Kenmore 79040283411 electric wall oven Parts

No. “24-inch” wall ovens are grouped by nominal width, but the actual cabinet cutout, overall height, and depth vary by brand and model. For your Kenmore 79040283411 electric wall oven, use the exact cutout and clearance measurements listed in the 79040283411 installation guide before ordering a replacement or modifying cabinetry.

Even when two units are both called 24-inch wall ovens, these dimensions commonly differ:

• Cutout width (the cabinet opening) can vary by fractions of an inch
• Cutout height varies by design and trim style
• Overall depth varies based on door design and cooling airflow needs
• Trim overlap (how much the front frame covers the cabinet opening) varies
• Electrical requirements and junction box location can differ

These are common ranges for many 24-inch single electric wall ovens; always confirm with the installation specs for the exact model.

Measure the cabinet opening and compare it to the installation requirements for the exact model.

• Measure cutout width at the top, middle, and bottom
• Measure cutout height on both sides
• Measure cutout depth from the front of the cabinet to the back wall
• Check for rear clearance for wiring and airflow
• Confirm the door swing clears nearby drawers and handles

A wall oven that is even slightly different in cutout size can leave gaps, prevent the mounting screws from lining up, or restrict airflow. Using the correct specs for Kenmore 79040283411 helps you avoid cabinet rework and fit issues.

Last updated: February 2026

Most electric wall ovens, including Kenmore model 79040283411, are designed to run on a 240-volt (often called 220-volt) circuit, not a standard 120-volt (110-volt) household outlet. The exact electrical requirements for your installation are listed in the installation guide.

Electric wall ovens typically need a dedicated high-voltage circuit because the bake and broil elements draw much more power than a 120V outlet can safely provide.

• Voltage: typically 240V (sometimes specified as 208/240V)
• Circuit: typically dedicated (no other appliances on the same breaker)
• Connection: usually hardwired to a junction box (not a plug-in cord)
• Breaker size: commonly 30A to 50A depending on oven rating
• Wire size: commonly 10 AWG or 8 AWG copper depending on breaker and run length

Use these checks to match your home wiring to the oven requirements.

• Look up the required voltage and breaker size in the installation guide
• Verify the breaker in your electrical panel is a 2-pole breaker (typical for 240V)
• Confirm the oven is connected to a junction box with the correct gauge wire
• If the oven is not heating properly, inspect for loose or overheated connections at the terminal area (a damaged connection can cause low or no heat)

Using the wrong voltage or an undersized circuit can cause weak heating, nuisance breaker trips, or overheated wiring. Correct power supply helps the bake element, broil element, control board, and cooling fan operate as designed.

Last updated: February 2026

For your Kenmore electric wall oven model 79040283411, the model number is printed on a rating label attached to the oven frame or cabinet. The most common spot is along the oven door opening (door jamb) where you can see it when the door is open.

Check these locations in order; they are the most common for Kenmore wall ovens:

• Door jamb: open the oven door and look along the frame around the opening
• Side trim area: along the left or right side of the oven frame (visible with the door open)
• Lower oven frame: near the bottom edge of the opening (especially on double wall ovens)
• Behind the control panel area: sometimes visible from the front with the door open
• Installation paperwork: model number is often listed on the purchase or install documents

Most Kenmore wall oven rating labels include:

• Model number (example: 79040283411)
• Serial number
• Electrical rating (typically 240V information)
• Brand and safety certification markings

Kenmore model numbers can be very similar, and a single digit difference can change which parts fit (for example, a control board, bake element, or temperature sensor). Using the exact model number helps us match the correct diagrams and replacement parts the first time.

Use the model number exactly as shown on the label (include all digits). Then confirm the part using the diagrams and the 79040283411 owner's manual.

Last updated: February 2026

Kenmore model numbers are read left to right; the first 3 digits are the source (manufacturer) code, and the remaining digits identify the product series and specific configuration. For your Kenmore electric wall oven model 79040283411, the 790 prefix is the key identifier we use to match the correct parts and diagrams in the 79040283411 owner's manual.

Most Kenmore model numbers follow this pattern:

• Prefix (first 3 digits): manufacturer/source code (example: 790)
• Middle digits: product platform or series (helps narrow the design family)
• Last digits: feature set, revision, or cosmetic variation (helps match exact parts)

When ordering or troubleshooting, we recommend using the full model number exactly as shown on the rating plate.

• Match the entire model number (not just the 790 prefix)
• Use the model number to confirm the correct electrical and door parts
• Cross-check symptoms with common failure items (sensor, elements, control)
• If you are diagnosing heat problems, verify the wiring and connectors before replacing parts

Common parts customers replace on Kenmore 79040283411 include:

• Cooking appliance oven temperature sensor 5304504897
• Frigidaire wall oven bake element 139086600
• Wall oven broil element 139203500

On most Kenmore wall ovens, the rating plate is typically located in one of these spots:

• Along the oven frame behind the door (visible when the door is open)
• On the side trim area near the door opening
• Occasionally behind the lower drawer or lower access panel (if equipped)

A single digit difference can change the correct bake element, control board, or wiring harness for an electric wall oven. Using the full 79040283411 model number prevents wrong-part returns and speeds up repair.

Last updated: February 2026
