Craftsman 917376151 lawn mower Parts

Gas walk-behind mowers like the Craftsman 917376151 are not being phased out everywhere at once, but new gas mower sales are gradually shrinking in some areas as emissions rules tighten and more homeowners switch to battery-electric models. You can still maintain and repair your mower normally using the 917376151 owner’s manual.

What “phased out” usually means

Most changes focus on new equipment sales, not on owning or repairing an existing mower.

• Some states and cities restrict or plan to restrict new sales of certain gas-powered outdoor equipment.
• Many retailers are expanding shelf space for battery mowers because demand is growing.
• Gas mowers remain common for larger yards, thick grass, and long run times.
• Parts support continues through normal channels; routine maintenance still applies.

What to do if you already own a gas mower

Keeping a gas mower reliable is mostly about fuel quality, blade condition, and seasonal maintenance.

• Use fresh unleaded regular fuel; this model’s manual lists 1.6 quarts gasoline capacity.
• Change oil on schedule; the manual lists 20 oz oil capacity and SAE 30 or SAE 5W-30 by temperature.
• Keep the blade sharp and properly tightened (manual spec: 35 to 40 ft-lbs blade bolt torque).
• Replace wear items as needed (blade, belt, wheels, drive parts).

Common “keep it running” parts for this model

If performance drops, these are frequent maintenance or drive-related items we see on the Craftsman 917376151.

Symptom	Often involved	Example model-matched part
Poor cut quality or vibration	Blade, blade hardware	Lawn mower blade 532406713
Self-propel slows or slips	Ground drive belt, drive control	Poulan lawn mower ground drive belt, 3/8 x 33-3/16-in 532196857
Drive engagement feels inconsistent	Drive control assembly/cable	Lawn mower drive control assembly 532193480

Why it matters

Even if new gas mower sales decline in your area over time, maintaining your current mower is usually the most cost-effective path. A sharp blade, correct oil, and a healthy drive system keep cut quality high and reduce strain on the engine.

Last updated: January 2026

On the Craftsman walk-behind mower model 917376151, the model and serial numbers are printed on a decal on the rear of the mower housing (back of the deck). We use that exact model number to match the correct parts list and owner’s manual.

Where to look on the mower

Check these common spots on a Craftsman walk-behind mower deck:

• Rear of the mower housing (most common location)
• Back of the deck between the lower handle mounts
• Near the discharge chute area (less common)
• On the engine shroud (engine model, not the mower model)

What to write down (and why)

Record both numbers before ordering parts or troubleshooting:

• Model number (example: 917376151)
• Serial number (unique to your mower)
• Date of purchase (helpful for maintenance tracking)

Quick ID guide

Item you find	What it identifies	When you use it
Mower model number (917376151)	The mower and its parts diagrams	Ordering wheels, blade, drive parts
Serial number	Your exact production unit	Verifying correct revisions/labels
Engine model (example: Briggs & Stratton)	The engine only	Engine tune-up and engine-specific parts

Tips if the decal is hard to read

• Wipe the area with a damp rag and mild soap; dry it fully.
• Use a flashlight at an angle to make faded printing easier to see.
• Take a close-up photo and zoom in.

Why it matters

Craftsman model numbers can look similar, but small differences change the blade, drive belt, wheels, and hardware that fit. Using the exact model number helps us match the correct diagrams and specifications in the 917376151 owner’s manual.

Last updated: January 2026

The model number for this Craftsman walk-behind lawn mower is 917.376151 (often written without the dot as 917376151). You’ll see it printed on the mower’s model label and on the cover page of the 917376151 owner's manual.

Where to find the model number on the mower

We recommend confirming the model number directly on the mower before ordering parts like a lawn mower blade or drive belt.

• Check the model label/decal on the mower deck or rear housing area
• Look for a line that says Model No. 917.376151
• Match the full number, including the dot (917.376151)
• Use the same model number when searching diagrams and parts lists

Why you might see it written two ways

Both formats refer to the same mower; the dot is just a formatting style.

Format you see	What it means	When it’s used
917.376151	Same model number	Common on the owner’s manual and model label
917376151	Same model number	Common on parts sites and search fields

Why it matters

Using the exact model number helps ensure parts fit correctly, especially for high-variation items like the 22-inch blade, drive components, and hardware. For example, the parts list for model 917.376151 includes items such as the lawn mower blade 532406713 and the ground drive belt.

Last updated: January 2026
