Kenmore 25364522404 refrigerator Parts

The Kenmore top-mount refrigerator model 25364522404 is typically about 32 inches wide, 65-3/4 inches tall, and 26-5/8 inches deep. For the exact cabinet and clearance measurements to use in your kitchen opening, confirm the dimensions in the 25364522404 owner's manual.

Dimensions and fit checklist

Use these steps to make sure the refrigerator fits and can be installed correctly:

• Measure the opening width, height, and depth at multiple points (front and back).
• Plan for door swing clearance so the doors can open fully without hitting a wall.
• Leave airflow space around the cabinet (especially behind and above) per the manual.
• Confirm the path into the kitchen (doorways, hallways, turns) before delivery.
• If you have an ice maker hookup, confirm you can route a 1/4-inch water line to the back.

Quick reference table

Measurement	Approximate size
Width	32 in.
Height	65-3/4 in.
Depth	26-5/8 in.

Why it matters

Correct sizing prevents installation problems like doors that cannot open fully, poor ventilation that can reduce cooling performance, and water line or power cord strain. The manual also helps you plan for required clearances and utility connections.

Last updated: January 2026

On the Kenmore 25364522404 top-mount refrigerator, the upper section is the freezer compartment. It’s the coldest area of the appliance; it keeps foods frozen and also helps drive cold-air circulation that supports fresh-food cooling.

What the freezer compartment does

• Freezes and stores food long-term at a stable, low temperature
• Provides a cold-air source that circulates through the refrigerator section
• Often houses the ice maker (if your model is equipped) and freezer door bins
• Helps overall efficiency when the door seals tightly and airflow is not blocked

Quick terminology guide

What you see	Common name	What it means
Upper section on a top-mount unit	Freezer compartment	The frozen-food area above the fresh-food section
Lower section	Fresh-food compartment	The refrigerated area for everyday foods
Door shelves in upper section	Freezer door bins	Storage on the freezer door (warmer than interior)

Tips for best performance (freezer and fresh-food)

These habits help the freezer stay cold and keep temperatures consistent throughout the refrigerator:

• Leave space between packages so cold air can circulate.
• Avoid overloading the freezer with warm food at one time.
• Store temperature-sensitive frozen items (like ice cream) toward the freezer interior, not the door.
• Keep the refrigerator level so doors close tightly.
• Do not block the toe grille; airflow is essential for proper operation.

Why it matters

When you know the freezer compartment is the “upper part,” it’s easier to troubleshoot cooling complaints (warm refrigerator, frost buildup, poor airflow) because many common causes start with freezer airflow, loading, or door sealing.

For model-specific features and compartment details, use the 25364522404 owner’s manual.

Last updated: January 2026

For Kenmore model 25364522404, the correct water filter depends on whether your refrigerator is actually equipped with a water filtration system; the sure way to match the right cartridge is to confirm the filter style and part reference shown in the 25364522404 owner's manual.

How to identify the correct filter for your refrigerator

Use these quick checks before ordering:

• Look for a filter housing inside the fresh food compartment (often upper right) or in the base grille.
• Check for a filter status light or reset button on the control area.
• Remove the existing filter and note any printed numbers, letters, or “type” markings.
• If there is no filter housing and no filter installed, your model may not use a replaceable water filter.
• If your refrigerator has an ice maker or water dispenser but no internal filter, it may use an external inline filter.

Common filter setups (what you might have)

Setup	What you will see	What to do next
Internal cartridge filter	Twist-in or push-in filter in the refrigerator	Match the cartridge markings to the manual listing
No filter equipped	No filter housing, no cartridge installed	No filter needed unless you add an inline filter
Inline filter (external)	Small filter on the water line behind the refrigerator	Match by tubing size and flow direction; replace on schedule

Why it matters

Using the correct filter prevents leaks, weak water flow, and poor-tasting ice or water. It also helps protect the water system components by reducing sediment and contaminants.

Helpful next step if you are replacing a filter

If your refrigerator is equipped with a water filter, follow the replacement and reset steps in the how to replace the water filter in a Kenmore refrigerator guide so the indicator (if present) tracks filter life correctly.

Last updated: January 2026

On Kenmore refrigerator model 25364522404, the SY EF code indicates an evaporator fan circuit problem. The control is not detecting normal evaporator fan operation, so airflow from the freezer to the fresh food section can drop and temperatures can rise. Use the troubleshooting guidance in the 25364522404 owner's manual to locate the fan area and access panels safely.

What to check first (safe, quick checks)

• Make sure the freezer door closes fully and the door switch is being pressed.
• Listen for the evaporator fan with the door switch held in; it typically runs when cooling is active.
• Look for heavy frost on the freezer back wall; ice buildup can stop the fan or block airflow.
• Confirm air vents are not blocked by food packages.
• Power reset: unplug for 5 minutes, then restore power and recheck.

Common causes and next steps

What can trigger SY EF	What you may notice	What to do next
Fan blade obstructed or damaged	Rubbing, clicking, weak airflow	Inspect and replace the refrigerator evaporator fan blade 5308000010 if cracked, warped, or loose
Ice buildup contacting the fan	Fan noise changes, frost on back wall	Fully defrost and check for recurring frost patterns
Wiring or connector issue	Fan intermittent, code returns after reset	Inspect harness connections at the fan and control
Control not sensing fan feedback	Fan may run but code persists	Verify connections; schedule service if needed

Why this matters

The evaporator fan circulates cold air across the evaporator and into the refrigerator compartment. When the fan circuit fails, the refrigerator section often warms first, and the compressor can run longer than normal.

Helpful reference

For additional Kenmore-style error code patterns and troubleshooting flow, use the Kenmore 111 model top freezer refrigerator error codes guide as a practical reference.

Last updated: January 2026
