Kenmore 79096008803 electric range Parts

To reset a Kenmore electric range model 79096008803, turn the range OFF, shut off power at the breaker (or unplug it), wait about 1 minute, then restore power and reset the clock. This clears many control glitches after a power interruption.

Quick reset steps (safe and effective)

• Turn all surface burner knobs to OFF.
• Switch the range OFF at the circuit breaker (preferred) or unplug the power cord.
• Wait 60 seconds.
• Restore power.
• Set the time of day using the clock controls in the 79096008803 owner's manual.
• Test Bake at 350°F for 10 minutes to confirm the oven heats normally.

If the reset was triggered by a power failure

Your manual notes that if power fails, you should turn the range off; when power returns, the range can resume operation and you will need to reset the clock and oven function. Use the 79096008803 owner's manual to confirm the correct clock and timer button sequence.

What a reset fixes (and what it does not)

Symptom	Reset helps?	What to check next
Display frozen or beeping	Yes	Try reset again; then check control panel keys
Oven not heating after outage	Often	Test Bake and Broil; check elements
Door locked after self-clean	Sometimes	Allow about 1 hour to cool; do not force door
Burner not heating	Sometimes	Check the burner switch and element

Common next checks if the oven still will not heat

• Look for visible damage or blisters on the range bake element 316075103.
• If baking is weak or temperatures swing, consider the frigidaire range oven temperature sensor 316490000.
• If broil does not heat, inspect the broil element for damage.
• If the display works but heat never comes on, a wiring or control issue is likely.

Why it matters

A proper power reset is the fastest way to clear a stuck electronic control and restore normal operation after a power surge or outage; it also confirms whether you are dealing with a simple control glitch or a failed heating component.

Last updated: February 2026

On a Kenmore electric range like model 79096008803, an F3 error (sometimes shown as F30/F31) points to an oven temperature sensing problem. In most cases, the issue is a failed oven temperature sensor probe or a wiring/connection problem between the sensor and the electronic oven control.

What to do first (safe, quick checks)

• Press STOP/CLEAR once to silence beeping and clear the display; if the code returns, continue troubleshooting.
• Turn power off at the breaker for 1 minute, then restore power and retest.
• If the oven recently overheated, let it cool completely and try Bake again.
• If the code appears immediately when starting Bake, focus on the sensor circuit (sensor, harness, connectors).
• If you see any burnt smell or damaged wiring, keep power off and have the range serviced.

Parts that commonly cause an F3 code

The most common fix is replacing the oven temperature sensor.

Symptom	Most likely cause	Common next step
F3 appears during preheat	Sensor reading out of range	Test/replace sensor
F3 appears intermittently	Loose connection or damaged harness	Inspect connectors, repair wiring
F3 appears with other control issues	Electronic oven control problem	Check wiring first, then control diagnostics

For this model, the sensor part is the range oven temperature sensor 316490000.

Why it matters

The control uses the temperature sensor signal to regulate the bake element and broil element. When the sensor circuit reads too high, too low, or open/shorted, the control triggers F3 to prevent unsafe heating and poor cooking results.

Where to confirm the code and reset steps

We recommend checking the troubleshooting section in the 79096008803 owner's manual for model-specific display behavior and control-panel steps.

Last updated: February 2026

On the Kenmore 79096008803 electric range, “Warm and hold” is designed to keep cooked food warm at a low, safe holding temperature. Most Kenmore ranges of this style hold food at about 150°F to 170°F; use your control panel display and the 79096008803 owner's manual for the exact setting and how to turn it on or off.

What to expect from warm and hold

• It maintains a low oven temperature to keep food warm after cooking.
• It is meant for short-term holding, not for cooking or reheating.
• It can run until you cancel it, depending on the feature setup.
• If your oven is set for timed cooking, the behavior can differ from standard Bake.

Quick check: warm and hold vs. bake

Feature	Typical temperature range	Best use	Not recommended for
Warm and hold	150°F to 170°F	Holding cooked casseroles, rolls, plated food	Cooking raw foods, long holding times
Bake	170°F to 550°F	Cooking and baking	Holding food warm

How to confirm the exact temperature on this model

1. Start the Warm and hold (or Hold) function per the 79096008803 owner's manual.
2. Watch the display for the set temperature or “Hold” indicator.
3. If the oven seems too hot or too cool during normal baking, use the calibration steps in the manual (this model supports temperature adjustment up to about 35°F).

Why it matters

Warm and hold is intentionally lower than Bake so food stays warm without overcooking or drying out. Knowing the target temperature helps you choose the right function for serving, especially for breads, sides, and cooked meats.

Last updated: February 2026

The Kenmore 79096008803 electric range is a standard freestanding 30-inch class range; the exact oven cavity capacity (in cubic feet) and the exact exterior dimensions are listed in the model’s documentation. For the most accurate “size” spec, we use the measurements and capacity shown in the 79096008803 owner's manual.

What “oven size” can mean (and what to check)

Different sellers use “size” differently, so we recommend matching the spec to what you need:

• Oven capacity (cu. ft.): best for comparing how much you can bake/roast at once
• Exterior width: typically about 30 inches for this style of Kenmore range
• Overall height: varies with leveling legs and floor-to-cooktop height
• Depth: varies depending on handle style and rear clearance requirements
• Cutout/clearance: critical for safe installation next to cabinets

Where to find the exact measurements for model 79096008803

Use the documentation for your model to confirm the official specs:

• Look for a “Product dimensions” or “Specifications” section
• Check the installation clearances and anti-tip bracket placement requirements
• If you are measuring for a move or remodel, measure your range in place and compare to the guide

Quick comparison: typical freestanding electric range sizing

Spec you’re looking for	Typical value (30-inch class)	Best source for 79096008803
Exterior width	~30 in.	79096008803 installation guide
Overall height	~36 in. (adjustable)	79096008803 installation guide
Overall depth	~25 to 28 in.	79096008803 installation guide
Oven capacity	Varies by model	79096008803 owner's manual

Why it matters

Using the correct “size” prevents fit issues (door clearance, handle depth, cabinet spacing) and helps you choose the right bakeware and racks for everyday cooking.

