Kenmore 25329401990 upright freezer Parts

The exact cubic-foot capacity for Kenmore upright freezer model 25329401990 is listed on the model’s product specifications in the 25329401990 owner's manual. If you are estimating for food planning, most Kenmore upright freezers in this style commonly fall in the mid-to-high teens (about 15 to 18 cu. ft.).

We recommend using the manual first because Kenmore model numbers can look similar but have different capacities.

• Check the specifications section in the 25329401990 owner's manual
• Compare the model and serial number plate inside the cabinet (often on the upper left wall on upright models)
• If you still need a quick estimate, measure interior space and convert to cubic feet

You can estimate capacity from interior measurements.

Formula: (width in inches × depth in inches × height in inches) ÷ 1728 = cubic feet

Capacity helps you plan food storage and freezing performance. For example, the manual guidance to freeze only about 3 pounds of fresh food per cubic foot at one time means a 15 to 18 cu. ft. freezer typically handles roughly 45 to 54 pounds per batch without overloading.

Last updated: January 2026

The most common problems we see with the Kenmore 25329401990 upright freezer are warm temperatures, heavy frost buildup, unusual noises, and water leaking inside or onto the floor. These symptoms usually trace back to airflow restrictions, door sealing issues, or a failing start or sealed-system component; use the 25329401990 owner's manual for model-specific checks.

• Freezer not cold enough: dirty condenser area, blocked vents, door not sealing, or compressor/start issue
• Frost or ice buildup: door left ajar, torn gasket, frequent openings, or moisture intrusion
• Clicking or humming with no cooling: compressor start device problem (start relay/starter) or compressor trouble
• Water on floor: drain or hose routing issue, or condensation from poor door seal
• Runs constantly: warm room conditions, overpacked cabinet blocking airflow, or gasket leak

1. Set the control colder and give it 24 hours to stabilize.
2. Confirm the door closes squarely and does not pop open.
3. Reduce overpacking; keep air paths open around shelves and vents.
4. Clean dust from the condenser area (unplug first).
5. Listen for repeated clicking every few minutes; that often indicates a start problem.

Catching a door-seal or airflow problem early prevents long run times that strain the compressor and can lead to food thawing. If you address the basic causes first, you often avoid unnecessary part replacement.

Last updated: March 2026

On the Kenmore upright freezer model 25329401990, the model and serial number plate is typically located on the upper left wall inside the freezer compartment. Check that area first, then look for a rating label in other common spots if it is not immediately visible.

• Upper left interior wall (most common for upright models)
• Inside the cabinet near the top (sometimes near the ceiling area)
• Along the door opening frame (hinge side)
• Behind the lower kick plate or front grille (if your unit has one)
• Rear exterior panel (less common, but possible)

• Open the door and use a flashlight; the plate can be small and easy to miss.
• Look on the upper left interior wall first.
• Wipe frost or condensation off the wall so the print is readable.
• Write down both numbers exactly as shown (model and serial).
• Use the model number when ordering parts and the serial number for age and service history.

We use the exact model number to match your Kenmore freezer to the correct parts, diagrams, and troubleshooting information. Even one extra digit can point to a different door gasket, control, or shelf configuration.

For the official location notes and recording fields, see the 25329401990 owner’s manual.

Last updated: January 2026
