Can I look up Frigidaire parts by model number?
Yes. Looking up parts by model number is the most accurate way to get compatible replacement parts for your Frigidaire electric range model FGEF3035RFB, because it filters results to the exact version of your range and its component revisions.
For Frigidaire ranges, the model and serial tag is typically on a frame area you can see when you open the oven door, or around the storage drawer opening on freestanding models. Use the full model number exactly as printed.
- Check the oven door frame (open the door and look along the front frame)
- Check the storage drawer jamb area (pull the drawer out and look at the frame)
- Write the model number and serial number exactly (letters and numbers)
- Use the full suffix (for example, FGEF3035RFB, not a shortened version)
Reference the identification and service info section in the FGEF3035RFB owner's manual for the most reliable location details.
Searching by FGEF3035RFB helps you match parts for common repairs like heating problems, burner issues, and control failures.
| What is failing | Common part type to check | Example part for this model |
|---|---|---|
| Oven not heating or overheating | Oven temperature sensor | Range oven temperature sensor 316490000 |
| Bake not working | Bake element | Frigidaire range bake element 316505500 |
| Broil not working | Broil element | Frigidaire range broil element 316203301 |
| Burner won’t regulate heat | Surface element control switch | Frigidaire range surface element control switch 316238201 |
Model-number lookup prevents ordering a part that looks right but has different terminals, mounting points, or electrical ratings. That is especially important on an electric range where wiring connections and fit must be correct.
If you are moving the range to access wiring or replace components, reinstall the anti-tip bracket and follow the electrical connection requirements in the FGEF3035RFB installation guide.
Last updated: February 2026
How do I reset my Frigidaire electric range?
To reset your Frigidaire FGEF3035RFB electric range, turn the range off and disconnect power for about 30 seconds, then restore power. If the oven and all surface burners still do not heat afterward, focus on the power supply and terminal block wiring.
- Turn all oven and surface controls to OFF.
- Unplug the range, or switch OFF the range breaker.
- Wait 30 seconds.
- Restore power.
- Set the clock and test Bake and one surface element.
A full no-heat condition on an electric range usually points to a power or wiring problem, not a “stuck” control. The installation instructions for this model emphasize correct power cord connections and secure terminal block nuts.
- Confirm the breaker is a 2-pole range breaker and fully reset it (OFF then ON).
- Verify the wall receptacle type matches the cord setup (3-wire vs 4-wire).
- Inspect the terminal block area for loose or overheated connections.
- Do not loosen the factory-installed nuts that secure the range wiring to the terminal block.
- If you see melted wiring, stop and have the connection repaired.
| Installation type | Typical receptacle | Key point |
|---|---|---|
| 4-wire (new/remodel, mobile home) | 14-50R | Ground strap is disconnected; ground wire attaches to chassis |
| 3-wire (existing only) | 10-50R | Ground strap remains unless local codes require separate ground |
For the exact connection method and safety notes, follow the installation guide.
If the range powers up and heats but baking seems inaccurate, the oven temperature sensor can be a likely cause. For this model, the Frigidaire range oven temperature sensor 316490000 is the sensor used to monitor oven temperature.
A proper reset clears minor control glitches, but correct 240V power and secure terminal block connections are what make the bake element, broil element, and radiant surface elements heat normally.
Last updated: February 2026
How do I tell what model my Frigidaire stove is?
Your Frigidaire stove’s model number is printed on a rating label on the appliance, and it’s the fastest way to match the correct parts and instructions for your range. On most Frigidaire electric ranges like model FGEF3035RFB, the label is found around the oven door opening or on the storage drawer area.
Check these common spots first (use a flashlight and look for a sticker or metal plate):
- Along the oven door frame when you open the oven door
- On the front frame behind the storage drawer (pull the drawer out)
- On the lower front frame near the warming drawer area (if equipped)
- On the side trim or frame near the oven opening
- On the back panel (less common, but worth a quick check)
The model number is usually a mix of letters and numbers (example: FGEF3035RFB). Write it down exactly as shown.
- Watch for look-alikes like 0 (zero) vs O (letter O)
- Include any suffix letters at the end
- Copy dashes only if they appear on the label
| Label item | What it’s used for | Example |
|---|---|---|
| Model number | Identifies the exact range design | FGEF3035RFB |
| Serial number | Production tracking and date info | Varies |
| Electrical rating | Confirms voltage/amps for installation | Varies |
We use the model number to ensure parts fit and function correctly. For example, the correct oven temperature sensor and control board can vary by model series, even when ranges look the same.
If you’re installing or moving the range, the model number also helps you follow the correct clearances, electrical connection requirements, and anti-tip bracket steps in the FGEF3035RFB installation guide.
Last updated: February 2026
