the oven cavity capacity. Most 30-inch Kenmore slide-in or freestanding electric ranges have an oven capacity in the 4.8 to 5.7 cu. ft. range; confirm the exact capacity and interior dimensions in the 79092603012 owner's manual.

What “size” can mean for this model

When customers ask for oven “size,” it usually refers to one of these:

• Oven capacity (cubic feet)
• Interior dimensions (usable width, height, depth)
• Overall range dimensions (for fitting between cabinets)
• Required clearances (safe spacing to cabinets and walls)

Installation clearances and fit basics (from the install guide)

The Kenmore 79092603012 installation guidance calls out key spacing rules that affect whether the range fits safely.

• Plan for 30-inch minimum clearance from the cooktop to the bottom of an unprotected wood/metal cabinet above.
• The rear of the range can be installed at 0-inch minimum clearance (follow all listed dimension requirements).
• Avoid cabinet storage above surface elements; a range hood that projects outward helps reduce burn risk.
• Leveling legs must be adjusted so the range sits solid and level.

Quick reference table

Measurement type	What it tells you	Where to confirm
Oven capacity (cu. ft.)	How much the oven holds	79092603012 owner's manual
Interior dimensions	Pan and rack fit	79092603012 owner's manual
Clearance requirements	Safe spacing to cabinets	79092603012 installation guide

Why it matters

Using the correct “size” prevents cabinet interference, overheating risks, and poor baking results. Capacity and interior dimensions help you choose the right cookware; clearance specs help you install the range safely and correctly.

Last updated: January 2026

To reset your Kenmore electric range model 79092603012, we recommend doing a full power reset: turn the range circuit breaker OFF for 5 minutes, then turn it back ON and set the clock. This clears many control glitches and temporary error conditions.

Quick reset steps (power cycle)

• Turn OFF the range breaker (usually a 240V double-pole breaker).
• Wait 5 minutes (do not just flip it off and on).
• Turn the breaker ON.
• Set the clock and test Bake and Broil.
• If the display shows an error again, write down the exact code before resetting a second time.

If the oven still will not heat after a reset

A reset will not fix a failed heating or sensing component. On model 79092603012, these checks narrow it down fast:

• Bake works but broil does not: suspect the broil circuit or element.
• Broil works but bake does not: suspect the bake element.
• Both bake and broil are weak or inaccurate: suspect the oven temperature sensor.
• Nothing heats and the display is dead or flickers: suspect a power supply issue at the terminal block or cord.

Symptom after reset	Most common cause	What to check next
Oven temperature is way off	Sensor out of range	Inspect/replace frigidaire range oven temperature sensor 316490000
No bake heat	Failed bake element	Look for blisters/breaks on the element
No broil heat	Failed broil element	Check for visible damage and secure wiring

Why it matters

A proper reset clears temporary electronic faults, but repeated errors usually point to a real issue such as a failing sensor, heating element, or a loose power connection. Catching that early helps prevent uneven cooking and repeated shutdowns.

Safety notes before troubleshooting

• Turn power OFF at the breaker before removing panels or touching wiring.
• If you suspect a loose connection at the power cord/terminal area, follow the wiring and safety guidance in the 79092603012 installation guide.

Last updated: January 2026

On the Kenmore 79092603012 electric range, the F30 error code points to a problem in the oven temperature sensor circuit. Most often, the sensor probe is unplugged, the wiring is damaged, or the sensor itself has failed and needs replacement such as the frigidaire range oven temperature sensor 316490000.

What to check first (safe, quick steps)

• Press Cancel/Off to clear the code; if it returns, continue troubleshooting.
• Turn off power at the breaker for 1 minute, then restore power (resets the control).
• If the oven recently ran self-clean, let it cool completely; heat can stress sensor wiring.
• If the code appears as soon as you start Bake, focus on the sensor circuit.
• If the code appears intermittently, look for a loose connector or pinched wire.

Likely causes and what they mean

What’s wrong	What you’ll notice	Common fix
Sensor connector loose/unplugged	F30 comes and goes	Reseat connector, inspect pins
Sensor wiring damaged	F30 after moving range or after high heat	Repair/replace harness section
Temperature sensor failed (open/short)	F30 returns quickly after reset	Replace sensor
Control board issue (less common)	F30 persists after sensor checks	Professional diagnosis

How we recommend confirming the sensor is the issue

1. Disconnect power.
2. Access the sensor connection (typically at the rear of the range or inside the oven cavity, depending on design).
3. Inspect for burned terminals, loose plugs, or damaged insulation.
4. If wiring looks good, replace the sensor with the correct part for this model.

For wiring access points, panel removal, and any model-specific steps, follow the 79092603012 installation guide and the 79092603012 owner's manual.

Why it matters

When the control cannot read oven temperature accurately, it protects you by stopping heat. Fixing the sensor circuit restores proper baking temperatures and prevents overheating or underheating.

Last updated: January 2026
