How to read Kenmore model numbers?
Kenmore model numbers are read left to right: the first 3 digits identify the manufacturer behind the Kenmore brand, and the remaining digits narrow down the exact product series and feature set. For your Kenmore electric range model 79045499503, the 790 prefix is the key identifier.
What each section of a Kenmore model number means
Most Kenmore model numbers follow this pattern:
- Prefix (first 3 digits): manufacturer code (example: 790)
- Middle digits: base design or series
- Ending digits: version, color, or feature variations
For model 79045499503, you can think of it like this:
| Section | Example | What it tells you |
|---|---|---|
| Manufacturer prefix | 790 | Who built it for Kenmore |
| Base model/series | 45499 | Core platform and configuration |
| Variation digits | 503 | Specific revision or feature package |
Why the prefix matters for parts
The prefix helps ensure you match parts to the correct design family. That matters because ranges that look similar can use different bake elements, control panels, or wiring connections.
Common examples of parts that must match the correct model family:
- Oven heating parts (bake element, temperature sensor)
- Cooktop heating parts (radiant surface element)
- Electrical connection parts (terminal block)
- Control interface parts (control overlay, control panel gasket)
Where to find the model number on the range
On most Kenmore electric ranges, the model and serial tag is typically found:
- On the oven frame behind the storage drawer
- Along the door frame area when the oven door is open
- On a side trim area near the front of the cavity
For diagrams and the exact location callouts for this model family, use the 79045499503 owner's manual.
Helpful next step if you are troubleshooting
If you are trying to interpret a fault code on a Kenmore 790-prefix range, use the Kenmore 790 self-cleaning range error codes reference to match the code to likely causes.
Why it matters
Reading the model number correctly prevents wrong-part orders and speeds up troubleshooting because it ties your range to the correct wiring, control system, and heating design.
Last updated: January 2026
Where is the model number on my Kenmore electric stove?
On the Kenmore electric range model 79045499503, the model and serial number plate is located along the side of the oven door frame when the door is open. Use the exact model number from that plate when ordering parts or looking up service information in the 79045499503 installation guide.
How to find it quickly
- Open the oven door fully.
- Look along the side trim of the oven door opening (the vertical door frame area).
- Find the serial plate sticker or metal tag.
- Write down the model number, serial number, and any lot number/letter.
- Use that information when matching Kenmore range parts like a bake element, control panel, or temperature sensor.
What you should record (and why)
| What to copy | Example format | Why it matters |
|---|---|---|
| Model number | 79045499503 | Ensures parts fit your exact Kenmore 790 series range |
| Serial number | Letters and numbers | Helps identify production version |
| Lot number/letter (if shown) | Letter or code | Can affect part revisions and wiring layouts |
If the label is hard to read
- Wipe the plate gently with a damp cloth and mild dish soap; dry it.
- Use a flashlight and take a close-up photo to zoom in.
- If the plate is damaged, check your paperwork and then confirm details in the 79045499503 owners manual.
Why it matters
Kenmore ranges often have multiple versions that look the same but use different surface elements, control overlays, or wiring connections. Using the model and serial information from the door-frame plate prevents ordering the wrong part.
Last updated: January 2026
How do I reset my Kenmore oven control board?
To reset the control board on your Kenmore 79045499503 electric range, we recommend a simple power reset first: turn the range off and shut off power at the breaker for 5 minutes, then restore power. If the display shows “LOC”, cancel the oven lockout instead of resetting. See the 79045499503 owner's manual.
Step-by-step reset (power cycle)
- Turn the oven off.
- Switch the range circuit breaker OFF (or unplug the range if accessible).
- Wait 5 minutes to let the control fully discharge.
- Turn the breaker ON (or plug back in).
- Set the clock and test Bake at 350°F.
If the display says “LOC” (control lockout)
On this model, “LOC” usually means the control is in Oven Lockout mode, which can look like the control is “stuck.” The manual procedure is to press and hold the lockout pad for 3 seconds to toggle lockout on or off.
- Hold the lockout key for 3 seconds to cancel lockout
- Wait about 15 seconds for the door lock motor to finish moving
- Do not try to open the door while the “Door Locked” light is flashing
What to check if problems come back after a reset
If the range resets but errors return, the issue is usually a heat-sensing or heating problem, not a “glitch.” Common checks:
- Loose or overheated wiring at the power connection (inspect the terminal block 5304409888)
- Oven temperature drifting or error codes (sensor circuit issues; consider the frigidaire range oven temperature sensor 316217002)
- Oven not heating evenly or not heating at all (bake circuit issues; consider the frigidaire range bake element 318255401)
Quick guide: reset vs. lockout
| Symptom | Most likely cause | What to do |
|---|---|---|
| Blank display after outage | Control needs reboot | Power cycle 5 minutes |
| “LOC” shows when pressing keys | Oven lockout enabled | Hold lockout key 3 seconds |
| Error code returns quickly | Underlying fault | Check sensor, element, wiring |
Why it matters
A power reset clears temporary control-board glitches, but “LOC” is a normal safety feature that intentionally disables the keypad and can lock the door. Knowing which one you are dealing with prevents unnecessary parts replacement.
Last updated: January 2026
What was the size of the Kenmore 79045499503 oven?
The Kenmore electric range model 79045499503 is a standard 30-inch freestanding range; it fits a typical 30-inch range opening. For the exact exterior width, height, depth, and required clearances for your kitchen, use the measurements listed in the 79045499503 installation guide.
What “size” can mean for this range
Depending on whether you are replacing a range, planning cabinetry, or comparing ovens, “size” usually means:
- Overall range width (cabinet opening fit)
- Overall height (leveling legs, countertop height)
- Overall depth (varies with door and handle)
- Oven cavity capacity (cubic feet)
- Installation clearances (to walls and cabinets)
Typical planning dimensions for a 30-inch freestanding electric range
Most Kenmore 790-series freestanding electric ranges fall into these common planning ranges. Confirm the exact numbers for 79045499503 in the installation guide.
- Width: about 29 7/8 in. to 30 in.
- Height: about 46 in. to 48 in. (adjustable with leveling legs)
- Depth: about 25 in. to 28 in. (often deeper with handle)
| Measurement | Typical planning range | Where to confirm for 79045499503 |
|---|---|---|
| Width | 29 7/8 in. to 30 in. | Installation guide |
| Height | 46 in. to 48 in. | Installation guide |
| Depth | 25 in. to 28 in. | Installation guide |
| Clearances | Varies by install | Installation guide |
Oven capacity note
Oven capacity is listed in cubic feet in the product specifications. We use the 79045499503 owner’s manual to match the correct capacity and features to your exact configuration (cooktop style and control layout can vary by model).
Why it matters
Using the correct exterior dimensions and clearances prevents cabinet fit issues, helps you plan electrical cord routing and anti-tip bracket placement, and avoids door or drawer interference after the range is leveled.
Last updated: January 2026
