Kenmore 10660934901 refrigerator Parts

A fridge with the freezer on top is called a top-freezer refrigerator, also commonly called a top-mount refrigerator. Your Kenmore 10660934901 is this style, with the freezer compartment above the fresh food compartment and separate side-swing doors.

• Top-freezer refrigerator
• Top-mount refrigerator
• Freezer-on-top refrigerator
• Traditional two-door top freezer

Knowing the style helps us match the right parts and repair steps because airflow, defrost components, and door hardware are laid out differently on top-freezer models.

For example, on many top-freezer designs (including this Kenmore layout), cool air circulates between the freezer and refrigerator sections through vents; blocking vents can cause temperature and moisture problems.

• For door swing, hinge, and alignment details on the Kenmore 10660934901, use the 10660934901 owner's manual.
• If you are troubleshooting a display or control error on Kenmore 106 models, use the Kenmore 106 model refrigerator error codes guide.

Last updated: January 2026

For Kenmore model 10660934901, the most reliable way to confirm cubic feet is to look up the capacity in the product specifications section of the 10660934901 owner's manual. If you cannot find a stated capacity there, you can still estimate cubic feet by measuring the usable interior space and converting cubic inches to cubic feet.

• Check the specifications section in the 10660934901 owner's manual.
• Look for a rating label inside the fresh food compartment (often on a side wall or near the crisper area); some units list capacity there.
• Estimate capacity by measuring interior dimensions and converting.
• Use the model number to identify the correct spec sheet when shopping for replacement shelves, bins, or drawers.

1. Empty the compartment you are measuring (fresh food and freezer are often listed separately).
2. Measure width x depth x height of the usable interior space in inches.
3. Multiply to get cubic inches.
4. Divide by 1,728 to convert to cubic feet.

Knowing cubic feet helps us match the right Kenmore refrigerator parts and accessories for your space and airflow needs, especially when replacing door storage like the refrigerator door bin WPW10172187 or interior shelving.

Last updated: January 2026

For Kenmore model 10660934901, the correct water filter is the one specified for that exact model in the product documentation and accessories list. We recommend matching by model number (not by a filter number printed on an old cartridge) to ensure proper fit, flow, and leak-free sealing.

Use these checks to confirm compatibility before you buy:

• Confirm the refrigerator model tag reads 10660934901 (usually inside the fresh food section).
• Check the filter location (inside the refrigerator, in the base grille, or in-line behind the unit).
• Compare the old filter’s end-cap shape and locking style (twist-in vs push-in).
• If you have an ice maker, confirm the refrigerator is connected to a cold water supply and has adequate water pressure.
• Use the filter part reference listed in the 10660934901 owner's manual.

Low flow is often a supply or restriction issue, not the filter itself. For this Kenmore top-mount style, we use these steps:

• Make sure the shutoff valve is fully open.
• Confirm the supply line is not kinked behind the refrigerator.
• If you use reverse osmosis, verify the system is delivering adequate pressure to the refrigerator.
• Flush the new filter per the instructions so trapped air clears.
• If flow is still weak, replace a clogged filter and recheck the water line.

Using the correct filter for Kenmore 10660934901 protects the water system from leaks, keeps ice maker fill times consistent, and helps maintain normal water taste and odor performance.

Last updated: January 2026

To replace the water filter on a Kenmore 10660934901 top-mount refrigerator, we shut off the ice maker, open the filter access door (usually in the fresh food section), remove the old filter, install the new one fully seated, then flush water to clear air and carbon fines. See the 10660934901 owner's manual for the exact filter location and reset steps.

• Turn the ice maker OFF before starting (helps prevent air from entering the water system).
• Open the filter access door or cover.
• Remove the old filter (most styles either twist a quarter-turn or push and release).
• Install the new filter and lock it in place (push in firmly or twist until it stops).
• Dispense and discard several minutes of water to purge air and loose carbon.
• Turn the ice maker back ON and discard the first batch of ice.

A taped or broken filter door is common on used refrigerators. We recommend:

• Carefully remove tape and adhesive residue so the door can open without cracking.
• If the door will not open, access may require removing the housing trim or cover screws.
• Avoid prying hard; the plastic tabs can snap and create an air leak path.

This Kenmore refrigerator’s water system needs 30 to 120 psi to run the ice maker properly; reverse osmosis setups often reduce pressure and can cause slow fill or no ice. The manual also notes RO systems typically need 40 to 60 psi minimum on the supply side. Refer to the 10660934901 owner's manual for the full water supply requirements.

A properly installed water filter protects the water inlet valve and ice maker from sediment, improves taste and odor, and helps prevent low-flow issues that can lead to small cubes or hollow ice.

Last updated: January 2026
