Kenmore Elite 79097503001 electric range Parts

To reset your Kenmore Elite electric range model 79097503001, turn the range off at the household breaker for 1 minute, then restore power. This power reset clears many control glitches and is the most reliable “factory reset” method for this style of electronic oven control; confirm any model-specific settings in the owner's manual.

Quick reset steps (recommended)

• Set the oven to OFF and make sure no cooking cycle is running.
• Turn OFF the range circuit breaker (or unplug the range if accessible).
• Wait 60 seconds.
• Restore power.
• Set the clock and test Bake at 350°F.

If the control is still acting up

A reset helps only if the issue is a temporary control lockup. If the oven still will not heat, heats unevenly, or shows temperature problems, check these common causes:

• Failed temperature sensing (often points to the range oven temperature sensor 5304504897).
• Burned-out bake circuit (often points to the oven element 318601604).
• Loose or overheated power connections at the terminal block (inspect wiring and connections at the terminal block 5304409888).
• Control relay problem (intermittent heat or no heat can involve the oven relay board).

What a reset does (and does not do)

Action	What it affects	What it won’t fix
Breaker reset (power cycle)	Clears a frozen keypad/control logic	Burned-out element, failed sensor, broken wiring
Reprogram clock/settings	Restores time-based functions	Temperature accuracy problems

Why it matters

A proper power reset is a fast way to rule out a simple electronic glitch before you spend time testing parts like the bake element, temperature sensor, or wiring connections.

Last updated: February 2026

Yes. The Kenmore Elite 79097503001 is part of Kenmore’s premium “Elite” range lineup, so it’s generally considered a higher-end electric range compared with standard Kenmore models, especially for features and overall cooking performance. For model-specific operation and setup details, use the installation guide.

What “high end” means for this model

When we describe the 79097503001 as high end, we’re typically talking about a combination of cooking capability, fit and finish, and feature set.

Common high-end indicators on Elite electric ranges include:

• More precise oven temperature control and better baking consistency
• Convection cooking components (fan and related hardware)
• Higher-output radiant cooktop elements and multi-size elements
• More robust electronic controls and relays for oven and surface units
• Better insulation and cooling airflow management

Quick ways to judge it in your kitchen

Use these practical checks to decide if it feels “high end” for your needs:

• Heat consistency: Does the oven hold temperature well during long bakes?
• Preheat speed: Does it reach set temp quickly without large swings?
• Cooktop flexibility: Do you have multi-ring elements for different pan sizes?
• Noise and airflow: Does the cooling fan run smoothly and keep controls cooler?
• Serviceability: Are common wear parts available when you need them?

Parts that support premium performance (examples)

If you’re troubleshooting performance, these model-compatible parts are often involved:

Symptom	Common area	Example part on this model
Oven temp off, uneven baking	Temperature sensing	Range oven temperature sensor 5304504897
Oven not heating properly	Bake circuit	Oven element 318601604
Convection not circulating	Fan system	Range convection fan motor 5304463302

Why it matters

A “high-end” range is only as good as its real-world results. If your 79097503001 bakes evenly, holds temperature, and the cooktop responds predictably, you’re getting the main benefits people expect from a premium electric range.

Last updated: February 2026

For the Kenmore Elite electric range model 79097503001, the installation dimensions shown are approximately 29-7/8 inches wide and 25-3/4 inches deep, with a typical countertop height of 36 ± 1/8 inches. For the complete clearance and fit requirements, use the installation guide.

Key dimensions and clearances to plan for

These are the measurements that matter most when you are fitting the range into a cabinet cutout or replacing an older unit:

• Overall width: about 29-7/8 in.
• Overall depth (front to back): about 25-3/4 in.
• Countertop height reference: 36 ± 1/8 in.
• Minimum clearance to cabinets above the cooktop: 30 in. (or 24 in. if the cabinet bottom is properly protected)
• Rear clearance: 0 in. minimum (per the installation dimensions)

What “oven size” can mean (and what to use)

People often mean one of two things:

If you mean...	Use this measurement	Where to find it
Fit in the opening	Width, depth, height, and clearances	Installation guide
Cooking capacity	Oven cavity volume (cubic feet)	Owner's manual

Why it matters

Using the installation dimensions for model 79097503001 helps prevent cabinet interference, heat damage risk, and leveling problems. It also ensures the anti-tip bracket can be installed correctly, which is a critical safety step.

Related parts that come up during installs or moves

If you are reinstalling the range or addressing power connection issues, these parts are commonly involved:

• Terminal block 5304409888 (power connection point at the range)
• Range ground strap 318264200 (helps ensure proper grounding path)

Last updated: February 2026
