Kenmore Elite 11027072602 washer Parts

Yes; repairing a Kenmore Elite washer like model 11027072602 is worth it when the fix restores safe, reliable operation for less than the cost of replacement, especially for common failures such as draining problems, lid-lock issues, or out-of-balance vibration.

When repair is the better choice

We typically recommend repair when the washer’s core systems are sound and the problem is isolated to a serviceable part.

• The washer fills, drains, and spins but has one clear symptom (leak, no-drain, won’t start)
• The tub and cabinet are not heavily rusted or damaged
• The repair is a common wear item (pump, lid lock, suspension)
• You can confirm the issue with basic checks in the owner's manual
• The machine is otherwise meeting your needs (capacity, cycles, noise level)

Repairs that usually make sense on this model

These are frequent, straightforward repairs on Kenmore top-load platforms and often restore full performance.

Symptom	Common cause	Example part for 11027072602
Won’t drain or leaves water in tub	Drain pump issue or blockage	Pump-water W10536347
Won’t start or lid won’t lock	Lid lock failure	Washer lid lock WPW10619844
Banging, walking, off-balance	Worn suspension	Suspension W10820048

Quick cost-benefit checklist

Use this simple rule to decide quickly.

• Repair if the estimate is under about 50% of a comparable new washer and the fix addresses the root cause
• Replace if you need multiple major repairs at once (for example, tub/bearing plus motor plus control)
• Repair if the issue is safety-related or prevents operation (lid lock, draining) and the rest of the washer is solid

Why it matters

A targeted repair can extend the life of a Kenmore Elite washer and prevent secondary damage. For example, running with poor balance can stress the tub, hub, and drive components; correcting vibration early helps protect the wash system.

Last updated: February 2026

Kenmore washer model numbers use a prefix plus a series of digits to identify who built the washer and which design family it is. For your Kenmore Elite washer model 11027072602, the 110 prefix identifies the manufacturer family, and the remaining digits narrow down the exact version for correct parts and service info.

What each section of a Kenmore model number means

Most Kenmore washer model numbers break down like this:

• 3-digit prefix: manufacturer code (who built it)
• Middle digits: base model or design series
• Last digits: engineering revision, color, or feature variations

Example using your model

Model number	Prefix	What it’s used for	Why it matters
11027072602	110	Identifies the manufacturer family	Helps match the right diagrams and parts
11027072602	27072	Identifies the base design series	Helps match major assemblies (tub, drive, controls)
11027072602	602	Identifies the specific variation	Helps match exact-fit parts and updates

Where to find the model number on the washer

We recommend checking the model tag on the washer itself (not just paperwork), because a single digit change can affect part fit.

Common locations include:

• Under the lid on the top rim of the cabinet
• Around the lid opening near the tub
• On the rear panel
• On the inside of the cabinet (visible when the lid is open)

Why it matters for ordering parts

Using the full model number 11027072602 helps ensure you get the correct replacement part the first time, especially for fit-critical items.

Parts that commonly require an exact model match include:

• Lid lock assemblies such as washer lid lock WPW10619844
• Drain components such as pump-water W10536347
• Drive and spin components such as rotor 280146

Quick tip before you start a repair

If you’re using the model number to troubleshoot or service the washer, follow the safety and setup guidance in the owner's manual and confirm the washer is properly installed and leveled per the installation guide.

Last updated: February 2026

To force your Kenmore Elite washer model 11027072602 to drain, we recommend canceling the cycle and selecting a Drain/Spin option first. If the tub is still full, unplug the washer and manually drain water through the drain system, then clear the most common clogs before restarting.

Fast ways to get the water out

• Try Drain/Spin (or Cancel then Drain/Spin) to command the drain pump to run.
• Unplug the washer before any hands-on draining or panel removal.
• Lower the drain hose into a shallow pan to gravity-drain small amounts at a time.
• Check the standpipe height and hose insertion; the standpipe should be at least 39 in (99 cm) high.
• Prevent siphoning; do not insert more than 4 1/2 in (11.4 cm) of drain hose into the standpipe or drainpipe.

What usually prevents draining

Most “won’t drain” problems come from a restriction in the drain path or a failed drain pump.

Common causes to check:

• Kinked or crushed drain hose
• Lint, coins, or small items blocking the tub-to-pump or pump-to-hose path
• Standpipe or laundry tub drain backing up
• Failed drain pump motor or jammed impeller

If you suspect the pump is the issue, the correct replacement for this model is the pump-water W10536347.

