Kenmore 25321741102 freezer Parts

Kenmore upright freezer model 25321741102 has a 17.2 cubic feet total capacity. You can confirm the exact capacity for your unit on the rating label inside the cabinet and in the specifications section of the 25321741102 manual.

Use these quick checks to match the published spec to your exact unit:

• Check the rating label inside the freezer compartment (commonly on a side wall).
• Match the full model number 25321741102 on the label to the model shown in the 25321741102 manual.
• If the label is frosted over or faded, defrost and wipe it clean, then take a close-up photo.

Manufacturers list total (rated) capacity; usable space is slightly less because shelves, baskets, and airflow channels take up room.

Knowing the correct cubic feet helps you plan bulk shopping, avoid blocking air vents, and keep temperatures stable when loading fresh food.

To keep temperatures steady when adding unfrozen food:

• Allow about 4 hours for the freezer to cool down before loading unfrozen items.
• Freeze no more than 3 pounds of fresh food per cubic foot at one time.
• Spread packages across shelves for airflow.
• Avoid packing food tightly against the back wall.

Last updated: January 2026

On the Kenmore upright freezer model 25321741102, there is not a dedicated “reset” button for the cooling system. Most “reset” situations are handled by power-cycling the freezer and then re-setting the temperature control inside the cabinet; the alarm switch (if equipped) is separate.

• Unplug the freezer (or switch the breaker off) for 5 minutes.
• Plug it back in and set the temperature control to your normal setting.
• Allow several hours for temperatures to stabilize after any adjustment.
• If the freezer was just installed or restarted, allow 4 hours for a full cool-down before loading unfrozen food.
• If your freezer has a high-temp alarm, open the door and set the alarm switch to ON only after the freezer is cold.

For control locations and operating details specific to this model, use the 25321741102 owner's manual.

Some upright models include a high-temp alarm ON/OFF switch that you can view only with the door open. That switch does not reset the freezer; it only enables or disables the alarm.

A freezer that seems like it “needs a reset” is often reacting to a warm cabinet after a door-left-open event, a recent power interruption, or a heavy load of unfrozen food. Using the correct cool-down time and stable temperature settings prevents unnecessary part replacements.

Last updated: January 2026

The most common issues we see with the Kenmore 25321741102 upright freezer are warm temperatures, heavy frost buildup, unusual noises, and door sealing problems. These symptoms usually trace back to airflow, defrost-system, temperature-control, or door-gasket faults; use the owner's manual for model-specific checks.

• Freezer not cold enough: dirty condenser coil, weak evaporator fan, failing start components, or a temperature control issue
• Frost or ice building up on the back wall: defrost heater, defrost timer, or airflow restriction
• Loud buzzing, clicking, or humming: compressor start relay or fan motor noise
• Door hard to open or moisture around the door: worn or warped door gasket, door not aligned
• Water or ice at the bottom: drain area blocked by ice or debris

1. Set the control to a mid setting and allow 24 hours for temperature to stabilize.
2. Make sure vents are not blocked by packages; keep space around the evaporator cover.
3. Clean dust from the condenser area; restricted airflow raises temperatures.
4. Check the door seal with the paper test (paper should drag when pulled).
5. Listen for the evaporator fan; it should run when the unit is cooling.

Catching a defrost or airflow problem early prevents ice from choking circulation, keeps food safely frozen, and reduces compressor run time and energy use.

Last updated: March 2026
