Kenmore Elite 79551867611 refrigerator Parts

Kenmore Elite refrigerator model 79551867611 does not use one single, universal “reset button” for the whole unit. Instead, it has specific reset functions, such as the water filter reset on the control panel; you press and hold it for about 3 seconds after replacing the filter (see the 79551867611 owner's manual).

What you can reset on this model

Here are the most common “reset” actions customers mean on a Kenmore Elite side-by-side like 79551867611:

• Water filter indicator: press and hold Filter Reset for about 3 seconds after changing the filter.
• Accela Ice: press and hold the Ice Maker button for about 3 seconds to turn the 24-hour boost on or off.
• Control glitch after a power event: a full power cycle (unplug, wait, plug back in) often restores normal operation.
• Door alarm: on this model, the door alarm is activated when power is connected and is not designed to be turned off.

Quick steps: water filter reset (most common “reset button”)

1. Replace the filter.
2. Press and hold Filter Reset for about 3 seconds.
3. Confirm the filter light/indicator returns to normal.

If you are replacing the filter itself, use the correct fit for this model, such as Kenmore refrigerator water filter 9490 ADQ73613402.

Power cycle reset (when the display or cooling acts “stuck”)

Use this when the control panel is unresponsive or the refrigerator seems to be in a temporary fault state.

• Unplug the refrigerator (or switch off the breaker).
• Wait 5 minutes.
• Plug back in (or turn breaker on).
• Allow 24 hours for temperatures to fully stabilize after any reset or power interruption.

Common “reset” options at a glance

What you’re trying to fix	What to do	What to expect
Filter light is on	Hold Filter Reset ~3 seconds	Filter indicator clears
Need more ice fast	Hold Ice Maker ~3 seconds (Accela Ice)	Boost runs up to 24 hours
Display/control acting odd	Power cycle 5 minutes	Control often recovers

Why it matters

Using the correct reset prevents repeat issues like a filter light that never clears, reduced water flow, or ice production that does not match your settings. It also helps you avoid replacing parts that are still working.

Last updated: February 2026

Your Kenmore Elite side-by-side refrigerator model 79551867611 has a total capacity of 28.3 cubic feet. You can confirm the exact total and any compartment breakdown in the specifications section of the 79551867611 owner’s manual.

Where to verify capacity on the refrigerator

Use these quick checks to match the capacity to your exact unit:

• Open the 79551867611 owner’s manual and look for the Specifications or Product data section.
• Check the model and serial label inside the fresh food compartment to confirm the full model number.
• If the manual lists a family such as 795.5186*, match your full model (including any color code) to the correct spec line.
• Remember: cubic feet is interior volume, not the outside dimensions.

Capacity at a glance

Item	Value
Refrigerator type	Side-by-side
Total capacity	28.3 cu. ft.

Why it matters

Capacity affects how the refrigerator is configured inside (shelves, bins, air ducts) and helps ensure you choose compatible maintenance items. For example, this model uses a specific water filter design such as the Kenmore refrigerator water filter 9490 ADQ73613402.

Last updated: February 2026

Yes. Kenmore Elite is Kenmore’s premium line, and the Kenmore Elite side-by-side refrigerator model 79551867611 is built and supported like a higher-end appliance, with a longer limited warranty structure that includes extended coverage on the sealed refrigerant system and the linear compressor (details in the 79551867611 use and care guide).

What “high end” means for Kenmore Elite

Kenmore Elite typically sits in the mid-to-high range for features and build compared to standard Kenmore models. For owners, that usually shows up as:

• More feature-focused designs (ice and water dispensing, filtration, door storage options)
• Higher parts complexity (more motors, valves, controls, and sensors)
• More emphasis on long-term system coverage (sealed system and compressor)
• Higher replacement-part costs for major components (compressor, control board, evaporator)
• Better fit and finish than entry-level models

Quick comparison: Kenmore vs Kenmore Elite (typical)

Category	Standard Kenmore	Kenmore Elite
Feature set	Basic to moderate	Moderate to premium
Repair complexity	Lower	Higher
Major component costs	Lower	Higher
Warranty structure	Basic coverage	Often includes extended system/compressor coverage

Why it matters when buying parts or troubleshooting

A “high-end” refrigerator like the Kenmore Elite 79551867611 often performs best when maintenance items are kept current and water/ice components stay clean and leak-free. That helps protect expensive systems and reduces nuisance issues.

Parts that commonly affect performance

If you are diagnosing water, ice, or cooling complaints, these model-matched parts are frequent checkpoints:

• Kenmore refrigerator water filter 9490 ADQ73613402 (taste/odor, flow, ice quality)
• Refrigerator water inlet valve (water supply to dispenser and ice maker)
• Ice maker and auger components (ice production and dispensing)
• Electronic control board (cooling logic and system control)

Practical tips to keep it running like a premium unit

• Replace the water filter on schedule to maintain flow and ice quality.
• Keep door seals clean and sealing tightly to prevent temperature swings.
• Avoid overpacking vents; airflow problems mimic cooling failures.
• If water flow slows, check the filter first, then the supply line and inlet valve.

Last updated: February 2026

Common problems on the Kenmore Elite 79551867611 side-by-side refrigerator are no cooling or weak cooling (often after a move, during defrost, or if Demo Mode is on), slow water dispensing from an exhausted filter, ice maker underproduction from warm freezer temps or doors not sealing, and moisture or freezing issues caused by airflow and door-opening habits. See the 79551867611 owner's manual for model-specific troubleshooting and diagnostics steps.