Quick diagnostic table

What you see	Most likely cause	What we do next
Hums but no water moves	Pump jam or blockage	Inspect drain hose and pump area; replace pump if seized
Drains slowly	Partial clog or restricted hose	Straighten hose; clear obstruction; verify standpipe flow
Drains then refills or won’t finish	Siphoning due to drain setup	Correct standpipe height and hose insertion depth
Won’t start drain/spin	Lid not locking	Check lid lock operation; inspect washer lid lock WPW10619844

Why it matters

Forcing a drain without fixing the cause can lead to repeat stoppages, longer cycle times, and extra strain on the drain pump. Correct drain hose setup also prevents siphoning, which can mimic a drain failure.

For the correct drain hose routing, standpipe requirements, and anti-siphon guidance, follow the installation guide.

Last updated: February 2026

To hard reset your Kenmore Elite washer model 11027072602, unplug it (or switch off the breaker) for about 1 minute, then restore power and select a new cycle. This clears a temporary control glitch without changing the washer’s normal cycle presets in the control.

Quick hard reset steps

• Press STOP twice to end the current cycle and turn the washer off.
• Unplug the washer from the wall outlet (or turn the circuit breaker off).
• Wait 60 seconds.
• Plug the washer back in (or turn the breaker on).
• Press POWER, select a cycle, then press START.

For normal control operation and button functions on this model, use the owner's manual.

If the washer still will not start after a reset

These checks fix the most common “looks dead” or “won’t run” symptoms after power is restored:

• Confirm the washer is plugged into a grounded 3-prong outlet (no adapter, no extension cord).
• Make sure the lid is fully closed; the washer will not start with the lid open.
• If the Lid Lock light stays on or the lid will not lock, inspect the lid strike area and consider replacing the washer lid lock WPW10619844.
• If the washer stops mid-cycle, press START to restart after selecting your Modifiers and Options.
• If the tub will not drain and the cycle will not complete, check for a drain restriction; a failed drain pump can require replacing the pump-water W10536347.

Reset vs. stop/pause: what’s the difference?

Action	What it does	When to use it
Press STOP once	Pauses cycle and unlocks lid (after Lid Lock light turns off)	Add a garment or pause briefly
Press STOP twice	Stops cycle and turns washer off	Cancel a cycle before resetting
Unplug for 60 seconds	Clears a temporary control glitch	Random freezing, unresponsive buttons

Why it matters

A hard reset is the fastest way to clear a momentary control issue after a power flicker or a stalled cycle. If the problem returns, the cause is usually a lid-lock issue, a drain problem, or an out-of-balance condition that needs troubleshooting rather than repeated resets.

Last updated: February 2026

Your Kenmore Elite washer model 11027072602 is a front-load washer; most full-size front-load washers are about 3.5 to 4.5 cu. ft. For the exact rated capacity for your specific unit, check the specifications section in the 11027072602 owner's manual.

Where to find the exact capacity in the manual

In the manual, look for wording such as “Capacity,” “drum volume,” “basket volume,” or “specifications.” If you are confirming fit for a replacement washer or planning laundry room space, also verify these common spec items:

• Overall width, depth, and height
• Electrical requirement (grounded 3-prong outlet)
• Water supply hookup (hot and cold inlet connections)
• Drain requirements (standpipe or laundry tub setup)
• Leveling requirements to reduce vibration

Practical load-size guide (front-load capacity classes)

Once you know the cubic-foot rating, use these real-world load guidelines to avoid poor cleaning and out-of-balance spinning:

• 3.5 to 3.8 cu. ft.: everyday mixed loads, smaller towel loads
• 4.0 to 4.5 cu. ft.: larger family loads, more towels or jeans
• Over 4.5 cu. ft.: bulky items fit more easily (comforters, blankets)

Quick comparison table

Capacity class	Best for	What happens if you overload
3.5 to 3.8 cu. ft.	regular weekly laundry	poor tumbling, items stay packed
4.0 to 4.5 cu. ft.	larger mixed loads	vibration, longer cycle time
Over 4.5 cu. ft.	bulky bedding	poor spin-out, more noise

Why it matters

Correct capacity helps you load the drum properly so clothes tumble and rinse correctly. Overloading a front-load washer increases vibration and can contribute to drainage issues if water cannot move freely during the cycle.

If you are troubleshooting slow or no draining (often mistaken for “too small” capacity), a common related part is the Pump-water W10536347.

Last updated: February 2026
