Kenmore Elite 79036719505 gas range Parts

A Kenmore gas range like model 79036719505 typically lasts about 15 years with normal household use. Regular cleaning, correct burner flame, and prompt repair of heating or ignition issues help you get the full life out of the oven and cooktop.

Typical lifespan and what affects it

Most ranges reach their expected life when heat, airflow, and gas ignition stay consistent.

• Cleaning habits: grease buildup and spills speed up wear
• Ventilation: a working hood reduces heat and grease accumulation
• Ignition health: weak igniters cause longer preheat times and extra strain
• Temperature accuracy: a drifting sensor can lead to overworking the oven
• Usage level: heavy daily cooking shortens lifespan compared to light use

Quick maintenance checklist (high impact)

Use these steps to keep your Kenmore Elite gas range running efficiently.

• Keep burner caps and ports clean and dry
• Wipe up oven spills after the oven cools
• Avoid lining the oven bottom with foil (it can disrupt airflow and heat)
• Run self-clean only as needed and follow the owner's manual
• Replace failing ignition parts early (for example, a slow-to-glow igniter 5303935066)

Common “end-of-life” symptoms and likely fixes

Many “old range” problems are actually repairable with a few key parts.

Symptom	What it often points to	Example part on this model page
Oven takes too long to heat or won’t light	Weak oven igniter	Igniter
Oven temperature swings or bakes unevenly	Temperature sensing issue	Oven temperature sensor
Clicking won’t stop or burners won’t spark	Spark/ignition control issue	Cooktop spark module
Oven shuts off or overheats	Safety thermostat issue	High-limit thermostat

Why it matters

A gas range that lights quickly and holds temperature uses less gas, cooks more evenly, and puts less stress on components like the gas valve, regulator, and electronic controls. That is the difference between replacing a part and replacing the whole appliance.

Last updated: February 2026

The most common problems we see on the Kenmore Elite 79036719505 gas range are burners that will not ignite or keep clicking, an oven that will not heat or heats unevenly, and temperature accuracy issues. These symptoms usually trace to ignition parts, gas flow components, or oven temperature sensing.

Common symptoms and what they usually point to

• Surface burner will not light: dirty burner ports, weak spark, failed igniter, or a bad spark module
• Continuous clicking after the flame is on: moisture or soil around the igniter, misaligned burner cap, or a failing spark module
• Oven will not bake or broil: failed oven igniter, gas valve issue, or control problem
• Oven temperature is off: drifting temperature sensor or calibration needed
• Gas smell or weak flames: regulator or supply issue (shut off gas and ventilate before troubleshooting)

Parts that commonly solve these issues (when testing confirms failure)

If your symptoms match, these model-compatible parts are frequently involved:

• Igniter 5303935066 for no-heat or delayed ignition conditions
• Cooktop spark module 5304505695 for weak spark or constant clicking across burners
• Frigidaire range oven temperature sensor 316217002 for inaccurate oven temperatures
• Range pressure regulator 5304521339 for weak flames or inconsistent gas flow

Quick checks we recommend before replacing parts

1. Confirm the burner cap is seated correctly and ports are clear.
2. Dry the cooktop area thoroughly if clicking started after cleaning.
3. Verify the range has power (spark ignition and controls need electricity).
4. For oven heat issues, watch for a normal ignition sequence (glow, then flame) and note delays.

Troubleshooting map (symptom to likely area)

Symptom	Most likely area	Common part involved
Burner will not ignite	Spark/ignition	Igniter, spark module
Clicking continues	Igniter area or spark module	Spark module
Oven not heating	Oven ignition or gas valve	Igniter, gas valve
Temperature inaccurate	Sensing/calibration	Oven temperature sensor

Why it matters

On a gas range, ignition and gas flow problems can prevent safe, reliable lighting. Fixing the correct root cause helps restore normal burner operation, stable oven temperatures, and consistent baking results.

For model-specific operating steps, cleaning guidance, and any temperature calibration procedure, use the 79036719505 owner's manual.

Last updated: March 2026

Kenmore gas ranges (including Kenmore Elite model 79036719505) are made for Kenmore by other major appliance manufacturers; the actual maker varies by model and production run. The most reliable way to identify who built your specific range is to use the model and serial information shown in the owner's manual.

How to identify the manufacturer for your specific Kenmore range

We use the model number and serial plate details to match your range to the correct parts diagrams and service information.

• Confirm the full model number is 79036719505 (match every digit)
• Locate the serial plate (the manual shows where it’s typically found)
• Record the serial number and purchase date for your records
• Use the parts list for this model to ensure part compatibility
• If you are comparing parts across similar Kenmore models, match by model number first, not by appearance

Common manufacturers behind Kenmore-branded ranges

Kenmore is a brand label; ranges have historically been produced by multiple manufacturers over time. For gas ranges, the most common OEM relationships have included large U.S. and global appliance makers.

What you see	What it means	Best next step
“Kenmore” or “Kenmore Elite” on the front	Brand name, not the factory	Use the model number to select parts
Model number like 79036719505	Identifies the design family and parts set	Use the model-specific parts diagrams
Serial plate info	Helps narrow production run details	Keep it with your records

Why it matters when ordering parts

Two Kenmore gas ranges can look similar but use different igniters, sensors, or control components. Matching parts to 79036719505 helps you avoid fit and ignition or temperature-control issues.

If you are troubleshooting common bake problems on this model, the igniter 5303935066 and the frigidaire range oven temperature sensor 316217002 are examples of model-matched parts that often relate to heating and temperature symptoms.

Last updated: February 2026
