Kenmore 25328262804 freezer Parts

Kenmore upright freezer model 25328262804 is a 17.0 cubic foot freezer. Use this capacity when planning food storage, choosing baskets/shelves, and estimating energy use; it is the standard size reference for this specific Kenmore model.

Quick ways to verify you are matching the right model

Use these checks so you do not confuse 25328262804 with a similar 253.xxxxxxxx Kenmore freezer:

• Confirm the full model number on the rating label inside the cabinet (upright models are commonly on an interior wall).
• Match all digits exactly: 25328262804.
• Use the capacity for storage planning and organization zones (meats, vegetables, ready-to-eat).
• For feature details and operating instructions, use the 25328262804 owner's manual.

Capacity guide: what 17.0 cu. ft. means in practice

A 17.0 cu. ft. upright freezer is a mid-to-large household size that supports bulk shopping while still fitting typical garage or utility-room footprints.

Capacity	Category	Typical fit/use
12 to 14 cu. ft.	Small	Overflow storage, apartments
17.0 cu. ft.	Mid-to-large	Bulk groceries with organized shelving
19 to 21+ cu. ft.	Extra-large	Large families, long-term storage

Why it matters

Capacity affects how well cold air circulates. When an upright freezer is packed too tightly, airflow can be restricted, which leads to warm spots, longer run times, and more frost.

Helpful organization tip

For faster access and less door-open time, use tips for finding food in the freezer faster to set up zones and label bins.

Last updated: January 2026

Kenmore upright freezer model 25328262804 does not use a single dedicated “reset” button for normal operation. Instead, resetting is typically done by restoring power (unplugging briefly and plugging back in) and then re-setting the electronic temperature control inside the cabinet as described in the 25328262804 owner's manual.

What to try first (safe reset steps)

• Unplug the freezer (or switch off the circuit) for 5 minutes.
• Plug it back in and listen for the compressor and evaporator fan to start.
• Re-set the temperature using the inside control panel (UP for warmer, DOWN for colder on standard electronic controls).
• Allow several hours for the temperature to stabilize after any adjustment.
• If the red temperature alarm light is blinking and a buzzer sounds (deluxe electronic models), press ALARM OFF to silence the buzzer.

Which control type you have matters

Your 25328262804 may use an electromechanical knob or an electronic control inside the freezer. Use this quick check:

Control style	What you see	“Reset” approach
Electromechanical	A dial/knob inside the cabinet	Power-cycle, then re-set the knob and wait several hours
Standard electronic	UP and DOWN buttons inside	Power-cycle, then re-set with buttons and wait several hours
Deluxe electronic	Panel with alarm features	Power-cycle; use ALARM OFF for buzzer; re-set temp

Why it matters

A freezer that seems “stuck” often just needs a power-cycle and enough time to pull down temperature again. Frequent button pressing or rapid setting changes can delay stabilization and make troubleshooting harder.

When a “reset” does not fix it

If the freezer will not cool, keeps warming, or repeatedly alarms after a power-cycle, we focus on common cooling and defrost causes such as the defrost system or controls. For this model, parts often involved include the defrost timer 5304518034 and the defrost heater 5304496687.

Last updated: January 2026

The most common problems we see with the Kenmore 25328262804 upright freezer are warm temperatures, heavy frost buildup, unusual fan noise, and door sealing issues. These symptoms usually trace back to the defrost system, airflow components, or the door gasket; the owner's manual helps confirm normal operation and settings.

Common symptoms and what they usually point to

• Freezer not cold enough or warming up: evaporator fan not running, dirty condenser coil, control issue, or sealed-system problem
• Frost or ice building up on the back wall: defrost heater, defrost thermostat, or defrost timer not working
• Loud buzzing, clicking, or humming: evaporator fan motor noise, compressor start components, or vibration
• Door hard to close or frost around the door: worn gasket, misaligned hinge, or air leaks
• Water/ice at the bottom: drain restriction or drain tube icing

Parts commonly involved on this model

If your symptoms match, these are frequently checked or replaced on the 25328262804:

• Defrost timer 5304518034
• Defrost heater 5304496687
• Refrigeration appliance defrost bi-metal thermostat 297216600
• Freezer evaporator fan motor 297309000
• Freezer door gasket 5304507201

Quick checks we recommend before replacing parts

1. Verify the temperature control setting and allow 24 hours after any adjustment.
2. Make sure the door closes tightly; inspect the gasket for gaps, tears, or hardened spots.
3. Listen for the evaporator fan (inside) when the door switch is held closed.
4. Check for heavy frost on the evaporator cover; that strongly suggests a defrost-system issue.
5. Clean dust from the condenser area to improve heat removal.

Symptom-to-likely-cause guide

Symptom	Most likely area	Common next step
Warm temps, little/no airflow	Airflow/fan	Test/replace evaporator fan motor
Heavy frost, temps rise over days	Defrost system	Check heater, thermostat, timer
Frost around door perimeter	Door seal/hinge	Inspect gasket, adjust hinge
Clicking and not cooling	Start/compressor circuit	Inspect relay/overload, then compressor

Why it matters

Catching airflow or defrost problems early prevents food loss and reduces strain on the compressor. A small door air leak can also cause constant running, excess frost, and higher energy use.

Last updated: March 2026
