Samsung RF28HDEDTSR/AA-01 refrigerator Parts

For the Samsung RF28HDEDTSR refrigerator, the correct replacement water filter is the refrigerator water filter DA29-00019A. This is the filter we list for this model; replacing it on schedule helps keep water tasting clean and protects the dispenser and ice maker from flow restrictions.

How to confirm you have the right filter

Use these quick checks before ordering:

• Match the refrigerator model number: RF28HDEDTSR
• Match the filter part number: DA29-00019A
• Confirm the filter location (most Samsung French door units use an internal, twist-in filter)
• If your old filter has a different number, compare it to the parts list for this model
• Review the replacement steps in the owner's manual

Replacement interval and what to expect

Most refrigerator water filters should be replaced every 6 months, or sooner if water flow slows or ice production drops.

• After installing, flush several gallons of water through the dispenser to clear air and carbon fines
• Discard the first bin or two of ice after a filter change
• If the filter is hard to remove, turn it slowly and keep the housing aligned to avoid cracking

Common symptoms a clogged filter causes

A restricted filter often shows up as:

• Slow water dispensing
• Hollow or small ice cubes
• Ice maker stops filling consistently
• Water tastes or smells off
• Filter indicator stays on until reset

Quick reference

Item	What to use for RF28HDEDTSR
Water filter part number	DA29-00019A
Typical replacement timing	Every 6 months
Helpful DIY guidance	How to replace the water filter in a Samsung refrigerator

Why it matters

A fresh filter helps maintain steady water pressure to the inlet valve and ice maker, reduces sediment buildup, and keeps the dispenser system working the way it should.

Last updated: February 2026

If your Samsung RF28HDEDTSR bottom-mount refrigerator isn’t making ice, the most common causes are the ice maker being turned off, a frozen fill tube, low water flow from a clogged filter, or a temperature/airflow problem in the freezer. We recommend checking settings first, then water supply and ice buildup.

Quick checks we recommend first

• Confirm Ice On is enabled (not in “Ice Off” mode).
• Make sure the ice bucket is fully seated and not jammed with clumped ice.
• Set the freezer to 0°F (typical target for reliable ice production).
• Look for frost or ice around the ice maker area that could block the fill tube.
• Dispense water at the door (if equipped); weak flow points to a supply or filter restriction.

Reset and restart the ice maker

A reset often clears a stalled harvest cycle.

1. Remove the ice container and check for broken cubes or obstructions.
2. Use the ice maker test/reset function described in the owner's manual.
3. After resetting, allow 24 hours for normal production (and up to 48 hours after a full thaw or first startup).

Water supply and filter issues (very common)

Restricted water flow can stop ice production even if the dispenser still works.

• Replace the filter if it is older than 6 months or water flow is slow.
• After installing a new filter, flush several gallons of water to purge air.
• Verify the household shutoff valve is fully open and the supply line is not kinked.

Helpful part for this model:

Symptom	What it points to	Part to consider
Small cubes or no cubes	Low water flow	Refrigerator water filter DA29-00019A

Cooling and airflow problems that stop ice

If the freezer is too warm or airflow is blocked, the ice maker may not cycle.

• Make sure vents are not blocked by food packages.
• If you hear unusual fan noise or the freezer temperature swings, inspect for heavy frost buildup.
• If temperatures are inaccurate, a failed sensor can mislead the control.

Issue	What you may notice	Part that can be involved
Defrost problem	Frost buildup, warming	Refrigerator defrost heater DA47-00244U
Temperature sensing problem	Temps don’t match setting	Refrigerator temperature sensor DA32-10104N

Why it matters

An ice maker depends on three things working together: correct freezer temperature, steady airflow, and consistent water fill. Fixing the root cause prevents repeat clogs, leaks, and ice clumping.

For model-specific steps and control panel options, follow the owner's manual.

Last updated: February 2026

The Samsung RF28HDEDTSR bottom-mount refrigerator is 35 3/4 in. wide. Depending on whether you include hinges, doors, and handles, the overall size ranges from 68 7/8 to 70 in. high and 29 3/8 to 36 1/2 in. deep; confirm clearances in the owner's manual.

Dimension options (W x H x D)

Use the set that matches how you are planning the install and how the unit will sit in your kitchen.

• With hinges, handles, and doors: 35 3/4" x 70" x 36 1/2"
• With hinge and door, no handle: 35 3/4" x 70" x 34"
• Without hinges and door (cabinet only): 35 3/4" x 68 7/8" x 29 3/8"

Weight

Spec	Value
Approximate weight	390.2 lb.

How we recommend planning your space

These checks prevent fit and clearance problems with French door refrigerators.

• Measure the opening width at the front and back; use the smaller number.
• Verify height to the lowest cabinet, trim, or soffit.
• Plan depth for door swing and the freezer drawer pull-out.
• Allow room for leveling and ventilation clearance.
• If you are moving it in, compare cabinet-only depth to doorways and tight turns.

Why it matters

Using the correct dimension set (with handles vs. without) prevents a refrigerator that sticks out too far, doors that cannot open fully, or airflow restrictions that reduce cooling performance.

Last updated: February 2026
