Samsung RH29H9000SR/AA-05 refrigerator Parts

The Samsung RH29H9000SR side-by-side refrigerator is a large-capacity model; the commonly listed total capacity is about 28.5 cu. ft. For the exact capacity and the fresh-food vs. freezer breakdown for your specific version, confirm it in the RH29H9000SR owner's manual.

What the manual does confirm (fit and clearance)

The manual provides model-family cabinet dimensions for RH29* units, which are the most important numbers when you are planning installation space.

Dimension (RH29* family)	Measurement
Depth “A”	35 1/8 in (893 mm)
Width “B”	35 7/8 in (912 mm)
Height “C”	68 1/2 in (1742 mm)
Overall height “D”	69 6/8 in (1774 mm)
Depth “E”	35 2/8 in (896 mm)

How to use cubic feet when comparing refrigerators

Capacity is helpful, but it does not tell the whole story. When comparing a 28.5 cu. ft. side-by-side to other refrigerators, focus on these practical factors:

• Side-by-side compartments are narrower; wide platters can be harder to fit than in a French door.
• In-door ice storage and the water filter system reduce usable space slightly.
• Shelf and bin layout can make two refrigerators with the same cu. ft. feel very different.
• “Total capacity” is different from “usable capacity” once shelves, drawers, and the ice bin are installed.

Related parts that affect usable space and performance

If you are trying to keep water and ice working well (and avoid losing storage to bulky add-ons), these model-matched parts are commonly replaced:

• Refrigerator water filter DA29-00019A (HAF-QIN/EXP)
• Samsung refrigerator ice container DA97-14263A

Why it matters

Knowing the true capacity helps you plan grocery storage, compare models fairly, and avoid installation surprises. The dimension chart in the manual is also the best reference for door swing and clearance planning.

You can order replacement parts for your Samsung RH29H9000SR from the parts list for this model, or search by model number on Sears PartsDirect.

Last updated: February 2026

To reset the ice maker on your Samsung RH29H9000SR side-by-side refrigerator, pull out the ice bucket and press and hold the ice maker Test button until you hear the refrigerator chime, then release. That chime confirms the ice maker reset and test cycle.

Reset steps (RH29H9000SR)

• Remove any glass from the dispenser area.
• Pull out the ice bucket/bin.
• Find the Test button on the right side of the ice maker.
• Press and hold Test until you hear the “ding-dong” chime.
• Release the button as soon as the chime sounds.
• Reinstall the ice bucket and let the ice maker run its cycle.

Control settings that can stop ice production

Your RH29H9000SR has an Ice Maker Off function on the control panel that turns ice production on or off. If ice is off, turn it back on before waiting for new ice.

• If the Ice Off indicator is lit, press Ice Maker Off briefly to turn ice back on.
• If the dispenser/panel is locked, press and hold the Ice Maker Off/Control Lock button for 3 seconds to unlock.
• Keep doors fully closed; an open door can prevent dispenser operation.

Quick reference table

Check	What it means	What to do
Test button chimes	Reset/test cycle started	Wait for the next harvest cycle
Ice Off indicator lit	Ice maker is turned off	Turn Ice Maker Off back on
Control Lock icon lit	Dispenser and panel buttons are locked	Hold Ice Maker Off/Control Lock 3 seconds

Why it matters

A proper reset forces a diagnostic cycle; it helps clear minor stalls and confirms the ice maker can cycle, so you can focus next on water supply, freezing, or a failed component.

If it still won’t make ice

• Dump clumped ice and make sure the bucket seats fully.
• Replace an overdue filter; restriction can reduce fill.
• If the ice maker won’t cycle after a reset, replace the ice maker.

For model-specific button locations and indicator meanings, use the RH29H9000SR owner's manual. For deeper troubleshooting, use why your Samsung fridge stopped making ice and how to fix it. Replacement options include the refrigerator ice maker DA97-14253A or refrigerator ice maker DA97-13415B. You can also search by model number on Sears PartsDirect.

Last updated: February 2026

For Samsung refrigerators like model RH29H9000SR, the most common problems we see are cooling performance issues (warm fridge or freezer, frost buildup) and ice maker or dispenser troubles. These are often tied to blocked air vents, defrost and drain issues, or water supply and filter-related restrictions; see the owner's manual for model-specific operating and care guidance.

Most common symptoms customers notice

• Fresh food section warms up while the freezer seems OK
• Frost or ice buildup that reduces airflow
• Ice maker stops producing ice or makes small/hollow cubes
• Water dispenser flow slows down
• Temperature swings after the doors are opened frequently

Quick checks that fix many “common problems”

1. Airflow: Keep food and bags from blocking interior vents and cold air outlets.
2. Water supply: Confirm the refrigerator is connected to a potable water supply and that supply pressure is in the typical operating range (many Samsung units call for 20 to 125 psi).
3. Filter restriction: If water flow is weak or ice production is slow, replace the filter on schedule and flush water after replacement.
4. Door sealing: Make sure doors close fully and aren’t held open by overpacked bins.
5. Power reset: If you unplug the refrigerator, wait at least 5 minutes before plugging it back in.

Parts that commonly relate to these issues

If troubleshooting points to a restriction, leak, or dispenser issue, these model-matched parts are commonly involved:

Problem area	What it affects	Example part for RH29H9000SR
Water filtration	Slow water flow, poor ice fill	Refrigerator water filter DA29-00019A
Ice production	No ice, irregular ice harvest	Refrigerator ice maker by Samsung DA97-13415B
Drain/defrost water handling	Water under drawers, ice buildup from poor drainage	Refrigerator drain tube kit DA97-04049E
Airflow control	Warm spots, uneven temps	Samsung refrigerator air damper control assembly DA97-13749D

Why it matters

Cooling and ice maker complaints usually start as airflow or water-flow restrictions. Fixing those early helps prevent food spoilage, reduces frost buildup, and keeps the ice maker cycling normally.

Ordering the right parts

We list RH29H9000SR-COMPATIBLE parts on this model page; for broader model lookups and ordering, use Sears PartsDirect.

Last updated: February 2026