Last updated: February 2026

On Kenmore electric range model 79096008803, the model and serial number are printed on an identification (serial) plate located on the right side of the oven front frame inside the storage or warmer drawer compartment. Open the storage drawer (or the front lower panel on some versions) to see it; confirm the exact spot in the 79096008803 owner's manual.

Where to look on model 79096008803

Check these locations in order:

• Open the storage drawer and look along the right side of the oven front frame
• If your range has a front lower panel instead of a drawer, open/remove that panel and look in the same area
• Look for a label that lists Model No. 790.** and a Serial No.
• Use a flashlight; the plate is often on the frame where it is harder to see from above

Quick steps to find it fast

1. Turn the oven light on (or use a flashlight).
2. Pull the storage drawer fully open.
3. Look at the right-side frame just inside the drawer opening.
4. Write down the full model number and serial number for parts lookup and service.

What the label typically shows

Label item	What it’s used for
Model number (example format: 790.xxxx)	Matching the correct Kenmore range parts and diagrams
Serial number	Identifying production details for service and compatibility
Electrical ratings	Verifying power requirements during installation or troubleshooting

Why it matters

Using the exact model number prevents ordering the wrong bake element, oven temperature sensor, or control overlay for your Kenmore range. Even small model variations can change wiring, control boards, and door parts.

Last updated: February 2026

If your Kenmore electric range model 79096008803 is not heating, the most common causes are a failed oven heating element (bake or broil), a bad oven temperature sensor, or a control issue triggered by a fault code. Start with a quick visual check, then test components for continuity.

Quick checks first (no tools)

• Confirm the range has power; if there was a power failure, turn the range off, restore power, then reset the clock and cooking mode per the 79096008803 owner's manual.
• Make sure you are using Bake (for normal oven heating) and allowing full preheat time.
• If the control is beeping and showing an F code, press STOP/CLEAR to stop the beeping and clear the display.
• Check whether the cooktop works; if the cooktop and oven are both dead, the issue is often power supply related.

Most likely failed parts for “oven won’t heat”

In this model, these parts commonly affect oven heating:

• Bake element: look for blisters, cracks, or a separated spot on the element; replace if damaged or open on a continuity test using range bake element 316075103.
• Broil element: some baking cycles use broil for preheat; a failed broil element can cause slow or no preheat.
• Oven temperature sensor: if the sensor is out of range or open, the control may prevent proper heating; test and replace if needed using frigidaire range oven temperature sensor 316490000.

What the symptoms usually mean

Symptom	Most common cause	What we recommend
Oven won’t heat at all, no glow/heat	Failed bake element or control issue	Inspect and continuity-test bake element first
Oven heats unevenly or takes too long	Weak bake element or sensor drift	Verify temperature with an oven thermometer; check sensor
Control beeps and shows F code	Electronic control detected a fault	Clear with STOP/CLEAR; then diagnose the code

Why it matters

An electric range that will not heat is usually a single failed component (element or sensor). Testing in a logical order prevents unnecessary parts replacement and gets your Kenmore 79096008803 back to safe, reliable baking.

Last updated: February 2026

A burner on your Kenmore electric range model 79096008803 usually stops working because the surface element is not getting power (tripped breaker, loose/burned wiring), the control switch is failing, or the element itself is open. Start with power and control checks, then test the element and switch.

Quick checks (fastest fixes first)

• Confirm the range has power; reset the house circuit breaker fully OFF then ON.
• Make sure you turned the correct knob for that burner; incorrect control settings can make it seem dead.
• If your cooktop uses removable elements, reseat the element so the contacts fit tightly.
• Try the same burner on a different setting (LOW to HI) to see if it heats at any level.
• If other burners work but one does not, focus on that burner’s element, switch, and wiring.

Most common failed parts for this symptom

If the burner never heats, these are the most likely culprits:

• Surface element (radiant element): open heating circuit, damaged terminals, or cracked element.
• Infinite switch (surface element control switch): no power sent to the element even though the knob turns.
• Wiring/terminal connections: overheated spade terminals, loose connectors, or burned wires.

Helpful model-matched parts to consider:

• Range radiant surface element, 9-in 316135401
• Frigidaire range surface element control switch 316436001
• Frigidaire range small surface element control switch 316436000

Troubleshooting guide (what the results mean)

What you see	Most likely cause	What we recommend
Only one burner is dead	Bad element or bad infinite switch	Swap/test element first; then replace switch if needed
Burner heats only on HI (or cycles oddly)	Weak/failed infinite switch	Replace the correct control switch
No burners work	Power supply issue	Check breaker, cord connection, and terminal block

Safety and “why it matters”

A non-working burner is often an electrical connection problem. Loose or overheated wiring can worsen quickly and damage the harness or terminal block. Always disconnect power at the breaker before inspecting wiring, and follow the safety and service guidance in the 79096008803 owner’s manual.

When to stop and schedule service

• You see melted wiring, scorching, or a burning smell
• The breaker trips when you turn the burner on
• The range has intermittent power or multiple burners fail at once

Last updated: February 2026
