To reset your Kenmore Elite 79096593602 oven back to factory default settings, press and hold the 7 keypad for about 6 seconds until you hear a single beep, then press START once. This clears stored recipes and resets common control adjustments.

What this reset changes (and what it does not)

This reset is a control-board settings reset (not a breaker reset). It typically affects user-programmable options.

• Clears any stored recipe programmed under the Bake key
• Resets 12/24-hour clock display preference
• Resets energy-saver or continuous bake mode settings
• Resets silent control operation setting
• Resets Fahrenheit/Celsius display setting
• Resets any oven temperature offset adjustments

For the exact button locations and feature names on your control panel, use the owner's manual.

If the oven is acting up after a power outage

If you had a power failure, the range can resume operation when power returns if it was left on. After power is restored:

• Turn the oven and surface elements off
• Reset the clock
• Re-enter any desired oven function (Bake, Broil, Cook Time)

Quick comparison: settings reset vs power reset

Reset type	How to do it	What it’s for
Settings reset (factory defaults)	Hold 7 for 6 seconds, then press START	Clears stored recipes and resets control preferences
Power reset (hard reset)	Turn the range off at the breaker for 1 to 2 minutes, then restore power	Clears a temporary control glitch after a surge or lockup

Why it matters

A factory-default reset is the fastest way to fix odd control behavior caused by changed settings (temperature display mode, silent beeps, or temperature calibration). It also helps after troubleshooting because it returns the oven controls to a known baseline.

Last updated: February 2026

Kenmore is a brand name sold by Sears, and the Kenmore Elite electric range model 790.9659* (including 79096593602) is part of the 790 model series that was produced for Sears by an OEM manufacturer. For parts and service information, we match everything by the full model number 79096593602 in the owner's manual.

How to identify the maker behind the 790 prefix

The most reliable way to identify the original manufacturer is the model prefix. For Kenmore ranges:

• The 790 prefix is associated with ranges built for Sears by Frigidaire/Electrolux.
• The remaining digits (like 96593602) identify the exact configuration (features, color code, and revisions).
• Parts listings for this model commonly cross to Frigidaire-style part numbering (for example, oven sensors and elements).

Quick reference

What you see	What it means	Why it helps
790.9659*	Kenmore Elite range series	Confirms you are in the correct family
79096593602	Full model number	Ensures correct fit for parts
Frigidaire/Electrolux-style parts	OEM supply chain	Helps when comparing part descriptions

Why it matters when ordering parts

Kenmore-branded appliances can be built by different manufacturers, so the OEM matters because it affects:

• Wiring and control layouts
• Oven sensor and heating element styles
• Door lock and switch designs
• Surface element compatibility
• Correct troubleshooting steps in the manual

If you are replacing a common failure part on this model, examples from the parts list include the frigidaire range oven temperature sensor 316490000 and the frigidaire range bake element 316413800.

Tip: confirm the exact model before you buy

Use the rating plate model number (not just “790.9659”) and match it exactly to 79096593602. If your last digits differ, the correct bake element, broil element, or wire harness can change.

Last updated: February 2026

If your Kenmore Elite electric range 79096593602 is not heating, the most common causes are a power supply problem (tripped breaker), an incorrect control setting or cooktop lockout, or a failed heating component such as a bake element, broil element, or oven temperature sensor. Use the owner's manual to confirm control settings and error-code steps.

Quick checks we recommend first

• Verify the range has power; reset any tripped circuit breaker(s).
• Confirm you are using the correct surface element control for the burner you want.
• If the cooktop display shows "- -", the ESEC lockout is active; unlock it (the manual notes holding CLOCK for about 3 seconds).
• Try a different surface element and a different cookware pan (flat, medium or heavyweight pans heat more evenly).
• If the oven is the issue, test Bake and Broil separately to narrow the failure.
• If the control is beeping and shows an F code, press STOP to clear it, then retry the function.

What failed parts usually cause “not heating”

When power and settings are correct, these parts are the most common heat-related failures on an electric range:

Symptom	Most likely area	Common part to check
Oven will not heat in Bake	Bake circuit	Frigidaire range bake element 316413800
Oven will not heat in Broil	Broil circuit	Frigidaire range broil element 316203301
Oven temperature is erratic or won’t regulate	Temperature sensing	Frigidaire range oven temperature sensor 316490000

Why it matters

A range that “won’t heat” can be a simple control lockout or breaker issue, but it can also be an electrical failure that overheats wiring or prevents the oven from reaching safe cooking temperatures. Narrowing the symptom (surface vs. oven, bake vs. broil) speeds up the right repair.

Last updated: February 2026

On a Kenmore Elite electric range model 79096593602, the NCAL code points to a control calibration problem. Start by resetting power for about 1 minute; if NCAL returns, the electronic oven control typically needs replacement. See the owner's manual for control and display details.

What to do when NCAL shows up

• Press STOP/CLEAR to silence beeping (if the keypad responds).
• Turn power off at the breaker (preferred) or unplug the range for 1 minute.
• Restore power and set the clock if needed.
• Try a simple heat test: Bake at 350°F for 20 to 30 minutes and watch for normal operation.
• If NCAL reappears, plan for a control repair; also inspect for loose connections at the rear terminal area.

Quick checks before replacing parts

NCAL is usually control-related, but these checks prevent repeat failures:

• Confirm the range is on a proper 240V circuit and the breaker is not tripping.
• Look for signs of overheating or arcing at the power connection area (burnt smell, discoloration).
• If the display shows other fault codes (often starting with F), write them down and address those first.

Parts that are commonly involved in temperature and control symptoms

These parts do not “cause” NCAL in every case, but they are frequent suspects when the oven won’t regulate heat correctly:

Symptom you notice	Common part to check	Part option on this model page
Oven temperature swings, underbakes, overbakes	Oven temperature sensor	Range oven temperature sensor 316490000
Oven will not heat in Bake	Bake element	Frigidaire range bake element 316413800
Oven will not heat in Broil	Broil element	Frigidaire range broil element 316203301

Why it matters

When the control loses calibration, it can misread sensor feedback and drive the bake or broil circuits incorrectly. Fixing the root cause helps prevent poor baking results, nuisance error codes, and repeated shutdowns.

Last updated: February 2026

On your Kenmore Elite electric range model 79096593602, the model number is on the rating label. The label is most often on the oven frame behind the door, or on the frame behind the lower storage or warming drawer; confirm the exact spot using the 79096593602 owner's manual.

Common places to check first

Look in these locations in order:

• Oven door frame (door jamb): open the oven door and check the frame around the opening
• Behind the bottom drawer: pull the storage or warming drawer out and look on the frame rails or side panels
• Rear of the range: check the back panel near where the power cord enters and near the terminal block cover
• Lower side frame: check the front lower side panels near the floor

What to write down from the label

Copy the model number exactly as printed (for this range, it is the full number 79096593602).

Label item	What to record	Why it matters
Model number	79096593602	Matches you to the correct diagrams and replacement parts
Serial number	The full serial shown	Helps identify the production run for service and compatibility
Electrical rating	Volts/amps listed	Useful when diagnosing heating or power issues

Tips that make it easier

• Use a flashlight; the label is usually a white or silver sticker/plate with dense text.
• If the drawer stops, lift slightly and pull straight out (remove cookware first).
• If you see a shorter series like 790.9659 on paperwork, keep looking for the full model number on the appliance label before ordering parts.

Why it matters

Using the exact model number helps ensure correct fit when replacing parts such as the frigidaire range bake element 316413800, frigidaire range broil element 316203301, or frigidaire range oven temperature sensor 316490000.
