Kenmore 7909641340D electric range Parts

Your Kenmore stove’s model number is printed on the appliance identification plate. On Kenmore electric range model 7909641340D, the manual shows the ID plate is on the right side of the oven front frame, inside the storage or warmer drawer compartment; match the number on that plate to your paperwork and parts list in the 7909641340D owner's manual.

Where to look on a Kenmore range

We recommend checking these common ID-plate locations in this order:

• Inside the storage drawer or warmer drawer opening (right side of the oven front frame is common)
• Along the oven door frame when you open the door
• On the back panel of the range
• Under the cooktop (some models lift up)
• On your purchase receipt or warranty paperwork (if you recorded it)

What the model number looks like

Kenmore model numbers are usually a long number with a prefix that identifies the manufacturing source. For many Kenmore ranges, you’ll often see a prefix like 790 at the start of the model number.

What you see	What it means	What to do next
Model number (example: 7909641340D)	Identifies the exact range design	Use it to select the correct parts list and diagrams
Serial number	Identifies your specific unit	Keep it for service records and age tracking
“790” prefix	Common Kenmore range prefix	Use the full model number, not just the prefix

Why it matters

We use the full model number to match the correct wiring, control layout, and oven components (like a bake element, broil element, or oven temperature sensor). Even small model-number differences can change which parts fit.

Ordering the right parts once you find it

After you confirm the model number, order parts from the parts list for that exact model, or search by model number on Sears PartsDirect.

Last updated: February 2026

To reset your Kenmore electric range model 7909641340D, turn the range OFF, shut off power at the breaker (or unplug it) for about 1 minute, then restore power and reset the clock. If the cooktop is locked after a power outage, turn OFF the Cooktop Lockout feature.

Quick reset steps (power reset)

• Turn all surface element knobs to OFF.
• Press CLEAR/OFF to stop any beeping or cancel an oven function.
• Switch the range circuit breaker OFF (or unplug the cord).
• Wait 60 seconds.
• Restore power, then reset the clock and reselect your bake or broil setting (see the owner's manual).

If the cooktop controls are locked (Cooktop Lockout)

Your range can stay locked after a power failure or after a Self-Clean cycle. To unlock:

• Verify all surface controls are OFF.
• Press and hold the Cooktop Lockout key for about 3 seconds until you hear a beep.
• If you hear a triple beep, recheck that every surface control is OFF and repeat.

What a reset fixes (and what it does not)

Symptom	Reset usually helps?	What to check next
Display frozen or unresponsive	Yes	Power reset, then set clock
Oven will not start after outage	Yes	Clock must be set; try Bake again
“F” code beeping	Sometimes	Press CLEAR/OFF; if it returns, troubleshoot the code using Kenmore 790 self-cleaning range error codes
Oven not heating	Sometimes	Check elements and sensor connections; consider frigidaire range bake element 316413800 or frigidaire range oven temperature sensor 316490000 if testing shows failure

Why it matters

A proper reset clears temporary electronic control glitches and restores normal operation after a power interruption. On this model, the oven may not operate correctly until the time of day is set, and the cooktop may stay unusable until Lockout is turned off.

You can order replacement parts for Kenmore 7909641340D from the parts list for this model, or search by model number on Sears PartsDirect.

Last updated: February 2026

A Kenmore 7909641340D electric range oven typically stops working because it is not getting proper power, the controls are not set correctly, or a key oven component (like the bake element, broil element, or temperature sensor) has failed. Start with power and settings checks, then move to parts testing.

Quick checks we recommend first

• Confirm the range has power (check house lights and the breaker for the range circuit).
• Make sure the oven controls are set for the correct cooking mode and temperature.
• If the display is beeping and shows an “F” error code, press STOP/CLEAR to stop the beeping, then reprogram the oven.
• If the oven stopped during or after a power outage, reset the clock and reselect the oven function (the range should not be operated during a power failure).
• If the oven light is out, replace or tighten the bulb (this does not stop heating, but it helps confirm the oven cavity is accessible).

Most common failed parts when the oven will not heat

If the range has power and the controls respond, these are the most common heating-related failures on electric ranges:

Symptom	Most likely cause	What to check next
Oven will not bake	Open bake circuit	Inspect and test the frigidaire range bake element 316413800
Oven will not broil	Open broil circuit	Inspect and test the frigidaire range broil element 316203301
Temps are erratic or oven shuts down	Sensor out of range	Test/replace the frigidaire range oven temperature sensor 316490000
Control beeps, shows “F” code	Control detected a fault	Clear with STOP/CLEAR; if it returns, use the error code chart in the owner's manual

Why it matters

An oven that “stops working” can be a simple power or settings issue, but it can also be a failed heating circuit. Checking power and error codes first prevents unnecessary parts replacement and helps you pinpoint whether the problem is in the bake, broil, or temperature-sensing system.

Parts and help for this model

We list common replacement parts for Kenmore 7909641340D on this model’s parts list. For broader part searches by model number, use Sears PartsDirect.