Most common symptoms and what usually causes them

• Refrigerator and freezer not cooling: power cord unplugged, Demo Mode enabled, unit in defrost cycle, or not enough time after installation (up to 24 hours).
• Ice maker not making enough ice: freezer set too warm (target 0°F), doors opened often, or doors not fully closed.
• Water dispensing slowly: water filter is exhausted; replace the filter and purge air from the line.
• Food freezing in fresh food section: items with high water content placed near an air vent, or temperature set too cold.
• Condensation or frost: frequent door openings, uncovered food, or humid air entering through a poor door seal.

Quick checks we recommend first (fast, no tools)

1. Confirm the unit is plugged into a live outlet.
2. Make sure Demo Mode is off (lights can work while cooling is disabled).
3. After a power outage or move, allow 30 minutes after defrost and up to 24 hours after installation for temps to stabilize.
4. Set temperatures to typical targets: 0°F freezer, 37°F refrigerator.
5. Check that doors close fully and vents are not blocked by food packages.

Parts that commonly solve ice and water complaints

Symptom	Most likely part to check/replace	Notes
Slow water at dispenser	Kenmore refrigerator water filter 9490 ADQ73613402	Replace when flow drops; then flush several glasses of water.
No ice or weak ice production	Refrigerator water inlet valve AJU34125555	A weak valve can limit water fill to the ice maker.
Ice issues at dispenser	Refrigerator ice maker and auger motor assembly EAU61004410	Helps when auger drive or ice delivery is failing.

Why it matters

Cooling, ice, and water problems often trace back to settings (Demo Mode, temperature), airflow (blocked vents), or water supply components (filter, inlet valve). Fixing the root cause protects food safety, improves ice production, and reduces strain on the sealed system.

Last updated: February 2026

A Kenmore Elite refrigerator typically lasts 10 to 15 years under normal household use. For your Kenmore Elite 79551867611 side-by-side, consistent maintenance (especially airflow, clean coils, and good door sealing) is what most often determines whether it reaches the high end of that range.

What affects lifespan the most

• Condenser cleanliness and airflow: dust buildup makes the cooling system run longer.
• Door gasket condition: air leaks force longer run times and create frost issues.
• Ice maker and dispenser use: heavy use increases wear on moving parts.
• Water quality and filter changes: reduces clogs and valve strain.
• Stable temperatures: frequent door openings and hot food loads increase compressor run time.

Maintenance checklist (best return for the effort)

Use these habits to extend the life of a side-by-side like model 79551867611:

• Vacuum and brush the condenser area regularly (and keep rear clearance open).
• Keep doors closing squarely; clean and condition the gasket sealing surface.
• Replace the water filter on schedule; a restricted filter can reduce water flow.
• Avoid overpacking; blocked vents reduce cooling efficiency.
• After moving the refrigerator, keep it upright before powering it on (the manual notes a 24-hour upright rest if it was moved on its side).

Common wear items vs. long-life components

Item	Typical role	What you notice when it’s wearing out
Water filter	Improves taste and protects water system	Slow dispenser flow, odd taste/odor
Door gasket	Keeps cold air in	Frost, sweating, warm spots, longer run time
Compressor	Drives cooling	Warm fridge/freezer, constant running, clicking

Parts that often come up in “older fridge” repairs

If performance drops as the unit ages, these model-matched parts are commonly involved:

• Kenmore refrigerator water filter 9490 ADQ73613402
• Refrigerator water inlet valve AJU34125555
• Refrigerator condenser coil ACG73748502

Why it matters

Once a refrigerator is past the 10-year mark, small efficiency losses (dirty coils, weak door seal, restricted water flow) can add up to higher run time and more strain on the sealed system. Preventive care helps you avoid nuisance failures and keeps temperatures stable.

For model-specific care, operating tips, and troubleshooting steps, use the 79551867611 owner’s manual.

Last updated: February 2026

Water leaking from your Kenmore Elite side-by-side refrigerator model 79551867611 is typically caused by a clogged defrost drain (defrost water overflows), a leak in the dispenser water tubing or fittings, or a seep at the water inlet valve or supply connection. Start by locating where the water appears.

Quick checks (fastest way to narrow it down)

• Water under crisper drawers: defrost drain backup or ice blockage.
• Water at the dispenser or down the freezer door: tubing or fitting leak.
• Water behind the refrigerator: supply line connection or inlet valve seep.
• Drips after changing the filter: filter not fully seated or housing O-ring issue.
• If the water line is not connected, keep the ice maker OFF (noted in the 79551867611 owner's manual).

What to inspect and what to do

Defrost drain area

• Look for standing water or a sheet of ice under the bottom drawers.
• Melt visible ice; then flush the drain area with warm (not boiling) water.

Dispenser tubing and fittings

• Check for cracked tubing, loose push-in connections, or kinks.
• If your unit uses a quick-connect, inspect the refrigerator water tube fitting 4932JA3002C for a hairline crack or a connection that is not fully seated.

Inlet valve and supply line

• Inspect the valve area for wetness or mineral tracks.
• A slow seep often points to the refrigerator water inlet valve AJU34125555.

Common leak locations

Where you see water	Most likely cause	First action
Under drawers	Defrost drain clog	Clear ice, flush drain
At dispenser	Tubing or fitting leak	Reseat connections, inspect tubing
Back of unit	Supply or inlet valve seep	Tighten fitting, inspect valve

Why it matters

Stopping the leak quickly prevents floor damage and reduces the chance of ice buildup and airflow problems that can affect cooling.

Last updated: February 2026
