Bosch SHX65T55UC/02 dishwasher Parts

Bosch dishwashers typically last 10 to 15 years with normal household use and basic care. For your Bosch SHX65T55UC, consistent cleaning, correct loading, and keeping the fill and drain systems flowing freely are the biggest factors in reaching the high end of that range; see the owner's manual for model-specific care guidance.

• Water quality and temperature: Hot water around 120°F (49°C) helps cleaning performance and reduces extra-long run times.
• Supply pressure and steady fill: Low or inconsistent fill can strain components over time.
• Drain performance: Standing water and repeated drain issues accelerate wear.
• Loading habits: Overloading can block spray arms and increase pump workload.
• Routine maintenance: Cleaning filters and spray arms prevents circulation restrictions.

• Run hot water at the sink until it is hot before starting a cycle.
• Keep the filter area clean and remove food debris regularly.
• Check spray arms for clogs and clear blocked holes.
• Use the right detergent amount; avoid over-sudsing.
• Fix small leaks quickly so moisture does not reach electrical parts.

A dishwasher that is filling at the right temperature and pressure, spraying freely, and draining completely runs fewer “extra” minutes per cycle. That reduces heat and pump run time, which is a direct path to longer service life.

You can order replacement parts for your Bosch SHX65T55UC from the parts list for this model, or search by model number on Sears PartsDirect.

Last updated: February 2026

The most common problem we see with Bosch dishwashers like model SHX65T55UC is a drain issue (water left in the tub) caused by a clogged filter area, a restricted drain path, or a failing drain component. Filling problems are also common when the water supply or inlet valve is restricted.

• Standing water after the cycle: drain path restriction, drain hose routing issue, or a drain component problem
• Hums but doesn’t drain: blockage at the sump area or a restricted hose
• Not filling or fills slowly: water supply valve not fully open, kinked supply line, or inlet valve issue
• Poor cleaning: spray arm holes clogged, diverter not directing water correctly
• Error code on the display: points to a specific system (drain, fill, heating, sensor)

For model-specific checks and the correct “self help” steps, use the owner's manual.

1. Cancel/drain the cycle and listen for drain pump operation.
2. Check the sink/disposer connection (if newly installed) for a knockout plug that was not removed.
3. Inspect the drain hose routing: avoid kinks and avoid a low spot that can trap water.
4. Clean the filter area in the bottom of the tub and remove debris.
5. Confirm hot water supply is available; if the hot water system has been unused for weeks, run a nearby faucet until the water runs normally before starting the dishwasher.

If troubleshooting points to a failed component, these are common matches for the symptoms above:

To decode what the dishwasher is reporting, use Bosch dishwasher error codes. For ordering, we list model-matched parts on this page, and you can also search by model number on Sears PartsDirect.

Drain and fill problems can stop a cycle mid-run, leave dirty water in the tub, and reduce cleaning performance. Catching restrictions early also helps protect key components like the circulation system and sensors.

Last updated: February 2026

If your Bosch SHX65T55UC dishwasher shows an E22 error, we recommend stopping use until you clear the drainage restriction. E22 is tied to poor draining (often a clogged filter or blocked drain path), and continuing to run cycles can leave dirty water in the tub and reduce cleaning performance.

• Cancel the cycle and let the dishwasher drain if it will.
• Turn off power at the breaker before reaching into the sump area.
• Remove and clean the filter area (food debris and glass are common).
• Check the drain hose routing for kinks or a crushed section.
• Make sure the sink drain or garbage disposer inlet is not blocked.
• Review the drain and self-help steps in the SHX65T55UC owner's manual.

You can run the dishwasher again after the filter and drain path are clear and the unit drains normally at the end of a cancel or rinse cycle.

If cleaning and hose checks do not fix the issue, these model-compatible parts are common suspects:

• Dishwasher drain hose 00744881 (kinked, clogged, or leaking)
• Dishwasher water inlet valve 10023852 (fill issues can complicate wash performance, even if the main symptom is draining)

E22 is a drainage-related fault; when water cannot move out correctly, the dishwasher can recirculate dirty water, leave residue on dishes, and increase the chance of odors. Clearing the restriction protects wash results and helps prevent repeat errors.

For additional troubleshooting and code meanings, use our Bosch dishwasher error codes guide. If you need to order replacement parts for SHX65T55UC, use the parts list for this model or search by model number on Sears PartsDirect.

Last updated: February 2026
