Frigidaire FFGF3023LWE gas range Parts

On the Frigidaire gas range model FFGF3023LWE, the model and serial number identification plate is on the right-hand surface of the oven front frame. Open the storage, warmer, or broiler drawer to access the plate; the exact location is shown in the FFGF3023LWE installation guide.

1. Make sure the oven is off and cool.
2. Pull the bottom drawer straight out (storage drawer, warmer drawer, or broiler drawer depending on your range).
3. Look at the right side of the oven front frame (the front frame area behind the drawer opening).
4. Record the model number, serial number, and any lot number/letter shown.

When we help you look up Frigidaire range parts or troubleshoot a symptom, these details prevent ordering the wrong component.

• Model number (example: FFGF3023LWE)
• Serial number
• Lot number or letter (if listed)
• Fuel type and pressure rating shown on the plate
• Burner ratings (BTU information)

Frigidaire ranges can look similar across model families, but parts like an oven igniter, temperature sensor, or control overlay can vary by revision. Using the exact model and serial information helps us match the correct diagrams and parts for FFGF3023LWE.

Last updated: February 2026

On the Frigidaire FFGF3023LWE gas range, you reset an F31 code by clearing the fault, then removing power to the range for about 5 minutes and restoring power. If F31 returns, the oven temperature sensor circuit is the most common cause.

• Press Clear/Off to stop the beeping and clear the display.
• Turn Bake or Broil on again to see if the code returns.
• If it returns, switch OFF power at the breaker (or unplug the range).
• Wait 5 minutes.
• Restore power, then set the clock.
• Test Bake again; if F31 comes back, move to troubleshooting.

For control locations and basic operation, use the FFGF3023LWE owner's manual.

F31 is typically tied to the oven temperature sensor (probe) circuit. The issue is usually one of these:

• Sensor resistance out of range (failed sensor)
• Loose or corroded sensor connector
• Pinched, burned, or broken wiring between sensor and control
• Control board input problem (less common)

A common replacement part for this symptom is the range oven temperature sensor 316490000.

• Shut off power at the breaker before touching wiring.
• Inspect the sensor harness connection at the sensor and at the control (look for loose pins).
• Check for heat damage where the harness passes near the oven cavity.
• If you have a multimeter, test the sensor resistance at room temperature (compare to the spec in the manual/service info).
• If wiring and sensor test good, the oven control board becomes the next suspect.

When the control detects a bad temperature signal, it may shut down heating to prevent overheating or unsafe operation. Fixing the sensor circuit restores accurate temperature control for baking and broiling.

Last updated: February 2026

If your Frigidaire FFGF3023LWE gas range smells like gas, treat it as a safety issue first: turn all burner knobs to OFF, avoid flames and electrical switches, and follow the “What to do if you smell gas” steps in the FFGF3023LWE installation guide. After the area is safe, the most common appliance-related causes are a burner that is not lighting cleanly or an oven burner ignition problem.

• Do not try to light any burner or the oven.
• Do not touch electrical switches or use a phone inside the home.
• Move to fresh air and call your gas supplier from a neighbor’s phone.
• If you cannot reach your gas supplier, call the fire department.
• Have installation and service performed by a qualified installer or service agency.

A brief gas odor can happen when gas is flowing but not igniting right away. These issues are common on gas ranges:

• Surface burner ports clogged (spillovers, grease): delayed ignition and a “puff” of gas smell.
• Weak or failing igniter in the oven: the burner may take too long to light.
• Loose burner cap or misaligned burner head: flame lifts or lights unevenly.
• Gas valve or regulator issue: improper gas flow can affect combustion.

If the smell happens mainly when using the oven (bake), a weak igniter is a top suspect.

A persistent gas smell can indicate unburned gas or improper combustion. Addressing ignition and burner alignment quickly helps your range light reliably and reduces the risk of unsafe operating conditions.

Last updated: February 2026

On the Frigidaire FFGF3023LWE gas range, we do not manually light the oven burner; it uses a hot-surface igniter and should light automatically within about 60 seconds after you set Bake or Broil. If it does not ignite, troubleshoot the igniter and gas supply instead.

• Set the control to Bake 300°F and watch for ignition; the burner should light within 60 seconds.
• Listen for the igniter cycling; it can glow, then cycle off after the oven reaches temperature.
• Confirm the range has power (the oven igniter needs electricity even though it is a gas oven).
• Make sure the gas shutoff valve is fully open.
• If you smell gas and the burner is not lighting, turn the control OFF and ventilate the area.

The installation instructions describe a normal delay and cycling pattern for the oven burner.

If the oven will not ignite (or takes much longer than a minute to light), the most common fix is replacing the igniter.

• For bake ignition issues, check the tappan range oven burner igniter 316489403.
• For broil ignition issues, check the range oven igniter 5304506545.
• If temperatures are inaccurate after it lights, the Frigidaire range oven temperature sensor 316490000 is a common suspect.

Trying to manually light an oven that is designed for electronic ignition can create delayed ignition, flare-ups, and unsafe gas buildup. Using the built-in ignition sequence keeps flame lighting controlled and consistent.

For operating steps and safety notes specific to the FFGF3023LWE, follow the FFGF3023LWE owner’s manual.

Last updated: February 2026
