Kenmore 58714013410B dishwasher Parts

Yes. You can still get replacement parts for Kenmore dishwashers, and for Kenmore model 58714013410B many common repair parts are currently available, such as the drain pump, water inlet valve, door seal, and heating element. Use the full model number to match the correct part.

Best way to find the right part for 58714013410B

We recommend matching by model number first, then confirming the part name and ID before ordering.

• Use the exact model number: 58714013410B
• Match the symptom to the system (drain, fill, heat, leak)
• Compare the part name and part ID, not just a photo
• If you are installing or reconnecting the dishwasher, follow the grounding and anchoring steps in the 58714013410B installation guide

Common parts people replace (and what they fix)

Here are examples of parts available for this model and the problems they typically solve:

Symptom	Likely system	Example part for this model
Won’t drain, standing water	Drain system	Drain pump a A00126401 or drain hose
Won’t fill or fills slowly	Water supply/fill	Water inlet valve
Leaks at the door	Door sealing	Door seal
Dishes not drying well	Heating circuit	Heating element

Quick checks before you order

These checks help avoid buying the wrong part and can reveal a simple fix.

• Confirm the dishwasher has power and a proper 120V grounded supply (per the installation instructions)
• Check for kinked drain or water hoses (kinks can cause fill and drain issues)
• If connected to a garbage disposer, make sure the disposer inlet plug has been knocked out
• Flush the water line before final connection to help prevent clogging the inlet valve screen
• Make sure the dishwasher is level and anchored; poor leveling can affect performance and door sealing

Why it matters

Kenmore dishwashers are often built with widely supported components, so parts availability stays strong for common repairs. Using the exact model number and installation guidance helps ensure the replacement fits and the dishwasher operates safely and reliably.

Last updated: February 2026

The Kenmore dishwasher model 58714013410B is a standard built-in size designed to fit a 24-inch-wide cabinet opening. For a correct fit, we match the dishwasher to your cabinet opening height and depth using the measurements and adjustment chart in the 58714013410B installation guide.

What “size” means for fit

Dishwasher sizing is mainly about the cabinet opening and connection clearances, not just the outside shell. For 58714013410B, the installation instructions focus on:

• Width: standard 24-inch class built-in opening
• Height: adjustable leveling legs to match common countertop-to-floor openings
• Depth/clearance: space for the door to open and for routing the drain hose, water line, and wiring

Key measurements to check before you buy or install

Measure your opening and compare it to common built-in dishwasher requirements.

• Measure opening width (side-to-side) at the front and back
• Measure opening height from underside of countertop to finished floor
• Measure opening depth to ensure the unit sits back without pinching hoses
• Confirm you have access to hot water, drain, and 120V power near the sink base
• Plan routing so water, drain, and electrical do not cross in front of the motor/frame

Typical built-in dishwasher opening (quick reference)

These are the common targets most 24-inch built-in dishwashers (including Kenmore models like 58714013410B) are designed around.

What you measure	Typical target	What to do if it’s off
Opening width	~24 in.	Adjust cabinetry only if needed; do not force the tub into a tight opening
Opening height	~34 to 35 in.	Use leveling legs; follow the leg adjustment chart
Electrical	120V, 15 to 20A	Use a dedicated circuit sized correctly

Why it matters

Correct sizing prevents door interference, vibration, leaks from kinked hoses, and installation issues like an unlevel tub (which can affect wash performance and draining). If you are replacing an older unit, verifying the opening is especially important because utility locations vary by age and model.

Last updated: February 2026

Yes, repairing a Kenmore dishwasher like model 58714013410B is usually worth it when the fix is a common wear item (seal, hose, valve) or a straightforward service issue. Replacement makes more sense when multiple major components are failing or the repair cost approaches the price of a new unit.

Quick decision checklist

• If the dishwasher is under 10 years old, repairs are typically the better value.
• If the problem is a leak, drain issue, or poor cleaning, repairs are often cost-effective.
• If you need a major electrical or control repair, compare total cost to replacement.
• If the tub is damaged or heavily corroded, replacement is usually the better path.
• If you can do safe DIY work (basic disassembly, hose/valve swaps), you can save significantly.

Common repairs that are usually “worth it”

These are frequent fixes on dishwashers in this class and often restore full performance:

• Leaks at the door: replace the dishwasher door seal 809006501
• Not draining or draining slowly: check/replace the drain pump a A00126401 or clear the drain path
• Fill problems (won’t fill, fills slowly): replace the dishwasher water inlet valve 154637401
• Standing water or siphoning issues: inspect/replace the drain hose 807117001

Cost-to-replace comparison (rule of thumb)

Scenario	Typical recommendation	Why
One part failure, no other symptoms	Repair	Lowest cost, fastest return to service
Two or more major symptoms (leak + no drain + won’t start)	Compare totals	Multiple parts and labor add up quickly
Major electrical work needed	Compare totals	Higher labor time and troubleshooting cost

Why it matters

A targeted repair keeps your 58714013410B running reliably and avoids the cost and hassle of replacement. It also prevents secondary damage, for example a small leak that turns into cabinet or flooring issues.

Installation and safety notes that affect repair value

From the installation guide, we recommend:

• Disconnect power at the breaker before servicing.
• Do not use an extension cord.
• After any water-related repair, turn on the supply and check carefully for leaks.

Last updated: February 2026

Your Kenmore dishwasher model number is printed on the appliance’s identification label, most often along the inner door frame or on the tub rim when you open the door. For parts and troubleshooting, match that label exactly to your model (for example, 58714013410B).

Where to look on the dishwasher

Check these spots in order (they are the most common locations):

• Inner door frame (left or right side) when the door is open
• Top edge of the door or the tub opening (around the rim)
• Side wall of the tub near the front
• Behind the lower kickplate or toe panel (near the floor)
• On the side of the cabinet frame if the unit is pulled out slightly

What to write down (and why)

Record the full model number and serial number exactly as shown (including any letters at the end). That last letter or suffix can change which parts fit.

Quick checklist

• Copy the model number character-for-character
• Copy the serial number character-for-character
• Take a clear photo of the label for reference
• Use the model number when ordering parts like a door seal, drain hose, or water inlet valve

Common label formats you might see

Kenmore dishwashers can show different model number patterns. Here are typical examples:

What you see on the label	What it means for parts lookup
587.14013410B (or similar)	Use the full number including the suffix
665.xxxxxxxx	Different Kenmore platform; still use the full number
A long number with letters	Letters matter; they can indicate a revision

Why it matters

We use the exact model number to match the correct diagrams, wiring, and fit-tested parts. Even small differences can affect compatibility for items like the dishwasher door seal 809006501 or the drain hose 807117001.

Helpful next step

If you are also confirming installation details (electrical supply, drain routing, leveling legs, and cabinet opening height), use the installation guide.

Last updated: February 2026
