Kenmore 79095033503 electric range Parts

For the Kenmore 79095033503 electric range, the exact oven size (capacity in cubic feet) and the appliance’s exterior dimensions are listed in the product literature for this model. Use the 79095033503 owner's manual to confirm the precise measurements for your specific installation.

What “size” usually means for an electric range

When customers ask for oven “size,” it typically refers to one of these:

• Oven capacity (cubic feet)
• Exterior width (most are about 30 inches)
• Overall height (varies with leveling legs)
• Depth (varies with door closed and handle)
• Cutout/clearance needs (space around the range)

How to find the correct size for your exact unit

We recommend pulling the dimensions from the model-specific documents and then measuring your range to confirm.

• Check the model and serial tag location described in the 79095033503 owner's manual (behind the lower panel or in the storage drawer area).
• Use the 79095033503 installation guide for clearance and placement requirements.
• Measure your range at home (width, height, depth) and compare to the document specs.
• If you are replacing an older range, measure the opening and nearby cabinets, not just the old unit.

Quick measurement checklist (at home)

• Width: side panel to side panel
• Height: floor to cooktop surface (after leveling)
• Depth: back to front with door closed (note handle projection separately)

Measurement	What to include	Why it matters
Width	cabinet-to-cabinet space	fit between counters
Height	leveling legs set position	align with countertop
Depth	door closed plus handle note	walkway and door swing

Why it matters

Correct sizing prevents installation problems like a range that sits proud of the countertop, a door that hits nearby cabinetry, or inadequate clearance for safe ventilation and heat protection.

Last updated: January 2026

On Kenmore electric range model 79095033503, the model and serial number are printed on an identification (serial) plate located on the right side of the oven front frame, inside the storage or warmer drawer compartment. The quickest way to see it is to pull the lower drawer out.

How to find the label on model 79095033503

• Turn the oven off and let it cool completely.
• Pull the storage (or warmer) drawer straight out.
• Look at the right side of the oven front frame (the frame around the oven opening).
• Find the identification plate with the model and serial numbers.
• Write both numbers down for parts lookup and service.

What you should see on the plate

Most Kenmore 790-series ranges list the key details in a simple block like this:

Label item	What it’s used for
Model number	Matching parts and diagrams to your exact range
Serial number	Identifying production details for service history
Date of purchase (your record)	Warranty and maintenance tracking

For the exact illustrated location and wording used for your range, check the 79095033503 owner’s manual.

Why it matters

Using the correct model number prevents ordering the wrong bake element, oven probe, control overlay, or surface element switch. Even small model-number differences can change wiring, fit, and compatibility.

Last updated: January 2026

To reset a Kenmore electric range model 79095033503, turn the range off, then restore power by switching the circuit breaker off for 1 minute and back on. After power returns, reset the clock and any oven function as shown in the 79095033503 owner's manual.

Quick reset steps (most common)

• Turn all surface knobs to OFF.
• If the oven is running, press CANCEL/OFF.
• At your home electrical panel, switch the range breaker OFF.
• Wait 60 seconds.
• Switch the breaker ON.
• Set the clock, then test BAKE for a few minutes.

If the reset is for a power outage

The manual notes that if power fails, the range can begin operating again when power resumes if it was not turned off. Once power is restored, you should reset the clock and oven function.

What to do right after power returns

• Confirm all knobs are OFF
• Press CANCEL/OFF to clear the control
• Reset the clock
• Re-enter your desired cooking mode (BAKE, BROIL, TIMER)

When a reset does not fix the problem

A reset clears many temporary control glitches, but it will not fix a failed part (like a temperature sensor, control board, or surface switch).

Symptom after reset	Most likely area to check	Example part for this model
Oven will not heat	Heating circuit, element, sensor	Oven bake element 316225001
Oven temperature is inaccurate	Calibration or sensor	Oven probe 316233903
Display dead or erratic	Electronic control	Frigidaire range oven control board 316455420

Why it matters

Resetting the control restores normal operation after a power interruption and helps you confirm whether you have a simple control lockup or a true component failure. It also ensures the clock and cooking functions are set correctly for safe, predictable baking.

Last updated: January 2026
