Kenmore 79551036010 refrigerator Parts

Kenmore side-by-side refrigerator model 79551036010 is in the Kenmore 795.5103 model series, but the cubic-foot capacity is not listed in the manual excerpts we have for this model. Most Kenmore 795-series side-by-side refrigerators are typically about 20 to 26 cu. ft., depending on the exact configuration and trim.

How to find the exact cubic feet for 79551036010

We use the capacity listed on the model rating label or in the full specifications section of the documentation.

• Check the model and serial label inside the fresh food compartment (commonly on the right-hand side wall).
• Look for wording like “Capacity”, “Total volume”, or “cu. ft.”
• If your label lists liters (L), convert to cubic feet.
• Use the model series information in the 79551036010 owner's manual to confirm you are matching the correct 795.5103 variant.

Quick conversion (liters to cubic feet)

If the label shows	That equals about
566 L	20.0 cu. ft.
623 L	22.0 cu. ft.
708 L	25.0 cu. ft.

Why it matters

Knowing the cubic-foot capacity helps us match the right refrigerator parts and accessories (like shelves, bins, and water system components) and it also helps when comparing cooling performance expectations for a side-by-side layout.

Related parts that often depend on the exact model configuration

Even within the same 795.5103 family, internal layouts can vary. If you are replacing water or dispenser components, match by model number and diagram:

• Refrigerator water tank MJM61904702 (water reservoir inside the cabinet)
• Refrigerator door gasket 4987JJ1010M (helps prevent warm air leaks)
• Refrigerator air damper ADJ74092101 (controls airflow between compartments)

Last updated: February 2026

For Kenmore model 79551036010, replacing the ice maker is mainly a remove-and-swap job: disconnect power, remove the ice bin and mounting screws, transfer any matching brackets/stripper from the old unit, reconnect the wiring, then turn the ice maker back ON and allow time to start producing ice. See the 79551036010 owner's manual for your model’s exact access and switch locations.

Before you start (safety and prep)

• Unplug the refrigerator before touching the ice maker wiring.
• Empty the ice bin so you can access the ice maker area.
• Turn the ice maker power switch to OFF (O) before removal.
• Protect floors and shelves; ice and water can spill during service.
• Keep hands clear of the ejector mechanism and heater area when the unit is powered.

Replacement steps (typical side-by-side process)

1. Shut off power: unplug the refrigerator.
2. Remove the ice bin: pull it out to expose the ice maker.
3. Remove the ice maker assembly:
   • Take out the mounting screws.
   • Lift the ice maker off its mounting points.
4. Disconnect the harness: unplug the ice maker wiring connector.
5. Transfer parts if needed: move any identical bracket/stripper pieces from the old ice maker to the new one (only if they match exactly).
6. Install the new ice maker: hang it on the mounts, reinstall screws, reconnect the harness.
7. Restore operation:
   • Plug the refrigerator back in.
   • Set the ice maker power switch to ON (I).

What to expect after installation

A newly installed ice maker often needs time to cool down and cycle.

Item	Normal expectation
First ice after install	12 to 24 hours
Ice maker operating temp	15°F (-9°C) or below
Typical production	About 100 cubes per 24 hours (varies)

Quick checks if it is not making ice

• Confirm the freezer is cold enough (target 0°F; ice maker needs 15°F or below to run).
• Make sure the ice maker power switch is ON (I).
• Verify the water supply is connected and turned on; low water pressure can cause small cubes.
• If you hear the fill valve buzzing with no water connected, switch the ice maker OFF (O) to prevent damage.

Why it matters

Correct installation and startup prevents stripped mounts, pinched wiring, and ice maker damage from running without water. It also helps you avoid “no ice” complaints that are really temperature or water-supply issues.

Last updated: February 2026

The most common problems we see on Kenmore refrigerators like model 79551036010 are cooling issues (often airflow or dirty condenser coils), water leaks (typically a drain or water-line issue), ice maker and dispenser troubles, and unusual noises from fans or an unlevel cabinet. For model-specific operating checks, use the 79551036010 owner's manual.

Common symptoms and what usually causes them

• Not cooling or weak cooling: dirty condenser coils, blocked vents, evaporator fan or airflow problems, or defrost-related ice buildup
• Runs too much: frequent door openings, warm room temperature, dirty condenser coils, doors not sealing fully
• Water under the refrigerator: defrost drain issues, water line connection leaks, or condensation in humid conditions
• Ice tastes bad or smells: old ice, unwrapped food odors, mineral-heavy water, or a filter that needs replacement
• Rattling or vibration: refrigerator not level or not resting solidly on the floor

Quick checks we recommend first (fast, no parts)

1. Confirm cooling is actually enabled: Demo Mode can leave lights and the display working while cooling is off. The manual shows how to disable Demo Mode by pressing specific buttons together.
2. Check door closure and sealing: push doors firmly shut; rearrange bins and food packages that block closure.
3. Clean condenser coils: dirty coils reduce heat transfer and make the compressor work harder.
4. Level the refrigerator: an unlevel cabinet can cause vibration, noise, and door-closing problems.
5. Address ice and water quality: discard old ice, clean the bin, and replace the water filter on schedule.

Parts that commonly relate to these problems (for 79551036010)

Symptom	Part that may be involved	Example from this model’s parts
Ice not dispensing or auger not turning	Auger motor	Refrigerator auger motor EAU59551204
Water tastes or smells off	Filter system and water path	Refrigerator water tank MJM61904702
Door not sealing, moisture, warm spots	Door gasket	Refrigerator door gasket 4987JJ1010M

Why it matters

Most “big” refrigerator complaints trace back to airflow, sealing, or maintenance. Fixing door closure, leveling, and coil cleanliness helps stabilize temperatures, reduces run time, and prevents ice maker and odor issues.

Last updated: February 2026

On Kenmore side-by-side refrigerator model 79551036010, the model and serial number are printed on an identification label inside the fresh food (refrigerator) compartment, on the right-hand side wall. Use that label anytime you’re matching parts or checking specifications in the 79551036010 owner's manual.

How to find it quickly

• Open the refrigerator (fresh food) door, not the freezer door.
• Look along the right interior wall of the refrigerator compartment.
• Check near the front edge where the door gasket seals.
• Use a flashlight; the label can be easy to miss in low light.
• Write down both the model number and serial number exactly as shown.

What the label helps you do

The identification label is the fastest way to confirm you have the correct model when ordering parts or troubleshooting issues like cooling problems, water dispenser leaks, or ice maker failures.

You need to do	Use this from the label	Why it matters
Order the right replacement part	Model number (79551036010)	Ensures exact fit and compatibility
Check production details	Serial number	Helps match revisions and configurations
Use the correct procedures	Model number	Matches the right instructions and diagrams

Why it matters

Kenmore refrigerators often share similar styling across model families, but internal components (like the dispenser system, control boards, or water line routing) can differ. Confirming the model number prevents ordering the wrong part and reduces repeat repairs.

Last updated: February 2026
