On a Whirlpool WED5700AC1 electric dryer, you typically clear an error by canceling the cycle and resetting power. If the code returns right away, the dryer is detecting an ongoing problem (often airflow, heat, or a sensor issue) that needs troubleshooting.

Quick reset steps (most common)

• Press Cancel/Stop once to end the cycle.
• If the code stays on, unplug the dryer (or switch the breaker off) for 1 minute.
• Restore power and run a short Timed Dry test.
• If the code returns, note the exact code and follow the diagnostic steps in the WED5700AC1 owner's manual.

What to check if the code comes back

Many dryer error codes are triggered by conditions the control senses, not just a “stored message.” Start with the basics:

• Airflow restriction: clean the lint screen and check the vent duct for kinks, crushing, or heavy lint buildup.
• Overheating symptoms: burning smell, very hot cabinet, or repeated thermal shutdown.
• Moisture sensor issues: auto cycles end too soon or run too long; clean sensor bars inside the drum.
• Door switch problems: dryer stops when you bump the door or will not start with the door closed.
• Power supply (electric dryer): a weak/bad leg of 240V can cause heat-related faults.

Parts that commonly relate to error conditions on this model

If troubleshooting points to a specific failure, these are common repair items for WED5700AC1:

Symptom you see	Commonly involved part	Example part on this model
No heat or weak heat	Heating circuit	Dryer heating element WP3387747
Overheats, shuts down, or no heat after overheating	Safety cut-off	Dryer thermal cut-off fuse kit 279973
Auto cycles act “confused” (overdry or underdry)	Moisture sensing	Dryer moisture sensor WP3387223

Why it matters

Clearing the code without fixing the cause can lead to longer dry times, repeated shutdowns, or overheating. Restoring proper airflow and confirming the heating and sensing circuits are working correctly helps the dryer run safely and dry efficiently.

Helpful reference

For code definitions and what each one points to, use our Whirlpool electronic control model dryer error codes guide.

Last updated: January 2026

For the Whirlpool WED5700AC1 electric dryer, a “reset” usually means clearing a control glitch by power-cycling the dryer and then restarting a cycle. Start with the simple reset steps below; they solve most no-start and odd-behavior issues without replacing parts.

Quick reset steps (works for most control glitches)

• Turn the dryer OFF and unplug it (or switch the breaker OFF).
• Wait 2 to 5 minutes.
• Restore power.
• Open and close the door firmly.
• Select a normal timed cycle and press Start.

For model-specific control and cycle details, follow the steps in the WED5700AC1 owner's manual.

If the dryer still will not start after a reset

These checks target the most common “it has power but won’t run” causes:

• Confirm the door is fully closed; a failed door switch can prevent starting.
• Verify the breaker is fully reset (electric dryers often use a 2-pole breaker).
• Make sure the control is not in a delay or paused state.
• Try a timed dry cycle (it bypasses some sensor logic).
• If the drum light works but the motor will not run, inspect the belt and idler system.

Common parts related to no-start symptoms

Symptom	Likely area	Example part for WED5700AC1
Won’t start when door closes	Door interlock	Dryer door switch WP3406107
Hums but won’t tumble	Belt/idler/rollers	Dryer idler pulley W10837240
Runs but shuts off, then won’t restart	Overheat protection	Dryer thermal cut-off fuse kit 279973

Why it matters

A proper reset and quick checks help you avoid unnecessary part replacement and can also reveal airflow or overheating problems early, which improves drying performance and helps protect the heating circuit.

Last updated: January 2026

A Whirlpool electric dryer like the WED5700AC1 typically lasts about 13 years with normal household use and proper venting. Keeping airflow strong and replacing wear items (rollers, idler pulley, thermal fuse) on time helps you reach that lifespan.

What affects lifespan the most

• Vent restriction (long runs, crushed flex duct, lint buildup) that overheats the heater and safety fuses
• Overloading that strains the drive motor and drum support system
• Worn drum support parts that cause thumping, squealing, or belt wear
• Heat control issues (cycling problems) that increase stress on the heating circuit
• Moisture sensor buildup that leads to longer cycles and extra run time

Maintenance that adds years (and saves energy)

• Clean the lint screen every load; replace a damaged screen such as screen W10120998.
• Inspect and clean the exhaust ducting regularly; strong airflow prevents overheating.
• If you hear squealing or rumbling, service the drum support system early; common wear parts include the dryer drum support roller WPW10314173 and dryer idler pulley W10837240.
• If the dryer runs but won’t heat, check the heating safety devices and airflow; the dryer thermal cut-off fuse kit 279973 is a common fix when overheating has occurred.

Quick “repair vs. replace” guide

What you’re seeing	Most common cause	Typical fix
Loud rumble/thump	Worn rollers/shafts	Replace roller(s), inspect shafts
Squeal	Worn idler pulley	Replace idler pulley
Runs, no heat	Overheat fuse open or heater issue	Restore airflow, test/replace fuse or heater
Long dry times	Vent restriction or sensor issue	Clean venting, clean sensor bars

Why it matters

A dryer’s heater and safety fuses are designed to protect the appliance; restricted venting forces higher temperatures, which shortens the life of the heating element, thermistor, and thermal cut-offs. Following the maintenance and troubleshooting steps in the owner's manual helps keep the WED5700AC1 drying efficiently for its full service life.
